- Page 1 Owner's Manual Body Worn Camera GBW-G0116X 4 Megapixel Full HD IP68 Body Worn Camera ICR IR LED GBW-G0116X.49.1.21.03.2016 © ASP AG...
-
Page 3: Table Of Contents
Content Introduction ........................5 Important Safety Instructions ..................5 Package Contents ......................6 Key features ........................6 Installation ........................7 Camera’s connectors ....................7 Camera Usage ....................... 8 Power on ........................8 Video Recording ......................8 Photo .......................... 9 Digital Zoom Function ....................9 Record Audio recording .................. - Page 4 Use the management software ................13 Software Introduction .................... 13 Operation System ....................13 Driver Installation ....................13 7.3.1 Run the Driver ....................14 7.3.2 Installation Path ....................14 7.3.3 Create a Shortcut ....................14 7.3.4 Start the Installation................... 15 7.3.5 Complete the Installation ..................
-
Page 5: Introduction
Introduction Thank you for purchasing the Grundig Body Worn camera GBW-G0116X. This Manual applies to the Grundig Camera GBW-G0116X. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. -
Page 6: Package Contents
If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (GRUNDIG is not liable for problems caused by unauthorised modifications or attempted repair.) To prevent fire or electric shock, do not expose the inside of this device to rain or moisture. -
Page 7: Installation
Installation Camera’s connectors 1) Speaker 2) Video Recording Key 3) Rotatable ON-OFF Cap 4) Reset 5) LCD Screen 6) Walkie-talkie Port/Extension port 7) Photo-key 8) Fixing Hole 9) Inter-talk key 10) Playback 11) LCD turn off key 12) Power key 13) IR LED light 14) Status Indication LED 15) Lens... -
Page 8: Camera Usage
Camera Usage Power on Press【 】 to power on the camera. After the “beep” sound, the camera will enter into preview mode automatically. The status indication LED light will turn green. (Balance space, Files quantity, Available video recording time, Battery volume) In preview mode, you will see the balance space, the files quantity, the available video recording time, and the battery volume above the LCD screen from left to right. -
Page 9: Photo
(Recording status indicator in the top left corner, the number of the camera in the bottom left of the video) Note: The number of the camera will be integrated in the video in the bottom left part of the video stream. To change this number, please use the supplied software. Check the “Use Management Software”... -
Page 10: Record Audio Recording
Record Audio recording Press the Audio Recording button 【 】to record the audio while the camera is in preview mode. A beep sound will confirm that the recording has started. Press the Audio Recording button【 】once again to stop the recording. Tfile will be saved automatically in WAV format. -
Page 11: Playback Mode
Playback mode 5.7.1 Select Playback File In preview mode, press the playback button【 】to enter the playback mode (as shown in figure 1). Press the video recording button【 】or the photo recording button 】 to select the file type. Press the playback button【 】to enter the thumbnail 【... -
Page 12: Exit The Playback Mode
playback button【 】to set the retrieval time range, and press the menu button【 】to determine the retrieval. The files that conform to the retrieval time range will have a ）logo (as shown in figure 4). （ Figure 3 Figure 4 5.7.5 Exit the Playback Mode 】or the "display off"... -
Page 13: Set The Vibration Function
5.12 Set Vibration Function Open this function in the menu. This function will enable or disable the vibration feedback when you turn on/off the camera. 5.13 Reset If you want to reset the camera, please click as shown in the figure below. Note: this operation will not cause the file data being lost or damaged. -
Page 14: Run The Driver
7.3.1 Run the Driver Insert the attached CD-ROM of the camera into the upper drive, open the CD, run the driver and install the software. Click on the "Next" button. 7.3.2 Installation Path Select the installation path. Click on the "Next" button. 7.3.3 Create Shortcut Click on the "Next"... -
Page 15: Start The Installation
7.3.4 Start the Installation Click on the "Install" button. 7.3.5 Complete the Installation The installation is complete, click on the "Finish" button to end the installation. Open the Management Software In the CD file, click on the management software and run it. Management Software Instructions The camera needs to be connected with the upper machine through the USB cable, and the management software needs to be executed. -
