M2 Series
display the correct value.
10. Press the PRGM key
until the display changes.
See note 1 at bottom of
this table.
11. Press the PRGM key.
12. Follow steps 6-8
above to enter "FT H2O".
13. Press the PRGM key.
14. Press the down arrow
key.
15. Press the PRGM key.
Note 1: If at steps 4 or 10 the "VALUE=" is the desired value,
press the up or down arrow key. This will toggle the bottom line
from the default "CHANGE?: YES" to "CHANGE?: NO". Step 5
would then jump to step 10. Step 11 would then jump to step 13.

Flow Unit Select

Smart Manometers that use differential pressure sensors can be
programmed to read out flow measurement units such as CFM or
L/min. The primary element must be a differential pressure
producing, square root type of device, such as a pitot tube, orifice
plate or venturi.
The flow constant and flow units description are programmed into
the manometer using the same keystrokes used in the User Unit
Select programming. At step 3 choose "FLOW UNIT SELECT"
instead of "USER UNIT SELECT".
www.meriam.com
page 8 of 31
Instruction Manual 9R000045-A
APR2007
Top line reads "VALUE=".
Bottom line reads "CHANGE?:
YES".
Top line reads "USER UNIT
NAME".
Bottom line reads "FT H2O".
Last letter "O" is blinking.
Top line reads "PROGRAM
MODE".
Bottom line reads "UNITS
SELECT".
Bottom line reads "EXIT".
Manometer returns to Measure
Mode. Units Display shows "FT
H2O".
