Fig. 2. Dark dot defect description
【two adjacent】
Fig. 3. Minimum distance between dot defects
【dark dot - to - dark dot】
5 mm
Good
【bright dot - to - bright dot】
15 mm
Good
【bright dot - to - bright dot】
(Good)
(N. G)
4.9mm
N. G
14.9 mm
5-7
N. G
