Backache Belt RGT 284
INSTRUCTION MANUAL
Version 1, 2011-09
PJN056-11_GA-GB_RGT284_ 26.09.11
Dienstag, 27. September 2011 21:51:41
•
3 in 1, for pain, hot and cold
application on your back
•
Universal size for waist circumferences
from approx. 75 to 125 cm
•
Individually adjustable with 2 large
velcro fasteners
•
For all TENS devices with 2 mm plug diameter
•
With 2 cold/hot compresses
•
Gel compresses individually removable
•
4 electrodes, can be wetted with water,
2 electrodes each can be addressed
with one channel of the TENS device
•
Content:
1 backache belt with 4 electrodes
2 cold/hot compresses, diameter approx. 11 cm
•
Incl. instruction manual
•
24 months warranty
GB
RGT 284
1
100
95
75
25
5
0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dittmann RGT 284
Summary of Contents for Dittmann RGT 284
- Page 1 Backache Belt RGT 284 INSTRUCTION MANUAL • 3 in 1, for pain, hot and cold application on your back • Universal size for waist circumferences from approx. 75 to 125 cm • Individually adjustable with 2 large velcro fasteners •...
-
Page 2: Table Of Contents
TABLE OF CONTENTS No. Subject Page What do the symbols mean? Basic information What does TENS mean? Information on TENS use Information on cold and hot treatment Safety instructions General safety instructions For which application range/environment is the backache belt suited? For which application range/environment is the backache belt not suited? For which application range is the backache belt suited? For which application range is the backache belt not suited? -
Page 3: What Do The Symbols Mean
BASIC INFORMATION What do the symbols mean? The safety symbols shown in this manual are instructions concerning the proper handling of the backache belt and your personal safety. The symbols have the following meaning: Read and observe the instruction manual! Warning/Danger: Danger of serious injury/damage in case of improper handling! You must observe these instructions under all circumstances! -
Page 4: Safety Instructions
You may not use any other accessories of other devices. Observe the operating instructions of the manufacturer of your TENS device when connecting the backache belt RGT 284 to this. 3.1.9 Do not place any heavy or sharp-edged objects onto the backache belt or the cold/hot compresses. -
Page 5: For Which Application Range/Environment Is The Backache Belt Suited
SAFETY INSTRUCTIONS 3.2.6 Avoid excessively high pressure during a hot or cold treatment to prevent bad circulation and/or congestion. Adjust the pressure of the backache belt in such a way that the pressure sensation is pleasant. Excessively high pressure constricts the blood vessels and nerves, which may lead to irreparable tissue damage and loss of limbs. -
Page 6: For Which Application Range Is The Backache Belt Suited
SAFETY INSTRUCTIONS 3.5 ..For which application range is the backache belt suited? 3.5.1 TENS devices only treat symptoms. They cannot heal them. In case of questions concerning your therapy, contact your physician. 3.6 ..For which application range is the backache belt not suited? 3.6.1 In case of the following circumstances you may not use the backache belt: a) -
Page 7: Use By Children And Youths
SAFETY INSTRUCTIONS Use by children and youths 3.7.1 Children may not be treated with this backache belt. Keep the backache belt away from children and youths below the age of 18. 3.7.2 Use of the backache belt 3.8.1 The backache belt may only be connected to stimulators with a 2 mm plug. Make sure that the device/stimulator is turned off when attaching or removing the backache belt. -
Page 8: Where May The Backache Belt Not Be Used
The connection cables as well as the backache belt may not be bent. 4.1.4 In case of commercial or business use of the backache belt RGT 284, a safety check has to be performed every 24 months in line with § 6 MPBetreibV. -
Page 9: Delivery Scope/Package Contents
SCOPE OF DELIVERY Scope of delivery/Package content 2 x cold/hot compresses 1 x Backache belt 1 x Instruction manual Design of the backache belt B. Connection sockets 1 A. 4 electrodes E. Outer velcro fastener D. Inner velcro fastener C. Connection sockets 2 F. -
Page 10: Putting On And Using The Backache Belt
APPLICATION Applying and using the backache belt Application with a stimulation device (TENS) Step 1: B: Outer For TENS application, you must first wet the 4 electrodes velcro fastener (see fig. A, page 9) with a bit of water. Best use a damp cloth. -
Page 11: Hot Treatment With The Backache Belt
COLD/HOT TREATMENT Hot treatment with the backache belt 7.0.1 Never heat the gel compresses unattended! Check the temperature with the back of your hand or lower arm prior to use to avoid skin burns. 7.0.2 Never place the gel compresses directly on the skin; always insert them into the side compartments of the backache belt. -
Page 12: Technical Data/Symbols
TECHNICAL DATA/SYMBOLS 8.0 Technical data, symbols Model/Type: Backache Belt RGT 284 Electrode surface: Diameter: 4 x approx. 70 x 80 mm Max. pulse voltage (V): Up to 130 Volt at a load of 500 Ohm per channel Max. frequency (Hz): Up to max. -
Page 13: Warranty
Telephone hotline: 0180-5012678 (0.14 €/min. from German landlines; max. 0.42 € per minute from German mobile phones) www.dittmann-gmbh.com With best regards Manufacturer: Handelshaus Dittmann GmbH Kissinger Straße 68 D-97727 Fuchsstadt/Germany Copyright © Handelshaus Dittmann GmbH, 2011 3905611-Technical Documentation by www.dittmann-consulting.com PJN056-11_GA-GB_RGT284_ 26.09.11 Dienstag, 27. September 2011 21:51:43...
