Summary of Contents for Pixel EXPERT
- Page 1 Wireless Live View Remote Control 无线图像可视快门线 261008 V10.01...
-
Page 2: Table Of Contents
Contents Overview Cautions before use Features of Expert Included items Name of each part Usage Battery Installation Turn power ON and OFF Sync Code-Matching Channel adjustment Holding Expert Transmitter Connect with the camera Switching Signal Source Enlarge and review Sleep/Wake-up mode... -
Page 3: Overview
LCD Brightness adjustment Thank you very much for purchasing PIXEL high-performance product Volume adjustment First of all, thank you for purchasing PIXEL's Expert. This is monitoring the lens view Menu or the CMOS view on transmitter. Receiver side supports single shooting, [BULB] Remote Shooting shooting and delay shooting. -
Page 4: Cautions Before Use
Features of Expert ISM 2.4GHz frequency channel which qualified CE or FCC standard. Make sure the camera and Expert are powered off before install device. Operating range up to 200M As this is an electronic product accessory; some of the environment causes may affect the Real-time monitoring surround environment view from CMOS or camera lens directly working. -
Page 5: Included Items
Included items Name of each part Expert T ransmitter Please check all included items after open the packing, and PIXEL Expert with the following items: Code matching button Expert T ransmitter 1 pc Power socket Expert Receiver Power switch 1 pc... -
Page 6: Name Of Each Part
Name of each part Name of each part Expert Receiver MENU Button CMOS and camera view button Camera connecting side Video enlarge/Review button A side Channel switch/sleep and wake-up button Status LED indicator Shutter Volume up/Up shift button Video Connecting Cable... -
Page 7: Usage
Expert Receiver: When turn on the power, the STATUS LED shows the receiver is on; the STATUS LED off after starting up, and the screen shows [PIXEL Expert] and begins to When using 1.2V 2400mA battery, standby for 100 hours, working search signal of transmitter;... -
Page 8: Sync Code-Matching
Channel adjustment Sync Code-Matching 1. Press [MENU] enters to the menu. Expert Transmitter: 2. Press the right or left button move to [SYNC] page. Directly slide the Channel Switch to the channel you need. When power on, the times STATUS LED 3. -
Page 9: Holding Expert Transmitter
Usage Usage Connect with the camera Holding Expert Transmitter Available to hold the transmitter on hot shoe, rack or tripod. Insert shutter release cable A side to transmitter shutter release 1.Hold the transmitter on the hot shoe of camera. socket, another side insert to camera shutter release socket Lock the hot shoe locknuts. -
Page 10: Switching Signal Source
Usage Usage Switching Signal Source Enlarge and review Receiver directs to convert the input signal source of transmitter. Under the CMOS mode, slightly press the Enlarge and Check button [ ] to enlarge display Press [CCTV/AV] when camera's LV mode is on and AV signal has connected to transmitter, the input function, and the Screen display effect will be magnified one times. -
Page 11: Sleep/Wake-Up Mode 1
Usage Usage Sleep/Wake-up mode Menu Under operation status, hold [CHANNEL SWITCH/WAKE UP] for two sec, and the screen will get into 1. Press [MENU] to enter the menu. sleeping mode. 2. Press [right/left] to select submenu. Press [up/down] to select items in submenu. Under sleeping mode, hold [CHANNEL SWITCH/WAKE UP] for two sec, and the screen will get into 3. -
Page 12: Remote Shooting
Usage Usage SAVE： Screen shot saving setting: Save before taking the shot (BEFORE), D R I V E S A V E S Y N C Remote Shooting Save 1.8 sec after taking the shot (AFTER), No saving (OFF). BEFORE AFTER Single Shooting: Set the receiver shutter function as single shooting (SINGLE), and set the camera shutter function as... -
Page 13: Pixel Expert Specifications
Transmitter: 62.6mm×39.2mm×166mm (W×H×D) Receiver: 12 2mm×27.9mm×73.4mm Transmitter: Weight: 88.5(without battery) Receiver: 128(without battery) Now you can start to use unique high-performance PIXEL product Expert. If you have any questions, you can contact the local distributor. Or visit the website http://www.pixelhk.com.
