Symbologies Defaulted On; Symbologies Defaulted Off; Reading Ranges; Software Development Kit (Sdk) - Code CR4300 User Manual

10.0 - Symbologies Defaulted On

The following are symbologies are defaulted ON. Symbology
settings are controlled by the FlexTest SDK.
Aztec Data Matrix Rectangle
Codabar
All GS1 DataBar
Code 39
Interleaved 2 of 5
Code 93
MSI Plessey
Code 128
PDF417
Data Matrix
QR Code
UPC/EAN/JAN

12.0 - Reading Ranges

Test Barcode
7.5 mil Code 39
13 mil UPC
5 mil Data Matrix
6.7 mil Data Matrix
10 mil Data Matrix
15 mil QR Code
20.8 mil Data Matrix
Note: All samples were high quality barcodes and were read along a physical center line at a 10° angle. Default AGC settings were used.
Accuracy= +/- 10%.

13.0 - Software Development Kit (SDK)

Code provides an SDK for incorporating barcode reading into your iOS applications. The SDK provides a sample application, FlexTest, which
can be compiled in your environment to demonstrate the functionality of a CR4300. The SDK is available on Code's website.
D027635_02 CR4300 User Manual

11.0 - Symbologies Defaulted Off

The following are symbologies are defaulted OFF. Symbology
settings are controlled by the FlexTest SDK.
Code 11
Code 32
Composite
Han Xin Code
Hong Kong 2 of 5
IATA 2 of 5
CR4300 Performance
Min Inches (mm)
3.1" (80 mm)
2.4" (60 mm)
2.4" (60 mm)
2.2" (55 mm)
2.0" (50 mm)
1.6" (40 mm)
1.6" (40 mm)
Maxicode Standard 2 of 5
Matrix 2 of 5 Telepen
Micro PDF417 Trioptic
MSI Plessey Postal Codes
NEC 2 of 5
Plessey
Max Inches (mm)
9.4" (240 mm)
19.7" (500 mm)
4.9" (125 mm)
9.8" (250 mm)
10.4" (265 mm)
17.3" (440 mm)
17.7" (450 mm)
9
