Understanding the Primary Flight Controls

If you are not familiar with the controls of your drone, take a few minutes to familiarize yourself with them before
attempting your first flight.
Throttle
Throttle up
Rudder
Rudder left
Elevator
Elevator down/
Forward
Aileron
Aileron left

Flight Rate Selection

The Vizo camera drone has 3 available flight rates. Press RATE+ button to increase the flight rate from Easy to
Intermediate to Pro. Press the RATE– button to decrease the flight rate from Pro to Intermediate to Easy. The transmitter
beeps, indicating the active flight rate.
• Easy Rate = 1 beep. This rate limits the possible speed
and control sensitivity of the drone. This allows beginner
pilots to get used to the flight controls with less chance
of over-controlling.
Climb
Nose
Yaws Left
Left Side View
Forward
Rear View
Left
Throttle down
Rudder right
Elevator up/
Backward
Aileron right
• Intermediate Rate = 2 beeps. This rate increases the
possible flight speed and sensitivity of the drone.
• 3D Rate = 3 beeps. This rate allows for maximum flight
speed and manueverability and is recommended for more
experienced pilots.
6
Descend
Nose
Yaws Right
Left Side View
Backward
Rear View
Right
