1.0 Installation Overview
Please Note:
This product should only be installed by a qualifi ed electrician or
competent heating installer and should be in accordance with the
current edition of the IEEE wiring regulations.
GB
2.0 Product Specifi cation
Specifi cation
Power supply
Switching action
Unit switch rating
Battery back-up
Programme resolution
Dimensions, mm (W, H, D)
Design standard
Control Pollution Situation
Rated Impulse Voltage
Ball Pressure Test
3.0 Installation
•
Remove wallplate from unit by unscrewing the two screws on the
bottom edge of the unit.
•
From the top left hand corner of the wallplate, there must be
clearances of at least 140 mm to the right, 15mm to the left,
30mm above and 100mm below in order to mount the plug-on
module.
4
230V model
230 Vac,
±15%,
50/60 Hz
2 x SPDT internally linked, Type 1B
230 Vac, 3(1)A
24 hours minimum
± 1 minute
135 x 88 x 32
EN 60730-2-7
Degree 2
2.5 kV
75°C
24V model
24 Vac,
±15%,
50/60 Hz
24 Vac, 3(1)A
FP715SI
