Dittmann IHG 375 Instructions For Use Manual

Ultrasonic inhaler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Inhaler IHG 375
•
Ultrasound Inhaler IHG 375
•
Micro-fine atomisation of the inhalation solution by a
special misting technology
•
Application possible in various positions
•
Portable device, in a handy size for inhaling medication
during the day
•
Noiseless operation
•
Easily handled with a one-button function
•
Device is easily cleaned
•
Battery-operated with 2 x AA batteries
•
Mains-operated, possible with a 230 V / 3 V DC adapter
(not included)
•
24-month warranty
•
Contents: 1 Inhaler IHG 375, 1 flexible mask for adults,
1 flexible mask for children, 1 mouthpiece, 1 connecting
piece, 1 storage bag, 1 Instructions for Use, 2 x 1.5 V AA-
batteries
0123
Version 1, 2013-04

Instructions for Use

GB
IHG 375
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IHG 375 and is the answer not in the manual?

Questions and answers

Related Manuals for Dittmann IHG 375

Summary of Contents for Dittmann IHG 375

  • Page 1: Instructions For Use

    (not included) • 24-month warranty • Contents: 1 Inhaler IHG 375, 1 flexible mask for adults, 1 flexible mask for children, 1 mouthpiece, 1 connecting piece, 1 storage bag, 1 Instructions for Use, 2 x 1.5 V AA- batteries 0123...

  • Page 2: Table Of Contents

    What are the properties of the Inhaler IHG 375? Information about the application of the Inhaler IHG 375 Safety Instructions General Safety Instructions For which usage / environment is the Inhaler IHG 375 suitable? For which usage / environment is the Inhaler IHG 375 not suitable?

  • Page 3: No. Subject Page

    CONTENTS No. Subject Page 14.0 Cleaning and Disinfecting the Inhaler IHG 375 and the Accessories 14.1 Cleaning the Inhaler and its Accessories 14.2 Disinfecting the Inhaler and its Accessories 15.0 Technical Malfunctions, Rectifying Problems 16.0 Information regarding electromagnetic immunity 17.0 Technical Data, Symbols, Pictograms 18.0...

  • Page 4: What Do The Symbols Mean

    Basic Information What are the properties of the Inhaler IHG 375? The Inhaler IHG 375 is an inhaling device for atomising liquid medicines and other medical remedies. By being atomised, medication and medical remedies approved for the inhalation therapy can be absorbed by the respiratory tract in form of aerosols.

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS 3.0 Safety Instructions General Safety Instructions 3.1.1 In case of a malfunction the inhaler must not be used, dismantled, repaired by yourself or modified (changed). Damage can be caused by using the inhaler incorrectly. 3.1.2 Should irregularities become apparent at the inhaler, stop using the device at once and consult your doctor.

  • Page 6: For Which Usage / Environment Is The Inhaler Ihg 375 Suitable

    SAFETY INSTRUCTIONS For which usage / environment is the Inhaler IHG 375 suitable? Use the inhaler exclusively for the intended purpose: for inhaling suitable liquid 3.3.1 medicines and other medical remedies via the respiratory tract of a person. Any other use is considered to be improper and may lead to damages or even compromise your health.

  • Page 7: For Which Application Area Is The Inhaler Ihg 375 Suitable

    Essential medicinal plant oils, gargle solutions, liquids and solutions for rubbing in, or for steam baths must not be used in connection with the Inhaler IHG 375; these are too viscous and cannot be atomised. They may also damage the device.

  • Page 8: Advice On The Application Of The Inhaler Ihg 375

    SAFETY INSTRUCTIONS Advice on the application of the Inhaler IHG 375 3.8.1 Before using the device take care that the components and accessories (e.g. mouthpiece and mask) have been assembled in accordance with these instructions for use (see Page 14 -15).

  • Page 9: Which Medicines Are Not Suitable For Inhalation

    Remove the batteries from the device, if it is not used for a longer period of time. 4.2.4 In case the inhaler IHG 375 is used commercially a safety-technical inspection becomes necessary in compliance with § 6 MPBetreibV (Medical Devices Operator Ordinance) every 24 months.

  • Page 10: Operation With A Power Supply Unit 3 V / Dc (Optional)

    Operation with a Power Supply Unit 3 V / DC (optional) The Inhaler IHG 375 can also be operated with a suitable AC/DC power supply unit with a voltage of 3 Volt and 1.0 A (Ampere). Before connecting...

  • Page 11: Delivery Extent / Contents Of Box

    Please check that all parts have been delivered upon unpacking the parts and also check for damages. Do not use the device in case of any apparent damage, or if the instructions for use are missing! 1 x Inhaler IHG 375 1 x Instructions for Use 1 x Mask for Adults...

