POWER SUPPLY MANAGER
Power supply equipment for fire detection and fire alarm systems for buildings
Thank you for purchasing TOA's Power Supply Manager.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1134
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg, Germany
1134-CPR-137
DoP 14-001
EN 54-4: 1997/A1: 2002 + A2: 2006
VX-3000DS CE/CE-GB

OPERATING INSTRUCTIONS

VX-3000DS CE
VX-3000DS CE-GB
14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX-3000DS CE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toa VX-3000DS CE

Summary of Contents for Toa VX-3000DS CE

  • Page 1: Operating Instructions

    EN 54-4: 1997/A1: 2002 + A2: 2006 VX-3000DS CE/CE-GB Power supply equipment for fire detection and fire alarm systems for buildings Thank you for purchasing TOA’s Power Supply Manager. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. SAFETY PRECAUTIONS ................3 2. FEATURES ......................4 3. NOMENCLATURE AND FUNCTIONS ..........5 Front ..........................5 Front (with the front panel removed) ................6 Rear ..........................7 4. INSTALLATION ....................8 4.1. Installing the VX-3000DS in the Cabinet Rack ............8 4.2.

  • Page 3: Safety Precautions

    AC power plugs (AC power cords), disconnect the battery, and contact CAUTION your nearest TOA dealer. Make no further attempt to operate the unit in this condition as this may cause ire or electric shock. When Installing the Unit ·...

  • Page 4: Features

    Fix it with anchor bolts or take other arrangements high temperature and high humidity when storing to prevent it from falling down. batteries. · The supplied rack-mounting screws can be used for the TOA equipment rack only. Do not use them for other racks. 2. FEATURES • Internal dual power supply supplies DC power to individual components. • Automatically switches to the backup power supply when the AC Mains power supply is interrupted.

  • Page 5: Nomenclature And Functions

    3. NOMENCLATURE AND FUNCTIONS [Front] AC POWER BATTERY POWER CONNECT CHARGING CONDITION CHECK POWER SUPPLY MANAGER VX-3000DS 1. Power indicators [AC POWER IN1, IN2] Note Light green when AC power is supplied through the Battery check cannot function for 1 minute during of which Battery indicator (3) lashes twice, pause, AC inlets (18).

  • Page 6: Front (With The Front Panel Removed)

    [Front (with the front panel removed)] 7. DIP switch Switch 7 Sets whether the failure detection function is used for the AC Power IN2. Failure detection function disabled. OFF* : Failure detection function enabled. • Switches 1 and 2 are not used. Settings compliant with EN 54-4. Be sure to leave both switches OFF.

  • Page 7: Rear

    [Rear] View with the cover removed Protection cover 10. Functional earth terminal [SIGNAL GND] system, SX-2000 system, or VM-3000 system. • DS LINK OUT connector Hum noise may be generated when external
 C onnects to DS LINK IN connector of a daisy- equipment is connected to the unit. Connecting chained unit.
...

  • Page 8: Installation

    4. INSTALLATION 4.1. Installing the VX-3000DS in the Cabinet Rack Rack mounting screw 5 x 12 4.2. Battery Installation WARNING • Take special care to prevent the battery from being shorted by misconnection of the battery cable. If the short occurs, the unit may fail. Follow the instructions in this section for safe and secure connection. • Be sure to switch off the system power before battery connection. For the procedure, refer to p.
  • Page 9 • Insert the battery cable into the correct position in the battery terminal referring to the terminal's cross sectional diagrams below. Correct position of the cable insertion Incorrect position of the cable insertion Wrong insertion position of the cable or a forked cable insertion causes poor contact or insuficient Cable conductor connection tightness, making the cable come off to possibly cause short-circuit accident. Cable clamp • Strip the cable end long enough (30 mm ± 5 mm) to be Correct...
  • Page 10 • Use the battery connection cables as short in length and as large in diameter as possible. VX-3000DS Battery connnection terminals Cable C Cable A Cable B Battery Battery Example of wire length Cable cross Length (2 mΩ) sectional area Cable A, Cable C Cable B AWG 6 16 mm 180 cm 80 cm each 20 cm AWG 4 25 mm 280 cm...
  • Page 11 [Disconnecting the battery] Step 1. Conirm that battery power is not in use by means of the VX-3000DS' front-mounted BATTERY POWER LED, which is unlit in this case. Step 2. Loosen the VX-3000DS' BATTERY POWER IN negative terminal screw, then pull out the negative battery cable. Notes • Never remove the positive cable irst to avoid battery short-circuit that occurs if the positive cable should contact the unit chassis or equipment rack. • Insulate the exposed end of the removed cable with insulating tape to avoid shorting to the other cable.

