9

Do you have a problem identifying an animal?

9.1

The reading distance is too short

The maximum reading distance is obtained with the transponder (tag) perpendicular to the antenna
and aimed at the centre of the antenna coil. If the tag is implanted into an animal its orientation may
not be optimal and therefore the reading distance may be reduced.
You might be close to a source of electromagnetic disturbances like video or TV. Move a few meters
away and try again.
Do not use the reader on a steel table. The metal will reduce the performance of the antenna.
The reading distance is reduced if the transponder is still in the needle.
9.2

The reader does not read the transponder

Change the angle of the reader and try again.
Some types of transponders from other manufacturers are disturbed if placed in the centre of the
reader-antenna. It is possible that some tags will not function if placed in parallel and at the centre of
the antenna. Change the direction of the tag or of the antenna.
9.3

The reader does not work

Charge the reader for at least 30 minutes and try again (recommended time for full battery recharge =
2 hours).
Check the ambient temperature: It has to be between -5ºC and +45º C.
If you're still having problems, please contact your dealer.
The ISO MAX V reader is a product developed and produced by DATAMARS SA, Switzerland.
Should you have any suggestions or require information regarding this or other DATAMARS products,
please contact your dealer.
10 Advanced user instructions

10.1 Console commands description

This section is meant to describe the console commands implemented in the ISO MAX V in order to
remote control the features and the functions of the reader.
All console commands begin with '.' or '?' and end with a carriage return character ([CR]=13 dec). The
ISO MAX V answers with a bell character ([BEL]=7 dec) followed by line feed characters ([LF]=10 dec)
if the command is wrong or not executable, while it answers with just a line feed [LF] when the
command is correct and executed. Some commands give an answer: the answer is formatted in the
following mode:
[CR][LF] "answer string" [CR][LF]
ISO MAX V Manual – v. 1.2 – july 2012
23
