R R E E F F E E R R E E N N C C E E
T T R R A A C C K K S S 1 1 - - 3 3
A A N N A A L L O O G G - - O O U U T T P P U U T T S S
Per track CLOCK/GATE (0/5V) and CV/LFO (0...approx.5V) come out of seperate
jacks. Similar is the case with CLOCK and CV. They differ only in the expensed
voltage. That means on the CLOCK-jack is while the duration of GATE a voltage
of approx. 5V and during the breaks zero Volt. At the CV-jack while the duration
of GATE there is a voltage between 0 and 5V (determined by CV-switch and pos-
sibly RANDOM) and during the breaks zero Volt.
When CV-output is switched to LFO the according LFO-voltage between 0 and
approx.4V continuously comes out, not influenced by GATE or RANDOM.
All three Clock-outputs flow into a Clock-sum-output and a Gate-sum-output
(arranged as a stereo-plug). The signals of the three tracks are connected by
different ways. The according generation of both sum-outputs you can see in
the schedule below.
The three CV-output of the tracks are also put on an extra CV-sum-output.
Thereby one-third of the voltage of the according track is mixed on the output.
The sum-voltage ranges as well between 0 and 5 V. By means of this output dif-
ferent LFO - actions are mixable or Random can be influenced.
S S U U M M L L O O G G I I C C S S H H E E M M A A T T I I C C S S
1 2 3 CLOCK GATE
