Page 1: User Manual
VAM6800 A/D Conversion and Audio Embedder USER MANUAL... - Page 2 Product Information VAM6800 A/D Conversion and Audio Embedder Model: Version: V010002 Release Date: July 19th, 2010 Company OSEE TECHNOLOGY CO., LTD. Contact Information Address: No.22 Building, No.68 zone, Beiqing Road, Haidian District, Beijing, China 100094 Post Code: Tel: (+86) 010-62434168...
-
Page 3: Table Of Contents
Chapter 4 Specifications ..................15 Composite Video Input ........................15 Composite Video Output ........................16 Analog Audio Input .......................... 16 Warranty for osee product ................... 17 What the warranty covers: ....................... 17 What the warranty does not cover: ....................17... -
Page 4: Chapter 1 Introduction
In this manual, the analog video module and audio embedder module for VAM6800 are introduced. The modules for VAM6800 include decoder and line buffer that can remove the jitter, one analog video input, two balanced analog audio inputs and three SDI outputs with embedded audio. -
Page 5: Fcc Caution
6800N series frame can house up to 10 pieces of VAM6800 cards. Application in Multi-Standard The VAM6800 can work in both 525 and 625 standards, and auto sensing on standards can be achieved. Advance Decoding High performance is secured by adopting 12-bit decoding. -
Page 6: Module Descriptions
Module Descriptions The Front Part of the Module Figure 1-1 shows control switches and module status LEDs for VAM6800 Figure 1-1 Control Switches and Module Status LEDs for VAM6800 Table 1-1 briefly describes control switches and module status LEDs. Refer to chapter three for more information on control switches and module status LEDs. -
Page 7: Vam6800S
CHA INPUT: analog audio input of channel A CHB INPUT: analog audio input of channel B VAM6800S Figure 1-3 and Table 1-3 show the back connector for VAM6800S. Figure 1-3 VAM6800S Back Connector VAM6800 A/D Conversion and Audio Embedder - 7 -... -
Page 8: Signal Flow
The power consumption for module and the maximum power ratings that frame can sustain have to be confirmed before installing the module. In this chapter, the following topics on installation process for VAM6800 are discussed below: Unpacking the module ... -
Page 9: Maximum Power Ratings For Frame
Tab. 2-2 Packed Components Model Name Description VAM6800 VAM6800 module (1pc); back connector (1pc), and other accessories Installing the Module Static electricity may cause sensitive semiconductor out of order. Avoid installing Caution： or removing the module in the electrostatic-induced environment. -
Page 10: Making The Connections
Making the Connections Please connect signals based on Fig. 1-2. Removing the Module Follow the following steps to remove VAM6800 module: Open the front part of frame. Open the swivel handle to the full. VAM6800 A/D Conversion and Audio Embedder... -
Page 11: Setting Jumper
Install the front panel. Setting Jumper The jumper serves to set input level of analog audio. Four groups of jumpers of VAM6800 have to be set when needed. The four groups are: CH1, CH2, CH3 and CH4. Note: Shown as the following figure, follow the Table 2-3 indication to set jumpers for audio input level. -
Page 12: Chapter 3 Operation And Control
Pin 1 and 2 of JP3, JP6, JP9, JP12 16dB No jumper Figure 2-4 the board of the VAM6800 Module Chapter 3 Operation and Control Switches and Key Refer to Figure 3-1 or Table 3-1（Bank 0）or Table 3-2（Bank 1）to complete control Fig. - Page 13 -Set as default` Table 3-2 BANK B SW1 Setting UP: SW2+ Location Features Default DOWN: SW2- + BANK A Select BANK BANK A - BANK B H-phase + Increase (VAM6800S) - Decrease VAM6800 A/D Conversion and Audio Embedder - 13 -...
- Page 14 Note: *1. SETUP does not function in 625 standard *2. Hue does not function in 625 standard. *3. Set the 4, 5, 6, 7, 8, and 9 of BANK A as default. *4. Set all parameters as defaults. VAM6800 A/D Conversion and Audio Embedder - 14 -...
-
Page 15: Instructions On Led
ON: input standard is the same with the reference signal; Orange OFF: reference signal does not exist or standard mismatch with input signal. Chapter 4 Specifications The technical specifications for VAM6800 module are described on the following sections: Digital Video Input Digital Video Output ... -
Page 16: Composite Video Output
Input impedance High impedance THD+N 0.004% @ 1 kHz 0dBFS Frequency response 0±0.15dB, 20 Hz to 20 kHz S/N ratio >107 dB Note: Specifications are subject to change without notice VAM6800 A/D Conversion and Audio Embedder - 16 -... -
Page 17: Warranty For Osee Product
This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty. If there is no proof of purchase provided with a warranty claim, osee reserves the right not to honor the warranty set forth above. Therefore, labor and parts may be charged to the consumer.
