Aputure V-SCREEN VS-1 User Manual page 5

Aputura
3) Fix
the sunshade cover
Fix the sunshade cover
on
the V-Screen with the tape
as
shown
by
the picture.
ilE
Using PowerAdapter
To
power
by
adapter, connect the
DC
Adapter
to
the DC lnput
on the back of
V-Screen
Lithium Battery lnstallation
lnsert lithium batlery
into the battery slot
as
shown
below.
EE!
Note:
1.
Lithium
batteries should
be
purchased separately. You
can use: Sony F97OlF550/
NP-FM5OOH.
2.
There's no
need to remove the batteries when powered by adapter. DC power
will
charge
the batteries andbattery
powerwill
be
displayed
in the top left comer
of
the screen.
VS:N
Power Switch
Swltch
on
the V-Screen
by
pressing the power switch.
To
power off,
hold the power swilch
for 2 seconds.
@
Note:
l.
Power indicator lights
red u,hen connected
E
ith power.
2.
Power indicator lights
green
u
hen tumed on.
3.
A red
battery indicator rvill blink
on rhc screen u.hen power is lorv. Replace
batteries
immediately
Signal lnput Switch
Press the <
A/V> button
to
choose appropriate signal input mode. Ex: Switch to
HD mode to
receive
HD
signal.
Enter Sleep Mode
Enters sleep mode after
30
seconds when there
is no signal. Awake unit by
pressing any button except power switch.
4.
Function
and Operation
'1.
Before setting functions, make sure device
is connected correcfly.
2. Before entering the menu, the Direction Pad
has several default functions:
<
A/V
> =
brightness adjustment;
<<
/>>
=
contrast adjustment.
@
Note:
Refer to
P9
to
set
shortcuts
as
needed.
3. Press
<M> on
lhe V-Screen
to enter the menu. Press <
a/v
> to choose from
the main menu, including display, menu, function, and shortcut settings. Then
press
< > > to
enter sub-menu. Press
<
a
/V > to navigate the sub-menu,
and
<
<
/
> > to adjust parameters. Press
<M> to confirm and return to the
main
menu.
Press once
more to exit the menu.
ELI
Note:
1.
V-Screen
will
exit
menu when no operation
for
5
seconds.
2.
Referto
P8
to adjust the display time.
