Summary of Contents for Asus STRIX B250F GAMING

  • Page 1 STRIX B250F GAMING...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ....................... v About this guide ......................vi STRIX B250F GAMING specifications summary ........... viii Package contents ...................... xii Installation tools and components ................. xiii Chapter 1: Product Introduction Motherboard overview ................1-1 1.1.1 Before you proceed ..............1-1 1.1.2...
  • Page 4 3.6.11 USB Configuration ..............3-14 Monitor menu ................... 3-15 Boot menu ....................3-15 Tool menu ....................3-16 3.9.1 ASUS EZ Flash 3 Utility ............3-16 3.9.2 Secure Erase ................3-16 3.9.3 ASUS SPD Information ............. 3-17 3.9.4 Graphics Card Information ............3-17 3.10...

  • Page 5: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 6: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 7: Conventions Used In This Guide

    Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task.

  • Page 8: Strix B250F Gaming Specifications Summary

    DDR4 ® 2133MHz. *** Refer to www.asus.com for the lastest Memory QVL(Qualified Vendors List). 1 x PCIe 3.0/2.0 x16_1 slot (at x 16 mode) 1 x PCIe 3.0/2.0 x16_2 slot (max. at x 4 mode)* Expansion slots 4 x PCIe 3.0/2.0 x1 slots...
  • Page 9 STRIX B250F GAMING specifications summary 2 x USB3.1 ports (1 x typeA [red] and 1 x Type C) 4 x USB2.0 ports 1 x DVI port 1 x HDMI port 1 x DP port Rear Panel I/O Ports 1 x PS/2 keyboard/mouse combo port 2 x USB 3.0 ports [blue]...
  • Page 10 STRIX B250F GAMING specifications summary ROG RAMCache II ROG GameFirst IV* ROG Overwolf ROG Exclusive Features ROG CPU-Z ROG CloneDrive * ROG GameFirst IV is only available for Windows 10/8.1 64-bit. ® Performance Optimization - DIGI + VRM - GPU Boost...
  • Page 11 1 x Clear CMOS jumper (2-pin) 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, BIOS Features F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD...

  • Page 12: Package Contents

    Package contents Check your motherboard package for the following items. Motherboard STRIX B250F GAMING 4 x SATA 6Gb/s cables Cables 1 x RGB LED extension cable 1 x I/O shield 1 x ROG cable label Accessories 1 x Strix series sticker 1 x 3D Printing Mount 1 x M.2 Screw Package...

  • Page 13: Installation Tools And Components

    Installation tools and components Intel 1151 CPU ® Intel 1151 compatible CPU Fan ® Phillips (cross) screwdriver SATA hard disk drive PC chassis 1 bag of screws DIMM Power supply unit SATA optical disc drive (optional) Graphics card The tools and components listed above are not included in the motherboard package. xiii...

  • Page 15: Chapter 1: Product Introduction

    Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component. • Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. ASUS STRIX B250F GAMING...

  • Page 16: Motherboard Layout

    LGA1151 KBMS_USB78 LAN_USB3_56 CHA_FAN1 AIO_PUMP AUDIO 2280 2260 2242 PCIEX1_1 PCIE SATA IRST PCIEX16_1 Intel I219V Intel ® ASM1480 BATTERY strix b250F GAMING B250 Super PCIEX1_2 128Mb BIOS PCIEX16_2 1220 COVER 22110 2280 2260 2242 PCIEX1_3 MOUNT SB_PWR PCIEX1_4 USB3_34...

  • Page 17: Layout Contents

    9. USB 3.0 connectors (20-1 pin USB3_12, USB3_34) 1-13 10, Intel Serial ATA 6 Gb/s connectors (7-pin SATA6G_1~6) 1-13 ® 11. Standby power LED (SB_PWR) 1-11 12. Clear RTC RAM jumper (2-pin CLRTC) 13. System panel connector (20-5 pin PANEL) 1-18 14. Thermal sensor cable connector (2-pin T_SENSOR) 1-19 15. USB 2.0 connector (10-1 pin USB1112) 1-15 16. ROG Extension connector (18-1 pin ROG_EXT) 1-14 17. TPM connector (14-1 pin TPM) 1-14 18. RGB header (4-pin RGB_HEADER) 1-21 19. Serial port connector (10-1 pin COM) 1-19 20. Front panel audio connector (10-1 pin AAFP) 1-12 ASUS STRIX B250F GAMING...

