10-way DMX Splitter
Instruction Manual
Model:
DSR10N: RJ45 connectors
DSR10N-3 : 3pin/RJ45 DMX connectors
DSR10N-5 : 5pin/RJ45 DMX connectors
Version 2: 11/2015
ATTENTION!
This instruction manual contains important information about the
installation and the use of equipment. Please read and follow these
instructions carefully.
Always ensure that the power to equipment is disconnected before
opening the equipment or commencing any maintenance work.
SRS Light Design s.r.o, Rybničná 36/D , 831 06 Bratislava, Slovak Republic
tel:+421244681417, fax:+421244681419,
www.srslight.com
,
sales@srslight.com
Advertisement
Table of Contents
Related Manuals for SRS Light Design DSR10N
Summary of Contents for SRS Light Design DSR10N
- Page 1 Please read and follow these instructions carefully. Always ensure that the power to equipment is disconnected before opening the equipment or commencing any maintenance work. SRS Light Design s.r.o, Rybničná 36/D , 831 06 Bratislava, Slovak Republic tel:+421244681417, fax:+421244681419, www.srslight.com sales@srslight.com...
- Page 2 Data + Pin 4, 5 Pin 1, 3 Data + Pin 2, 6 Data - Pin 4, 5 Pin 7, 8 Ground / Common SRS Light Design s.r.o, Rybničná 36/D , 831 06 Bratislava, Slovak Republic tel:+421244681417, fax:+421244681419, www.srslight.com sales@srslight.com...
-
Page 3: Front Panel
When the DMX cable is connected to the device, all LEDs marked as 2 / 3 or the sign of signal polarity goes ON and this indicates that DSR10N is functioning properly and retransmitting the input to the splitted outputs. If any of LEDs is off, check the cable first –... -
Page 4: Technical Data
Dimensions & housing: 1U, 19” format, 482.5 x 44.5 x 130 mm Weight: 2.1 kg Package consists of: DSR10N, IEC or PowerCon cable, Printed manual Warranty: Life-time DECLARATION OF CONFORMITY According to guidelines 89/336 EEC and 92/31 EEC: Name of producer: SRS Light Design s.r.o.