Page 16: Verify The Password
7.5.1 Verify the Password To access the data of the camera or change any settings, you need to login into the camera. To login, please input the password of the camera, click on the "verify password" button. After the tip of "successfully set the system time", the system time of the camera will be automatically synchronised with the upper computer's time. -
Page 17: Delete Files
7.5.3 Delete Files To delete all files on the camera, click on "delete all files", and confirm the appearing dialogue box. Select "yes" to continue the operation. Once again, select "yes" to continue this operation or select "no" to cancel this operation. A confirmation dialogue will appear after that. -
Page 18: Recording Resolution
Note: After entering the mobile disk model, the management software cannot change any camera options. If you want to change the settings, please disconnect the USB connection and reconnect again. 7.5.5 Recording Resolution Here you can set the video resolution of the camera. After selecting “2304×1296(30)”, 1920×1080(60)”, 1920×1080(30)”, “1280×720(60)”, “1280×720(30)”, “848×480(30)”, click on “Recording Resolution”. -
Page 19: Segmented Time
7.5.6 Segmented Time You can set the segmentation time that will be used for video recordings. After choosing the "5 minutes", "10 minutes", "15 minutes", "30 minutes" and "off", click on "segmented time". 7.5.7 Photo Resolution After choosing “7680X4320”, “6016X3384”, “5376X3024”, “2688X1512”, click on “Photo Resolution”. -
Page 20: Screen-Off Time
7.5.8 IR You can set the IR mode of the camera. Under manual mode, you need to activate the IR mode with the dedicated button. Under auto mode, the camera will switch automatically to BW IR mode. After choosing between "manual", or "automatic" option, click the "IR"button. 7.5.9 Screen-off Time You can set the screen-off time of the Camera. -
Page 21: Voice Prompt
7.5.10 Voice Prompt You can set an intelligent voice prompt. After selecting "on" and "off", click on the "voice prompt". 7.5.11 Unit No. You can set the unit number in the camera. This number will be implemented in the video recording. -
Page 22: Unit Name
Enter the user number and click on the "user number" button. A dialogue will appear that the unit number has been changed successfully. Note: The User No. length cannot exceed 6 digits, and can only consist of numbers or characters. 7.5.13 Unit Name You can set the unit name in the camera. -
Page 23: User Name
7.5.14 User Name You can set the user name in the camera. Enter the username and click on the "user name" button. A dialogue will appear that the unit number has been changed successfully. Note: The user name length cannot be more than 32 characters. 7.5.15 Check the Equipment Information When you click on "check the equipment information", the following information can be... -
Page 24: Battery Recharging
Battery Recharging The Battery The camera has a built-in rechargeable battery. When the battery is insufficient, the camera will inform you by playing a “beep” sound and show the corresponding icons on the screen. USB Cable Charging Use the USB cable to connect the camera with a computer. The recorder will startup automatically and enter into charging mode. -
Page 25: How To Wear The Shoulder Strap
Note: 1. You can charge the camera after the connection of the multi-functional base with the camera. 2. It is recommended to charge in the shutdown state. 3. Please charge every three months if the camera is for a long time off, in order to avoid battery failure. - Page 26 5. Put the back clip of the camera inside the regulator. 6. Turn the regulator to adjust it to the appropriate location. Wearing Method II: 1. Open the shoulder straps, insert itunder the shoulder board. 2. Reverse the upper straps. 3.
- Page 27 SPECIFICATIONS Image Sensor: 1/3.2" CMOS 4.0 Megapixel Pixels - Total: 2688 (H) x 1520 (V) Sensitivity B&W: 0 Lux LED IR on S/N Ratio: 64.6 dB Col/B&W: On/Off/Auto Lens Focal Length: 2.5 mm Minimum Object Distance: 0.5 m Viewing Angle 170°...
-
Page 28: Ec Declaration Of Conformity
EC Declaration of Conformity GBW-G0116X 4 Megapixel Full HD IP68 Body Worn Camera ICR IR LED It is hereby certified that the products meet the standards in the following relevant provisions: EC EMC Directive 2004/108/EC Low Voltage Directive 2006/95/EC Applied harmonised standards and technical specifications:...