  • Page 18: Central Processing Unit (Cpu)

    1.1.3 Central Processing Unit (CPU) The motherboard comes with a surface mount LGA1151 socket designed for the 7th / 6th Generation Intel Core™ i7 / Intel Core™ i5 / Intel Core™ i3, Pentium , and Celeron ® ® ® ® ® processors. strix b250F GAMING STRIX B250F GAMING CPU socket LGA1151 • Ensure that all power cables are unplugged before installing the CPU. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1151 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap.

  • Page 19: System Memory

    1.1.4 System memory The motherboard comes with four DDR4 (Double Data Rate 4) Quad Inline Memory Modules (DIMM) slots. A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot. strix b250F GAMING STRIX B250F GAMING 288-pin DDR4 DIMM sockets Recommended memory configurations ASUS STRIX B250F GAMING...

  • Page 20: Memory Configurations

    For more details, refer to the Microsoft support site at http://support.microsoft. ® com/kb/929605/en-us. • The design of the DIMM fan may vary. Ensure that the DIMM fan fits to the motherboard • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. • For system stability, use a more efficient memory cooling system to support a full memory load (4 DIMMs) or overclocking condition. • Memory modules with memory frequency higher than 2133MHz and their corresponding timing or the loaded XMP profile is not the JEDEC memory standard. The stability and compatibility of the memory modules depend on the CPU’s capabilities and other installed devices. • Always install the DIMMS with the same CAS Latency. For an optimum compatibility, we recommend that you install memory modules of the same version or data code (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • ASUS exclusively provides hyper DIMM support function. • Hyper DIMM support is subject to the physical characteristics of individual CPUs. Load the X.M.P. or D.O.C.P. settings in the BIOS for the hyper DIMM support. • Visit the ASUS website for the latest QVL. Chapter 1: Product Introduction...

  • Page 21: Expansion Slots

    1.1.5 Expansion slots Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. PCIEX1_1 PCIEX16_1 STRIX B250F GAMING PCIEX1_2 PCIEX16_2 PCIEX1_3 PCIEX1_4 Slot No. Slot Description PCIe x1_1 slot PCIe x16_1 slot PCIe x1_2 slot PCIe x16_2 slot PCIe x1_3 slot PCIe x1_4 slot ASUS STRIX B250F GAMING...
  • Page 22 • We recommend that you provide sufficient power when running CrossFireX™ mode. • Connect a chassis fan to the motherboard connector labeled CHA_FAN1-2 when using multiple graphics cards for better thermal environment. IRQ assignments for this motherboard PCIe x1_1 – – – shared PCIe x16_1 shared – – – PCIe x1_2 – – – shared PCIe x16_2 shared – – – PCIe x1_3 – – shared – PCIe x1_4 – shared – – XHCI Controller shared –...

  • Page 23: Headers / Holes

    1.1.6 Headers / Holes Clear RTC RAM (2-pin CLRTC) This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. CLRTC strix b250F GAMING PIN 1 STRIX B250F GAMING Clear RTC RAM To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Use a metal object such as a screwdriver to short the two pins. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data. If the steps above do not help, remove the onboard battery and short the two pins again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery. ASUS STRIX B250F GAMING...
  • Page 24 3D Mount holes Create a 3D printout and secure it to these 3D Mount holes for a personalized motherboard. 3D Mount strix b250F GAMING 3D Mount STRIX B250F GAMING 3D Printing Mount • Download 3D source files at http://www.asus.com. • Use the bundled 3D printing mount screws to install the 3D printouts. Chapter 1: Product Introduction 1-10...

  • Page 25: Onboard Leds

    BOOT_DEVICE_LED VGA_LED DRAM_LED CPU_LED strix b250F GAMING STRIX B250F GAMING CPU/DRAM/ BOOT_DEVICE/VGA LED Standby Power LED (SB_PWR) The motherboard comes with a standby power LED. The LED lights up to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED. strix b250F GAMING SB_PWR Standby Power Powered Off STRIX B250F GAMING Onboard LED ASUS STRIX B250F GAMING 1-11...

