Pin Assignments

4-channel distributor board

First connection to CMD controller
Pin Designation
1 GND
2 GND
3 GND
4 GND
5 GND
6 + 5 V
7 + 5 V
8 + 5 V
9 + 5 V switched
10 + 5 V switched
11 + 5 V switched
12 Last - GND
13 Last - GND
14 Last - GND
15 Last - GND
16 Last - GND
17 Last - GND
18 + 24 V switched
19 + 24 V switched
20 + 24 V switched
21 + 24 V switched
22 + 24 V switched
23 + 24 V switched
24 Dispensing gear of dispensing unit 1
25 Retaining magnet of dispensing unit 1
26 Dispensing gear of dispensing unit 2
27 Retaining magnet of dispensing unit 2
28 Dispensing gear of dispensing unit 3
29 Retaining magnet of dispensing unit 3
01750060162 A Cash Media Dispenser Version 4 - Service Manual
4-channel distributor board
8-39
