M2 Series

Damp Rate Select

Adjustable exponential type damping is available to steady the
display when measuring pulsating pressure or flow. The Smart
Manometer has a range of damping rates; 0.1, 0.2, 0.5, 1, 2, 5, 10,
or 25 seconds. Exponential damping shows approximately 70% of
a step change in pressure upon the next display update. When set
for 5 second time constant, it takes 5 seconds from the time of the
step change until the manometer displays the full value of the new
pressure.
To set the damp rate:
Keystroke
1. Follow the steps on
page 4 to put the unit in
Program Mode
2. Press the up arrow
key.
3. Press the PRGM key.
4. Press the up or down
arrow key until the
desire desired damp rate
is displayed on the
bottom line.
5. Press the PRGM key.
6. Press the down arrow
key.
7. Press the PRGM key.
www.meriam.com
page 9 of 31
Instruction Manual 9R000045-A
APR2007
Display
Top line reads
PROGRAM MODE" and
bottom line reads "UNITS
SELECT".
Bottom line reads "DAMP
RATE SELECT".
Top line reads "DAMP
RATE SELECT".
Bottom line shows damp
rate in seconds.
Top line reads
"PROGRAM MODE" and
bottom line reads "UNITS
SELECT".
Bottom line reads
"EXIT".
Returns to Measure Mode.