  • Page 26: Internal Connectors

    GAMING STRIX B250F GAMING RGB LED Lighting 1.1.8 Internal connectors Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports HD Audio. Connect one end of the front panel audio I/O module cable to this connector. AAFP strix b250F GAMING HD-audio-compliant pin definition STRIX B250F GAMING Front panel audio connector We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. Chapter 1: Product Introduction 1-12...
  • Page 27 USB 3.0 connectors (20-1 pin USB3_12, USB3_34) These connectors allow you to connect a USB 3.0 module for additional USB 3.0 front or rear panel ports. With an installed USB 3.0 module, you can enjoy all the benefits of USB 3.0 including faster data transfer speeds of up to 5 Gb/s, faster charging time for USB-chargeable devices, optimized power efficiency, and backward compatibility with USB 2.0. USB3_12 PIN 1 USB3+5V USB3+5V IntA_P1_SSRX- IntA_P2_SSRX- IntA_P1_SSRX+ IntA_P2_SSRX+ IntA_P1_SSTX- IntA_P2_SSTX- IntA_P1_SSTX+ IntA_P2_SSTX+ IntA_P1_D- IntA_P2_D- IntA_P1_D+ IntA_P2_D+ USB3_34 strix b250F GAMING PIN 1 STRIX B250F GAMING USB3.0 connectors The USB 3.0 module is purchased separately. ASUS STRIX B250F GAMING 1-13...
  • Page 28 ROG Extension connector (18-1 pin ROG_EXT) This connector is for the Front Base and other ROG devices. strix b250F GAMING ROG_EXT STRIX B250F GAMING ROG_EXT connectors • The Front Base is purchased separately. • Visit www.asus.com for more information about the Front Base. TPM connector (14-1 pin TPM) This connector supports a Trusted Platform Module (TPM) system, which securely stores keys, digital certificates, passwords and data. A TPM system also helps enhance network security, protect digital identities, and ensures platform integrity. PIN 1 strix b250F GAMING STRIX B250F GAMING TPM connector The TPM module is purchased separately. Chapter 1: Product Introduction...
  • Page 29 USB 2.0 connector (10-1 pin USB1112) This connector is for a USB 2.0 port. Connect the USB module cable to this connector, then install the module to a slot opening at the back of the system chassis. This USB connector complies with USB 2.0 specification that supports up to 480 Mb/s connection speed. USB1112 strix b250F GAMING PIN 1 STRIX B250F GAMING USB2.0 connector DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. ASUS STRIX B250F GAMING 1-15...
  • Page 30 These are not jumpers! Do not place jumper caps on the fan connectors! • Ensure that the CPU fan cable is securely installed to the CPU fan connector. CPU_FAN CPU_OPT AIO_PUMP CHA_FAN1 CHA_FAN2 EXT_FAN strix b250F GAMING PIN 1 STRIX B250F GAMING Fan connectors • The CPU_FAN connector supports the CPU fan of maximum 1A (12 W) fan power. • The EXT_FAN connector supports 2 of 5 thermal sensor sources. • Connect the fan of your water cooling kit to the CPU_FAN connector. Chapter 1: Product Introduction 1-16...
  • Page 31 -5 Volts PIN 1 +5 Volts +5 Volts PSON# +3 Volts -12 Volts +3 Volts +3 Volts strix b250F GAMING PIN 1 STRIX B250F GAMING ATX power connectors • For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a minimum power of 350 W. • DO NOT forget to connect the 8-pin EATX12V power plug. Otherwise, the system will not boot. • We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate.

