Summary of Contents for Glensound ADDA 1
-
Page 1: User Guide
ADDA 1, DAC 1 & ADC 1 ANALOGUE/ DIGITAL AUDIO CONVERTERS Analogue to Digital and Digital to Analogue (ADDA), Digital to Analogue (DAC) & Analogue to Digital (ADC) audio converters. User Guide Glensound 6 Brooks Place, Maidstone Kent, UK, ME14 1HE Tel: +44 (0)1622 753662 www.glensound.co.uk... - Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to highlight that This symbol is intended to warn that there are important operating & dangerous voltages within the product are maintenance instructions in the literature present and constitute a risk of electric accompanying this unit. - Page 4 IMPORTANT: MAINS PLUG WIRING INSTRUCTIONS This Signature unit is supplied with a moulded mains plug fitted to the AC mains lead. Mains wiring colours/ connections: The Green/ Yellow or Green wire must be connected to the terminal in the plug marked ‘E’...
- Page 5 Emissions: EN55103.1 Immunity: EN55103.2 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR RoHS2 DIRECTIVE EC directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment.
-
Page 6: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and that the... -
Page 7: Table Of Contents
ADDA 1, DAC 1 & ADC 1 Analogue & Digital Audio Converters Handbook Contents Issue 1, Description Page No. Contents IMPORTANT SAFETY INSTRUCTIONS ........................3 PRODUCT WARRANTY: ..............................6 OVERVIEW ..................................9 PHYSICAL INSTALLATION ............................... 10 AUDIO BLOCK DIAGRAMS .............................. 12 EXAMPLES OF USE ................................ - Page 8 DAC Ident Tone................................20 ADC Input Level ................................21 ADC Input Source ................................ 21 ADC Clock Source ................................ 22 ADC Master Rate ................................22 ADC Sync Source ................................. 23 ADC Data Format ................................. 23 ADC Ident Tone................................24 WIRING INFORMATION ..............................25 SPECIFICATIONS ................................
-
Page 9: Overview
Signature DAC 1 is a single stereo digital to analogue audio converter. Signature ADC 1 is a single stereo analogue to digital converter. Signature ADDA 1 is a bi-directional analogue/ digital converter containing 1 x DAC 1 and 1 x ADC 1. -
Page 10: Physical Installation
PHYSICAL INSTALLATION The Glensound Signature Series have been designed to be highly versatile for installation and can be installed in 19” racks with either their front or rear panels facing the front of the rack. They can also be mounted underneath desks or work tops and can be either permananetly mounted or stood (using the supplied feet) on top of desks or worktops. - Page 11 SWAPPING RACK EARS TO ALLOW THE REAR TO BE INSTALLED AT THE FRONT OF A RACK PART No Signature Series PWR ON Keeps Working PIN 1 = GND PIN 2 = +12V (100mA) PIN 3 = -12V (100mA) 100-240V +/-12V - - - 50/60Hz 2.7 Watts First remove the 4 silver button head screws that fix the rack ears onto the front of the unit as shown in the top picture above.
-
Page 12: Audio Block Diagrams
BALANCED ANALOGUE IN AES TRANSMITTER AES3 OUT BALANCED ANALOGUE IN S/PDIF OUT S/PDIF TRANSMITTER UNBALANCED ANALOGUE IN ToSLINK OUT TosLINK TRANSMITTER To H'Phones UNBALANCED ANALOGUE IN From Analogue In From Digital In HEADPHONES Set Sample/ Bit Rate/ Fs From Analogue In From Digital In Control Data INTERNAL... -
Page 13: Examples Of Use
EXAMPLES OF USE ADC1 Radio Station Analogue to Digital Conversion Monitoring 1 x 6.36mm jack (balanced or unbalanced) ADC 1 Converter Analogue Stereo Signal From CD Player 2 x phono plugs 1 x XLR3 1 x BNC (balanced or connection unbalanced) AES Digital Output Master Clock Input... -
Page 14: Dac1 Connecting Active Monitors To A Digital System
DAC1 Connecting Active Monitors to a Digital System DAC 1 Converter Analogue Stereo Signal 2 x XLR3 (balanced or unbalanced) 1 x XLR3 Active 1 x 6.36mm jack (balanced or (balanced or Monitors unbalanced) unbalanced) AES Digital Output From Main Digital Router/Console Monitoring If a broadcast facility largely contains digital connections and you need to connect monitors to a studio, you will need a suitable analogue output. -
Page 15: User Controls & Connections
USER CONTROLS & CONNECTIONS Note: Picture & description is for the ADDA1 but facilities and control scale down to the ADC1 and the DAC1. FRONT PANEL 1. SELECT BUTTON 2. DONE BUTTON 3. UP/DOWN BUTTONS 4. H’PHONE VOLUME 5. H’PHONE SOCKET Select Button This a dual function button. -
