  • Page 1 36W “TMB” 36W Amplifier User’s Manual...

  • Page 2: Table Of Contents

    Plexi-inspired channel with full Treble, Middle, Bass tonestack and dedicated Master Volume. The power section is also beefed up with a quad of EL84s and a GZ34/5AR4 rectifier Most of all, we hope the 36W TMB becomes an integral part of your tone equation to exhilarate your playing and music. Rock on!

  • Page 3: Quick Setup

    2) QUICK SETUP (for instant gratification) 1) Plug your guitar using a 1/4” instrument cable into the upper I input on the right of the front panel 2) Plug a suitable power cable from the amp’s rear panel MAINS cable inlet to your wall power receptacle 3) Plug the amp into your speaker cabinet using 1/4”...

  • Page 4: Front Panel Controls

    3) FRONT PANEL CONTROLS From left to right: 1) POWER 2-way toggle switch 2) STANDBY 2-way toggle switch 3) INDICATOR LED 4) BASS control 5) MIDDLE control 6) TREBLE control 7) VOLUME control 8) MASTER VOLUME control 9) INPUT input ¼” instrument jacks 10) TONE control 11) VOLUME control 12) INPUT I and II input ¼”...
  • Page 5 MASTER VOLUME sets the overall volume level of the TMB channel of the amp. INPUT ¼” jack for instrument cables. Plug your guitar in here for the TMB Channel. The UPPER input is higher gain, whereas the LOWER input is lower gain.

  • Page 6: Rear Panel Controls

    4) REAR PANEL CONTROLS From left to right: 1) NEGATIVE FEEDBACK 2-way toggle switch 2) OUTPUT IMPEDANCE ¼” speaker jacks (x3) 3) POWER 2-way toggle switch 4) MAINS FUSE 5) MAINS IEC cable inlet NEGATIVE FEEDBACK toggle switch adds or defeats negative feedback in the power amplifier. UP engages negative feedback, which will tighten the response of the amp and decrease breakup and harmonic content.
  • Page 7 MAINS FUSE slow-blow fuse – used to protect your amplifier from voltage spikes or excessive current draw. Replace only when necessary with 2A Slo-Blo MAINS IEC cable inlet – plug a suitable IEC power cable into this inlet to power your amplifier...

  • Page 8: Tube Compliment And Bias Adjustment

    5) TUBE COMPLIMENT AND BIAS ADJUSTMENT From left to right: V1 – 12AX7/ECC83 (Input stage Normal and TMB channel) V2 – 12AX7/ECC83 (phase inverter) V3 – 12AX7/ECC83 (TMB Stage 2 and cathode follower) V4-7 – EL84 V8 – GZ34/5AR4 Amplifier is cathode-biased and requires NO BIAS ADJUSTMENT when installing new power tubes!

  • Page 9: Frequently Asked Questions

    6) FREQUENTLY ASKED QUESTIONS How do I hook up this thing? - See Section 2, beginning on page 3. Can I substitute different tube types? - Although you can try 12AT7s, 12AU7s, 5751s without any harm, the design is optimized for 12AX7s, and are therefore the only recommended tube in the preamp positions.

  • Page 10: Settings Templates

    7) SETTINGS TEMPLATES...