  • Page 32: System Panel Connector

    PWR_SW PIN 1 strix b250F GAMING +HDD_LED- RESET +PWR_LED- * Requires an ATX power supply STRIX B250F GAMING System panel connector • System power LED (2-pin or 3-1 pin PLED) The 2-pin or 3-1 pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin HDD_LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable...
  • Page 33 Serial port connector (10-1 pin COM) This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis. PIN 1 strix b250F GAMING STRIX B250F GAMING Serial port (COM) connector The COM module is purchased separately. Thermal sensor connector (2-pin T_SENSOR) This connector is for the thermistor cable that monitors the temperature of the devices and the critical components inside the motherboard. Connect the thermistor cable and place the sensor on the device or the motherboard’s component to detect its temperature. strix b250F GAMING T_SENSOR PIN 1 SENSOR IN STRIX B250F GAMING T_SENSOR connector...
  • Page 34 M.2 sockets (M.2_1~2) These sockets allow you to install M.2 SSD modules. M.2_1(SOCKET3) 2280 2260 2242 M.2_2(SOCKET3) strix b250F GAMING 22110 2280 2260 2242 STRIX B250F GAMING M.2(SOCKET3)s • M.2_1 socket supports SATA mode M Key design and type 2242/ 2260/ 2280 SATA storage devices. • M.2_2 socket supports PCIe 3.0 x4 M Key design and type 2242/ 2260/ 2280/ 22110 PCIe storage devices. • M.2_2 socket supports IRST (Intel ® Rapid Storage Technology). The M.2 SSD module is purchased separately. Chapter 1: Product Introduction...
  • Page 35 RGB headers (4-pin RGB_HEADER) This connector is for RGB LED strips. RGB_HEADER PIN 1 +12V G R B strix b250F GAMING STRIX B250F GAMING RGB_HEADER connector The RGB header supports 5050 RGB multi-color LED strips (12V/G/R/B), with a maximum power rating of 2A (12V), and no longer than 2 m. Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. • Actual lighting and color will vary with LED strip. • If your LED strip does not light up, check if the RGB LED extension cable and the RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up when the system is operating. • The LED strips are purchased separately. ASUS STRIX B250F GAMING 1-21...
  • Page 36 Chapter 1: Product Introduction 1-22...

  • Page 37: Chapter 2: Basic Installation

    2.1.1 Motherboard installation Install the ASUS I/O Shield to the chassis rear I/O panel. Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to the chassis’ rear I/O panel.
  • Page 38 Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis. strix b250F GAMING DO NOT overtighten the screws! Doing so can damage the motherboard. Chapter 2: Basic Installation...

  • Page 39: Cpu Installation

    Ensure that you install the correct CPU designed for LGA1151 socket only. DO NOT install a CPU designed for LGA1155 and LGA1156 sockets on the LGA1151 socket. Top of CPU Bottom of CPU Bottom of CPU ASUS STRIX B250F GAMING...
  • Page 40 Top of CPU • The CPU Installation Tool is only compatible on ASUS motherboards with a Intel ® LGA1151 socket. • Ensure that the CPU is firmly clicked into place before installing it onto the CPU socket on the motherboard. • Use the CPU Installation Tool for installing the CPU only. DO NOT damage or bend the CPU Installation Tool. • Always firmly hold both sides of the CPU Installation Tool when installing, removing, or picking up the CPU Installation Tool. • Ensure to use a soft stable surface when installing the CPU to the CPU Installation Tool to prevent CPU damage. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user.

  • Page 41: Cpu Heatsink And Fan Assembly Installation

    2.1.3 CPU heatsink and fan assembly installation Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan, if necessary. To install the CPU heatsink and fan assembly ASUS STRIX B250F GAMING...
  • Page 42 To uninstall the CPU heatsink and fan assembly Chapter 2: Basic Installation...

  • Page 43: Dimm Installation

    2.1.4 DIMM installation To remove a DIMM ASUS STRIX B250F GAMING...

  • Page 44: Atx Power Connection

    2.1.5 ATX power connection Ensure to connect the 8-pin power plug. Chapter 2: Basic Installation...

  • Page 45: Sata Device Connection

    2.1.6 SATA device connection ASUS STRIX B250F GAMING...

  • Page 46: Front I/O Connector

    2.1.7 Front I/O connector To install front panel connector To install USB 3.0 connector USB 3.0 To install USB 2.0 connector To install front panel audio connector AAFP USB 2.0 Chapter 2: Basic Installation 2-10...

  • Page 47: Expansion Card Installation

    2.1.8 Expansion card installation To install PCIe x16 cards To install PCIe x1 cards ASUS STRIX B250F GAMING 2-11...
  • Page 48 To install HYPER M.2 x4 card The SSD card is purchased separately. Chapter 2: Basic Installation 2-12...

