Specifications; Ipod Compatibility - Philips AZ1330D Specifications

Docking Entertainment System

Specifications

iPod compatibility

• Compatible with: iPod, iPod mini, iPod nano, iPod
with colour display, iPod 5th Generation
Audio Playback
• Cradle playback mode: Charging iPod, Play and
Pause, Next and Previous track, Fast forward and
reverse
• Loader Type: Motorised, Tray
• Playback Media: WMA-CD, MP3-CD, CD, CD-R,
CD-RW
• Disc Playback Modes: Fast Forward/Reverse, Next/
Previous Track Search, Repeat Play, Shuffle Play
• Programmable Tracks: 20
Sound
• Output power (RMS): 2 x 4 W
• Sound System: Stereo
• Loudspeaker types: Bass Reflex Speaker System
• Sound Enhancement: Dynamic Bass Boost
• Speaker diameter: 3"
• Volume Control: rotary
Tuner/reception/transmission
• Tuner Bands: FM, MW
• Auto digital tuning
• Antenna: FM Antenna
Issue date 2012-03-26
Version: 2.2.5
12 NC: 8670 000 31636
EAN: 87 12581 34689 8
Connectivity
• Aux in
• Headphones: 3.5 mm
Convenience
• Display Type: LCD
• Backlight
• Remote Control: Multi-functional
Power
• Mains power
• Battery type: LR20
• Battery voltage: 1.5 V
• Number of batteries: 6
Accessories
• Included Accessories: Remote Control, Audio
Cable, AC Power Lead, User manual, Warranty
certificate
Dimensions
• Packaging dimensions (W x H x D):
410 x 187 x 307 mm
• Product dimensions (W x H x D):
358.4 x 140.6 x 260 mm
• Weight: 2.22 kg
• Weight incl. Packaging: 3.15 kg
•
© 2012 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
AZ1330D/05
Highlights
Play and charge your iPod
Play and charge your iPod
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep bass
experience from a compact loudspeaker box system.
It differs from a conventional loudspeaker box
system in the addition of a bass pipe that is
acoustically aligned to the woofer to optimise the
low frequency roll-off of the system. The result is
deeper controlled bass and lower distortion. The
system works by causing the air mass in the bass pipe
to vibrate like a conventional woofer. Combined
with the response of the woofer, the system extends
the overall low frequency sounds to create a
completely new dimension of deep bass.
Dynamic Bass Boost
Dynamic Bass Boost maximises your music
enjoyment by emphasising the bass content of the
music throughout the range of volume settings -
from low to high – at the touch of a button! Bottom-
end bass frequencies usually get lost when the
volume is set at a low level. To counteract this,
Dynamic Bass Boost can be switched on to boost
bass levels, so you can enjoy consistent sound even
when you turn down the volume.
Motorised CD loader
Motorised CD loader for convenient access