  • Page 12: Affixing Declaration Of Compliance (En 54-4 Standard)

    (supplied with the VX-3000DS) When replacing the batteries, 4 each of fastener hooks and loops, and a thermal insulating sheet listed below are also required. Consult your nearest TOA dealer on how you can obtain them. Part code Part name...

  • Page 13: Connections

    5. CONNECTIONS 5.1. Connecting the VX-3000DS to VX-2000 System VX-2000 AUDIO LINK DATA LINK Ferrite cable clamp* DC POWER IN VX-2000SF Cat. 5 STP DS-SF LINK DC POWER IN VP-2000 series or VP-3000 series power amplifier DC POWER IN 28 V 4.8 A PA OUT (SP LINE) From VX-3000DS...

  • Page 14: Connecting The Vx-3000Ds To Sx-2000 System

    5.2. Connecting the VX-3000DS to SX-2000 System 5.2.1 When using a redundant power system* In this connection example, 2 power supply units are used. Even if one of the 2 units fails or its power supply line is broken, power is still supplied from the other unit, preventing the system from going down. * A method of connecting separate power sources to each power input or connecting the commercial power supply and backup power supply separately to each power input to prevent the system from going down when a cable is broken or power fails.
  • Page 15 5.2.2. When not using a redundant power system Required power is supplied to the system from a single power supply unit. Connect the [+] terminal of Input A to the [+] terminal of Input B, and the [–] terminal of Input A to the [–] terminal of Input B. SX-2100AO or SX-2000AO 4P removable terminal plug (The figure below shows the SX-2100AO.) (supplied with the SX-2000SM, SX-2100AI, SX-2000AO, SX-2100AO, SX-2000CI, and SX-2000CO) (DC power input terminal) (DC power input terminal) SX-2000SM SX-2100AI SX-2000CI...
  • Page 16 [Cable termination] When connecting 2 power cables to a single terminal of the removable Insulation sleeve terminal plug, use a ferrule terminal with an insulation sleeve to crimp the Contact section cables because such cable conductors could become loose. Recommended "Phoenix Contact" ferrule terminals for power supply cables Model Number AI 1,5-8 BK...

  • Page 17: Connecting The Vx-3000Ds To Vm-3000 System

    5.3. Connecting the VX-3000DS to VM-3000 System From VX-3000DS Note VM-3240VA/3360VA Remove the short bar attached at the factory. 230 V AC 220 V AC 50/60 Hz VP-2241 From DC POWER IN 28 V 4.8 A VX-3000DS PA OUT (SP LINE) PA LINK VP-200VX (–)
  • Page 18 5.3.1 Required number of VX-3000DS units in a 1-channel broadcasting system The required number of the VX-3000DS Power Supply Manager units is determined depending on the application of the system conigured with the VM-3240VA, VM-3360VA, VM-3240E, and VM-3360E (hereinafter called "VM ampliier"), and/or the VP-2241, VP-2421, VP-3304, and VP-3504 (hereinafter called "VP ampliier"). [System including VM amplifiers only] One VX-3000DS is required every 4 VM-3360VA/3360E ampliiers or 6 VM-3240VA/3240E ampliiers. No. of VM-3360VA/3360E No. of VX-3000DS units No. of VM-3240VA/3240E No.
  • Page 19 [System including one VP amplifier connected as a standby amplifier] One VX-3000DS is required every 4 VM-3360VA/3360E ampliiers or 6 VM-3240VA/3240E ampliiers. No. of VM-3360VA/3360E No. of VX-3000DS units No. of VM-3240VA/3240E No. of VX-3000DS units Below is an example showing that one VX-3000DS unit is used in a system including 4 VM ampliiers. VM-3240VA EXT. AMP INPUT VM LINK PA OUT EXT. PA LINK VP-3304 or VP-2241 DC POWER VX-3000DS PA OUT DS LINK VM-3240E DC POWER...
  • Page 20 [Required number of VX-3000DS units in a BGM/Paging system] One VX-3000DS is required every 3 VM-3360VA/3360E ampliiers or 4 VM-3240VA/3240E ampliiers. No. of VM-3360VA/3360E No. of VX-3000DS units No. of VM-3240VA/3240E No. of VX-3000DS units Below is an example showing that 2 VX-3000DS units are used in a system including 5 VM-3240VA/3240E ampliiers. No.1 VM-3240VA VX-3000DS DS LINK DC POWER EXT. AMP INPUT VM LINK PA OUT EXT. PA LINK VP-3304 or VP-2241 DC POWER Lead-acid Battery No.4...

