Waspper W3100VA Operation Manual

Engine driven
Hide thumbs

Advertisement

Table of Contents

Operation Manual
EN
TYP: W3100VA
Engine driven
*The picture serves for reference only and it may not represent an exact match of the device delivered

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W3100VA and is the answer not in the manual?

Questions and answers

Related Manuals for Waspper W3100VA

Summary of Contents for Waspper W3100VA

  • Page 1 Operation Manual TYP: W3100VA Engine driven *The picture serves for reference only and it may not represent an exact match of the device delivered...

  • Page 2: Table Of Contents

    INDEX Application compliant with the product design p. 1 Environmental protection ....p. 1 Safety ....... p. 1-2 Scope of delivery .

  • Page 3: Safety

    Hazard levels DANGER - Indication of an immediate danger potentially resulting in serious injuries or death. CAUTION - Indication of a potential hazardous situation that may result in light injuries. WARNING - Indication of a potential hazardous situation that may result in material damage. Safety features CAUTION - Safety features are designed to protect their users from injuries and these may not be altered in any way or even put out of order...

  • Page 4: Commissioning

    Nozzle Quick-coupler The low-pressure inlet on the pump must be fitted with the garden hose adaptor, included in the delivery. Commissioning Water supply CAUTION Avoid operating the pump without a water supply line connected and fed from the source. The water resource yield must correspond with at least 12 litres per hour, at the minimum pressure of 1 bar.

  • Page 5: Engine

    Engine MUST The engine be filled with the correct amount of engine oil supplied with the delivery before its first commissioning. The bottle with engine oil may contain larger amount than required for the particular engine type. For specifics refer to the Technical data section.

  • Page 6: Engine Maintenance

    CAUTION The starter cord recoil (engine resistance against the direction of starter cord pull) will draw your shoulder and hand towards the engine faster than you are able to release is, this may result in spraining, contusion or breakage of your limb. ENGINE SHUTDOWN Engine shutdown comprises the following steps OFF position.

  • Page 7: Engine Oil Change

    Engine oil change It is recommended to change the engine oil after use of this equipment (according to the Maintenance Schedule) Switch the engine off. Let the device cool down for a while, so its temperature drops below 50°C. This will prevent potential burns. Warm oil The engine should remain warm still.

  • Page 8: Pump

    Pump Your pump features an all-metal frame to ensure its long service life and flawless operation. The pump contains rotating parts mounted in very precise housings. It is therefore INEVITABLE that water fed into pump remains free of any mechanical contaminants. These contaminants would grind the contact surfaces inside the pump to increase the play between its internal components and reduce the output pressure.

  • Page 9: Troubleshooting

    That is why the priming hose should have the largest diameter possible and it must be the shortest possible. Follow the methods defined on page 3 to bleed to priming pipe. Use of self-priming cleaning agent The pump has a function for automatic drawing of the cleaning agent from its supply contained using vacuum.

  • Page 10: Warranty

    The position of all control and safety features illustrated in this manual corresponds with their actual positioning. This manual does not have to reflect any changes in design of control levers. Technical data Device type W3100VA Engine type Peggas 196cm3/ 3,6kw Maximum speed 3600 ot./min...
  • Page 11 List of components Top frame section - grip Pressure hose High-pressure nozzle Hose bracket High-pressure gun Engine Extension gun with quick Flexible grip locking pin Oil plugs with dipstick Air filter Exhaust Engine bracket High pressure pump Bottom section of frame with chassis...

  • Page 12: Eu Declaration Of Conformity

    Inspection reports Noise level Guaranteed noise measured level W2100HA 2569/3/2016-01 97 dB 99 dB W3000HA 2569/3/2016-02 97 dB 99 dB W3100VA 2569/3/2016-04 99 dB 101 dB W3000HB 2569/3/2016-03 100 dB 102 dB W2900HA 3282/3/2016 102 dB 104 dB Certificate issued by: Technická...
  • Page 13 Application of claims for repairs under warranty requires completion and submission of the complaint form via the manufacturer's website: www.waspper.com. The product is covered by a full warranty of 24 months for private customers (as defined by the Civil Code) and 12 months for corporate customers (as defined by the Commercial Code). The warranty period commences upon completion and submission of the complaint report via the website in case of simple defects and damages.

This manual is also suitable for:

W3000haW3000hbW2900ha