Page 16: Headphone Volume
Headphone Volume This rotary volume control adjusts the audio output level of the headphone circuit. Turning it clockwise increases the output level and turning it anti-clockwise reduces the output level. Headphone Output Socket This 3 pole 6.35mm (1/4”) TRS (Tip Ring Sleeve) jack socket provides the physical output connection of the internal headphone amplifier. -
Page 17: Mains In
REAR PANEL 10. WORD CLOCK 8. BALANCED SYNC INPUT 6. AC Mains ANALOGUE OUT 9. UNBALANCED 7. External DC ANALOGUE OUT 11. AES3 SYNC INPUT 13. BALANCED 12. UNBALANCED ANALOGUE IN ANALOGUE IN 14. DIGITAL OUT 15. DIGITAL IN Mains In This AC input accepts a wide range power supply, suitable for use Worldwide. -
Page 18: Word Clock Sync Input
10. Word Clock Sync Input This BNC input can be connected to external word clocks to allow the output sample frequency of the analogue to digital converter to be synced with the external word clock reference frequency. 11. AES (DARS) Clock Sync Input This balanced digital audio input can be connected to external digital sources to allow the output sample frequency of the analogue to digital converter to be synced with the external source frequency. -
Page 19: Menu & Setting Options
MENU & SETTING OPTIONS Note: Options are described for the ADDA1 but facilities and control scale down to the ADC1 and the DAC1. ENTERING SETUP To enter setup press and hold the yellow ‘SELECT’ switch for about 5 seconds. MOVING BETWEEN MENUS There are 11 different menus whose parameters can be set. -
Page 20: Dac Input Source
DAC Input Source This sets the digital audio input that is fed into the internal D/A converter. There are 3 options: A) Bal XLR (the AES3 input via balanced XLR) (Max input frequency 192K) B) Unbal Phono (The S/PDIF input on RCA Phono) (Max input frequency 192K) C) Optical (The Toslink optical input) (Max input frequency 96K) DAC De-emphasis If your digital audio source was originally mastered with pre-emphasis (normally the high... -
Page 21: Adc Input Level
ADC Input Level This sets the full scale (0dBFS) digital output level in reference to analogue input level. There are 4 options of 0dBFS equalling: E) +18dBu F) +12dBu G) +6dBu H) 0dBu ADC Input Source This sets which analogue input source is routed to the AD converter. There are 2 choices: A) Bal XLR (The stereo balanced XLR inputs) B) Unbal Phono (The stereo unbalanced RCA Phono inputs) Page 21 of 27... -
Page 22: Adc Clock Source
ADC Clock Source This control sets what clock source is used as a reference for the ADC. The digital output will be locked to the selected source. There are 4 options. A) Master (The internal clock is used as the reference) B) Slave (The external Sync (Word Clock, AES Sync or DAC input) is used as the reference) C) Auto (If an external clock is present then this is used as the reference, if not then the internal clock is used (The frequency of the internal clock can be different to that of the... -
Page 23: Adc Sync Source
ADC Sync Source This sets which of the 3 possible external reference clock sources the device should use. AES Sync (The balanced AES input (DARS)) BNC Wordclock (the wordclock input on the BNC conector) DAC Input (the digital input that is the source of the DAC) ADC Data Format This allows the digital output type of the ADC to be set. -
Page 24: Adc Ident Tone
ADC Ident Tone Turning on the ADC Ident tone (enabling it) adds a 1kHz tone @ 0dBu to the digital output. This can be useful for fault finding. Page 24 of 27... -
Page 25: Wiring Information
WIRING INFORMATION STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth XLR SOCKET (FEMALE) 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - XLR PLUG (MALE) UNBALANCED RCA PHONO CONTACT: Signal CONTACT SLEEVE: Common/ Earth SLEEVE RCA PHONO PLUG (MALE) Page 25 of 27... - Page 26 EXTERNAL DC INPUT: PIN 1: GND PIN 2: +12V PIN 3: -12V 4 PIN XLR PLUG (MALE) STANDARD HEADPHONE WIRING: RING TIP: A/ LEFT Ear RING: B/ RIGHT Ear SLEEVE SLEEVE: Common/ Earth Page 26 of 27...
-
Page 27: Specifications
SPECIFICATIONS AUDIO INPUTS - ANALOGUE 0dBFs Equivalents +18dBu, +12dBu, +6dBu, 0dBu Maximum Input Level Noise +24dBu -108dBFs Input Impedance Frequency Response 20k ohm balanced, 10k ohm unbalanced >-0.5dB 15Hz to 20kHz Balanced Input Type THD+Noise (ref +8dBu) Sophisticated electronically balanced - 100Hz = 0.008% (can be wired unbalanced) on 2 x Neutrik - 1kHz = 0.006%...