  • Page 21: Connecting The Vx-3000Ds To Vx-3000 System

    5.4. Connecting the VX-3000DS to VX-3000 System 5.4.1. DC power output terminal connections Required power is supplied to the system from a single power supply unit. Note A redundant power system of the VX-3000DS cannot be applied to the VX-3004F, VX-3008F, and VX-3016F. Amplifier DC power input terminal 4P removable terminal plug (VX-015DA, VX-030DA, or VX-050DA...
  • Page 22 [Cable termination] When connecting 2 cables or a shielded cable to a single terminal, use a ferrule terminal with an insulation sleeve to crimp the cables because such cable conductors could become loose. Recommended ferrule terminals for signal cables Insulation sleeve (made by DINKLE ENTERPRISE) Unit: mm Contact section...

  • Page 23: Cable Usage Table

    6. CABLE USAGE TABLE [VX-3000DS] Terminal to Connect Cable Type Equipment to be Connected to Equipment Terminal Equipment Terminal Name Plug Cable Type Plug Equipment Receptacle Name Receptacle 230 V AC, 50/60 Hz AC POWER IN1,2 3P inlet Supplied cable 220 V AC, 50/60 Hz SX-2000SM, SX-2100AO, VX-2000SF, VM-3240VA, DS LINK DS LINK RJ45 (female)

  • Page 24: Switching Off System Power (Dc)

    • VX-3000DS' DS LINK Connections Connector Name RJ45 Pin No. Colour Pair Assignment Direction/Level DS LINK IN/OUT Orange/white Connection Check Orange Battery Failure Green/white Charging Circuitry Failure Output/0 – 3.3 V Blue DC Off Blue/white AC Off Green 3.3 V DC Input Input (DC)/3.3 V Brown/white Brown...

  • Page 25: Block Diagram

    8. BLOCk DIAGRAM FAN1 FAN2 Control Connector [DS LINK IN] Control Connector Fuse RESET [DS LINK OUT] Control Circuit AC 250 V SWITCH T8A H SMPS* BATTERY TEMPERATURE SENSOR IN BATTERY CONNECT Battery Connection Terminal [BATTERY AC POWER IN1 POWER IN] PFC* POWER OUT DC24 V...

  • Page 26: Appendix

    9. APPENDIX: Recommendations to the Power Supply Installation Incorrect installations of the power supply manager VX-3000DS and its related equipment as batteries can cause unnecessary fault indications. This information sheet gives you helpful hints and recommendations to avoid it. Please also take care on the battery handling hints. Battery Storage The recommended storage conditions (duration, temperature) of charged and uncharged batteries must not be...

  • Page 27: Battery Connection

    Battery Connection Clean Contacts Take care that the connection terminals are clean before connecting the cables. Clean them if necessary. Ensure that the battery cables are inserted correctly into the battery terminals of the VX-3000DS and the screws are fastened tight. Add one crown gear (toothed washer) on one side of the battery’s terminal connection.

  • Page 28: Temperature Sensor

    The temperature sensor must not be disconnected during charging of the battery because then the charging voltage becomes high causing the dangerous situations explained above. When exchanging the temperature sensor, the charging voltage of the VX-3000DS must be re-adjusted by TOA dealer. Installation In opposition to the battery, the temperature sensor reacts on ambient temperature changes, therefore it must not be exceeded to such changes.

  • Page 29: Trouble Shooting

    At least one of the fuses at DC output terminals “POWER OUT 19-33V MAX 5A” or “POWER the blown fuse with the supplied one. If the fuse blows again, OUT 19-33V MAX 25A” blown. consult your TOA dealer. Internal fuse (15 A) of the VX-3000DS blown. Consult your TOA dealer. Either or both fans do not operate.
  • Page 30 Check procedure 2: This measurement can be done with a slow voltmeter. Disconnect the VA unit’s power supply from the DC output from the VX-3000DS and connect a load of 5 - 6 Ω / 600 W to the DC output (when the current of the connected system components is known), then take care that the total current is approximately 5 A. Do not measure a too long time to avoid reducing the battery’s capacity too much.

  • Page 31: Specifications

    CAT5 STP cable (3 m) .......... 1 (with plain washer) 5 x 12 ........4 Thermal insulating sheet ........1 Power cord (2 m) ..........2 Ferrite cable clamp ..........1 Traceability Information for Europe Manufacturer: Authorized representative: TOA Electronics Europe GmbH TOA Corporation 7-2-1, Minatojima-Nakamachi, Chuo-ku, Kobe, Hyogo, Japan Suederstrasse 282, 20537 Hamburg, Germany...
  • Page 36 URL: http://www.toa.jp/ 133-02-00037-04...