  • Page 49: M.2 Installation

    2.1.9 M.2 installation ASUS STRIX B250F GAMING 2-13...

  • Page 50: Motherboard Rear And Audio Connections

    Motherboard rear and audio connections 2.2.1 Rear I/O connection Rear panel connectors USB 2.0 ports Optical S/PDIF Out port USB 3.1 Type-A port EA1 USB 3.0 ports DVI-D port HDMI port PS/2 keyboard/mouse combo port DisplayPort Intel LAN port (LAN1)* USB 3.1 Type-C port EC1 ®...
  • Page 51 Line Out Front Speaker Out Front Speaker Out Front Speaker Out Pink Mic In Mic In Mic In Mic In Orange – – Center/Subwoofer Center/Subwoofer Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out ASUS STRIX B250F GAMING 2-15...

  • Page 52: Audio I/O Connections

    2.2.2 Audio I/O connections Audio I/O ports Connect to Headphone and Mic Connect to Stereo Speakers Connect to 2 channel Speakers Chapter 2: Basic Installation 2-16...
  • Page 53 Connect to 4 channel Speakers Connect to 6 channel Speakers If you are using Windows 8.1/10 platform, use only the light blue audio port for Side ® Speaker Out in a 6-channel configuration. ASUS STRIX B250F GAMING 2-17...

  • Page 54: Starting Up For The First Time

    Connect to 8 channel Speakers Starting up for the first time After making all the connections, replace the system case cover. Ensure that all switches are off. Connect the power cord to the power connector at the back of the system chassis. Connect the power cord to a power outlet that is equipped with a surge protector.

  • Page 55: Turning Off The Computer

    While the system is ON, press the power button for less than four seconds to put the system on sleep mode or soft-off mode, depending on the BIOS setting. Press the power switch for more than four seconds to let the system enter the soft-off mode regardless of the BIOS setting. ASUS STRIX B250F GAMING 2-19...
  • Page 56 Chapter 2: Basic Installation 2-20...

  • Page 57: Chapter 3: Bios Setup

    BIOS Setup Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 58: Bios Setup Program

    RTC RAM via the Clear CMOS jumper. • The BIOS setup program does not support the Bluetooth devices. Please visit ASUS website for the detailed BIOS content manual. BIOS menu screen The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode.

  • Page 59: Ez Mode

    Click to go to Advanced mode Loads optimized Search on the FAQ default settings Click to display boot devices Selects the boot device priority The boot device options vary depending on the devices you installed to the system. ASUS STRIX B250F GAMING...

  • Page 60: Advanced Mode

    3.2.2 Advanced Mode The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To switch from EZ Mode to Advanced Mode, click Advanced Mode(F7) or press the <F7> hotkey.

  • Page 61: Menu Bar

    Q-Fan Control(F6) This button above the menu bar displays the current settings of your fans. Use this button to manually tweak the fans to your desired settings. Refer to section 3.2.3 QFan Control for more information. ASUS STRIX B250F GAMING...

  • Page 62: Hot Keys

    Move your mouse over this button to show a QR code, scan this QR code on your mobile device to connect to the BIOS FAQ web page of the ASUS support website. You can also scan the following QR code: Hot keys This button above the menu bar contains the navigation keys for the BIOS setup program.

  • Page 63: Qfan Control

    Click to activate DC Mode configured PWM Mode Select a profile to Click to apply the fan setting apply to your fans Click to undo the Click to go back to main menu changes Select to manually configure your fans ASUS STRIX B250F GAMING...
  • Page 64 Configuring fans manually Select Manual from the list of profiles to manually configure your fans’ operating speed. Speed points Select to manually configure your fans To configure your fans: Select the fan that you want to configure and to view its current status. Click and drag the speed points to adjust the fans’...

  • Page 65: My Favorites

    My Favorites is your personal space where you can easily save and access your favorite BIOS items. My Favorites comes with several performance, power saving, and fast boot related items by default. You can personalize this screen by adding or removing items. ASUS STRIX B250F GAMING...
  • Page 66 Adding items to My Favorites To add BIOS items: Press <F3> on your keyboard or click from the BIOS screen to open Setup Tree Map screen. On the Setup Tree Map screen, select the BIOS items that you want to save in My Favorites screen.

  • Page 67: Main Menu

    The subitems in this menu allow you to set the CPU ratio and their features. Intel(R) SpeedStep(tm) [Enabled] This item allows the operating system to dynamically adjust the processor voltage and cores frequency, resulting to a decreased average power consumption and decreased average heat production. Configuration options: [Disabled] [Enabled] ASUS STRIX B250F GAMING 3-11...

