BFT CLONIX 4 RTE Installation And User Manual page 5

FIG.1
A
B
C
T
FIG.2
SW1 ----> CH1
SW2 ----> CH2
SW4 ----> CH4
A
2x
T1-->CH1
A
T2-->CH2
T3-->CH3
T4-->CH4
3x
B
4x
C
5x
N.D.
6x
Cancellation of the entire receiver memory.
EXIT
22 - CLONIX 4 RTE
The associated output relay remains picked up as long as it is receiving the command wirelessly from the
remote control.
The relay of the coupled output changes status each time the transmitter key is pressed.
Each time the transmitter key is pressed, the output relay remains picked up for the time set by means
of the dip switch (Fig.5). When the key is pressed during the count cycle, the actual count is restarted.
T
SW3 ----> CH3
ENTRY OF RADIO TRANSMITTERS
1 1 1
1 1
1 1
1
1
N.D.
1
10 sec.
SW1 SW2
A
B
C
15 s
EXIT
15 s
EXIT
15 s
EXIT
15 s
EXIT
EXIT