  • Page 12: Disposing Of The Inhaler Ihg 375

    Insert the 2 x 1.5 V AA batteries into the device by observing the correct polarities (+ and - Pole). Types of batteries: For the Inhaler IHG 375 you require 2 AA batteries. Do not use rechargeable batteries! Fig. 1 Fig.

  • Page 13: Designations / Functions Of The Inhaler Ihg 375

    FUNCTIONS OF THE DEVICE 8.0 Designations / Functions of the Inhaler IHG 375 Atomiser Unit Medication Container Container Cover with Locking Atomiser Head with Metal Mesh Contacts/Electrodes for the Atomiser Unit Basic Unit/Basic Casing of the Inhaler LED (green) indicating the operational readiness...

  • Page 14: Starting To Use The Inhaler Ihg 375

    START-UP 9.0 Starting to use the Inhaler IHG 375 Step 1 Fig. 3 Take the basic unit in one hand and the atomiser unit the other hand and slide the atomiser unit onto the basic unit in the direction of the arrow, according to Fig. 3.

  • Page 15: Using The Mouthpiece

    APPLICATION 10.0 Using the Mouthpiece The mouthpiece included in the delivery extent is used for Fig. 9 inhaling atomised liquid medicines (aerosols) through the mouth resp. the mouth and pharynx. Step 1 Install the mouthpiece by placing it in the direction of the arrow on the connecting piece of the atomiser cover , as shown in Fig.

  • Page 16: Advice On How To Use The Inhaler

    APPLICATION 12.0 Advice on how to use the Inhaler Exchange defective or worn parts (e.g. masks, mouthpieces, connecting pieces) only for original parts. Use the mouthpiece such that the inhaled aerosol is not sprayed onto the tongue. Do not swallow the inhaled aerosol and take care that the aerosol reaches the places in the respiratory tract that are the cause of the complaints.

  • Page 17: Measures To Be Taken After Having Used The Inhaler

    APPLICATION 13.0 Measures to be taken after having used the inhaler Always switch the device off with the ON/OFF switch after an application. When using the device with the power supply unit (optional), always remove this from the device and from the 230 V power supply after application. Remove the mouthpiece resp.

  • Page 18: Cleaning And Disinfecting The Inhaler Ihg 375 And The Accessories

    CLEANING AND DISINFECTION 14.0 Cleaning and Disinfecting the Inhaler IHG 375 and the Accessories WARNING: Danger of infection through viruses, bacteria and germs! Infections can transmit life-threatening diseases! The device must be cleaned and disinfected after every application. By adhering to these measures the risk of infection can be minimised.

  • Page 19: Technical Malfunctions, Rectifying Problems

    TECHNICAL MALFUNCTIONS 15.0 Technical Malfunctions, Rectifying Problems Malfunction Cause Solution The device only generates The yellow LED display Replace the batteries with very little atomised spray. low batteries lights up. new ones. Observe the correct polarity! The atomiser unit is Clean the atomiser unit contaminated.

  • Page 20: Information Regarding Electromagnetic Immunity

    Guidelines and manufacturer's declaration – electromagnetic emissions The model IHG 375 is intended for use in an environment as specified below. The customer or the user of the model IHG 375 should ensure that it is used in such an environment.
  • Page 21 The model IHG 375 is intended for operation in an electromagnetic environment as specified below. The customer or the user of the model IHG 375 should ensure that it is used in such an environment. Immunity tests IEC 60601 –...
  • Page 22 16.0 Information regarding electromagnetic immunity Guidelines and manufacturer's declaration – electromagnetic immunity The model IHG 375 is intended for operation in an electromagnetic environment as specified below. The customer or the user of the model should ensure that it is used in such an environment.
  • Page 23 IHG 375 must be observed at every application site. If unusual performance characteristics are observed, additional measures might have to be taken, such as reorientation or relocation of the model IHG 375. b. Not applicable above the frequency range from 150 kHz to 80 Mhz.

  • Page 24: Technical Data, Symbols, Pictograms

    V1513IHG375 Serial No. 00001 (consecutive number) Date of Manufacture: 2013-04 (year, month) 2013-04 The Inhaler IHG 375 has been certified in compliance with 0123 EU-Guideline 93/42 EWG for medical products. Manufacturer: Handelshaus Dittmann GmbH, Kissinger Straße 68, D-97727 Fuchsstadt/Germany Protection against electric shock acc. to Type BF (Body Float).

  • Page 25: Warranty

    WARRANTY 18.0 Warranty The Inhaler IHG 375 purchased by you was developed and manufactured with the utmost care. The legal warranty period is 24 months from the date of purchase for material- and manufacturing errors of the product. Please keep the receipt as evidence of having purchased the Inhaler IHG 375, in case of any warranty claims.
