Assembling

Mounting The Camera

Attach the camera mount to the camera using either of the fittings
on the top of the camera body. Damp the sucker cup with water and
place it on the window screen. Press the leaver down to secure it in
place. To release lift the leaver up and remove the mount from the
window screen.
Release
Position
Lock Position
(Please see legal requirements on page 27 before fitting)
Tilt the camera into your preferred position and tighten the locking
screw so it is finger tight. Turn the camera to pan it into the correct
position. The ratchet style mount will hold the chosen horizontal
position in place.
Please Note:
Some window screen have a coating that may not allow the suction
cup to stick.
After Sales Support
UK/N.IRELAND HELPLINE N
REP.IRELAND HELPLINE N
O
WEBSITE:
EMAIL: enquiries@quesh.co.uk
: 01270 508538
O
: 1800 995 036
www.quesh.co.uk
Place the mount
into the slot and
slide across to
lock into position.
6