  • Page 68: Advanced Menu

    Turbo Mode Parameters Long Duration Package Power Limit [Auto] Allows you to limit the Turbo Ratio’s time duration that exceeds the TDP (Thermal Design Power) for maximum performance. Use the <+> or <-> keys to adjust the value. The values range from 1 W to 4096 W. Package Power Time Window [Auto] Also known as Power Limit 1, this item allows you to maintain the time window for Turbo Ratio over TDP (Thermal Design Power).

  • Page 69: System Agent (Sa) Configuration

    PCH-FW Configuration This item allows you to configure the firmware TPM. 3.6.7 Onboard Devices Configuration HD Audio Controller [Enabled] This item allows you to use the Azalia High Definition Audio Controller. Configuration options: [Disabled] [Enabled] ASUS STRIX B250F GAMING 3-13...

  • Page 70: Apm Configuration

    PCIEX16_2 Configuration [Auto] This item allows you to configure the PCIe x16_2 device settings. [Auto] Automatically detects the device installed. (1) When a device is installed in PCIe x1_2 or PCIEx1_3 slot, PCIe x16_2 only runs in X2 Mode. (2) When there are no devices installed in PCIe x1_2 or PCIe x1_3 slot, PCIe x16_2 can run in X4 Mode.

  • Page 71: Monitor Menu

    The following four items appear when you set Launch CSM to [Enabled]. Boot Device Control [UEFI and Legacy OPROM] Allows you to select the type of devices that you want to boot up. Configuration options: [UEFI and Legacy OPROM] [Legacy OPROM only] [UEFI only] ASUS STRIX B250F GAMING 3-15...

  • Page 72: Tool Menu

    3.9.1 ASUS EZ Flash 3 Utility This item allows you to run ASUS EZ Flash 3. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice.

  • Page 73: Asus Spd Information

    To launch Secure Erase, click Tool > Secure Erase on the Advanced mode menu. Check the ASUS support site for a full list of SSDs tested with Secure Erase. The drive may become unstable if you run Secure Erase on an incompatible SSD.

  • Page 74: Exit Menu

    3.10 Exit menu The Exit menu items allow you to load the optimal default values for the BIOS items, and save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit menu. Load Optimized Defaults This option allows you to load the default values for each of the parameters on the Setup menus.

  • Page 75: Updating Bios

    ® ASUS EZ Flash 3: Updates the BIOS using a USB flash drive. ASUS CrashFree BIOS 3: Restores the BIOS using the motherboard support DVD or a USB flash drive when the BIOS file fails or gets corrupted. 3.11.1...

  • Page 76: Asus Ez Flash 3

    3.11.2 ASUS EZ Flash 3 ASUS EZ Flash 3 allows you to download and update to the latest BIOS through the Internet without having to use a bootable floppy disk or an OS-based utility. Updating through the Internet varies per region and Internet conditions. Check your local Internet connection before updating through the Internet.
  • Page 77 To update the BIOS by Internet: Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select ASUS EZ Flash Utility and press <Enter>. Select via Internet. Press the Left/Right arrow keys to select an Internet connection method, and then press <Enter>.

  • Page 78: Asus Crashfree Bios 3

    The BIOS file in the motherboard support DVD may be older than the BIOS file published on the ASUS official website. If you want to use the newer BIOS file, download the file at https://www.asus.com/support/ and save it to a USB flash drive.

  • Page 79: Appendix

    Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. ASUS STRIX B250F GAMING...

  • Page 80: Canadian Department Of Communications Statement

    IC: Canadian Compliance Statement Complies with the Canadian ICES-003 Class B specifications. This device complies with RSS 210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations. This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 81 ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
  • Page 82 доступний на: www.asus.com/support Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support Türkçe AsusTek Computer Inc., bu aygıtın temel gereksinimlerle ve ilişkili Čeština Společnost ASUSTeK Computer Inc. tímto prohlašuje, že toto Yönergelerin diğer ilgili koşullarıyla uyumlu olduğunu beyan eder.

  • Page 83: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site http://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support http://qr.asus.com/techserv ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555 Support Fax...

  • Page 84: Declaration Of Conformity

    800 Corporate Way, Fremont Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name : Motherboard Model Number : STRIX B250F GAMING Conforms to the following specifications: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
