Summary of Contents for Conbrov DV9
- Page 1 DV9 Book Hidden Camera User Manual Model No.: DV9...
-
Page 2: Table Of Contents
Safety precautions............4 Warning on invasion of privacy........5 What’s Included............6 DV9 Diagram..............7 Before Using Your Conbrov DV9 Camera....8-11 How to Use Your Conbrov DV9 Camera.....12-14 1.Turning the Camera On/Off........12 2.How to Record a Video ........12-13 3.How to Record with Sound........14 4.How to Switch Into Night Vision ......14... -
Page 3: Part1 Before First Use
Part1 Before First Use Charging the camera Before the first use, charge the camera for about three to four hours via your PC or USB charger (we recommend using the "5V/1A" power adapter) Yellow indicator Yellow indicator Formatting the microSD card Before the first use, format the microSD card to FAT32 format (applicable to Windows system ONLY). - Page 4 Part1: Before First Use Resetting the camera If the camera malfunctions for any reason, reset it with the included pin. A small paperclip can also be used.
-
Page 5: Part 2 Quick Guide
Part 2 Quick Guide A.Install the microSD Card B.Turn On/Off ON lights up blue OFF flashes and the camera is alternating red in standby mode and blue and then turns off D.Play The Video C.Record A Video 2S power on Record a Video USB2.0 flash 3 times blue... -
Page 6: Part 3 Detailed User Manual
Safety precautions Read this instruction manual carefully before using the camera. It contains important information for your safety as well as operating and maintenance instructions. Follow all safety precautions in order to prevent damage due to improper use of the camera. Keep this user manual carefully for future use. -
Page 7: Warning On Invasion Of Privacy
Warning on invasion of privacy The camera should be used for legal purpose only. Follow the laws of your country. Recording and circulating an image of an individual may constitute an infringement of their privacy for which you could be liable. Ask for authorization before filming individuals, particularly if you want to keep your recordings and/or circulate images on the Internet or any other medium. -
Page 8: What's Included
What's included DV9 Book Hidden Camera User Manual Model No.: DV9 Camera USB cable User manual Waring sticker Card reader... -
Page 9: Dv9 Diagram
DV9 Diagram Camera Lens (75 Camera Angle) 60 PIR Detection Angle... -
Page 10: Before Using Your Conbrov Dv9 Camera
Before Using Your Conbrov DV9 Camera 1. Charging your camera Yellow indicator Steady yellow Charging Fully charged Low power Flashing blue and red (1) Make sure the camera is OFF before charging. (2) Plug the USB cable both in the camera and in a computer USB port or a 5V/1A adapter (not included). - Page 11 Before Using Your Conbrov DV9 Camera Caution! Format the microSD before using. Doing this, however, will remove all data from the card. Make sure to back up data before formatting (applicable to Windows system ONLY). (1) The device supports a Class 10 microSD card which has capacity of more than 8GB and up to 32GB.
-
Page 12: Setting The Date And Time
Before Using Your Conbrov DV9 Camera 3.Setting the date and time Turn on the camera and connect it to a PC with the included USB cable. After a few seconds, the microSD card will be shown as a removable disk, then open SETTIME.TXT file. - Page 13 Before Using Your Conbrov DV9 Camera Note: If you cannot find the file SETTIME.TXT after opening the microSD on the computer, please record a video clip to activate the card and set the date and time again. The date and time will remain accurate unless the battery has been depleted for long time.
-
Page 14: How To Use Your Conbrov Dv9 Camera
How to Use Your Conbrov DV9 Camera 1.Turning the Camera On/Off (1) Press and hold the Power to switch the camera on. The LED will light up blue, which indicates that it is in standby mode. (2) Press and hold the Power to switch the camera off. - Page 15 How to Use Your Conbrov DV9 Camera Record a Video flash 3 times blue 2) Motion Detection Recording (Press after the camera is powered on) When motion detection is activated, recording will begin when there is movement in front of the camera(not further than25 feet).The motion sensor detects the environment...
-
Page 16: How To Record With Sound
5.How to Play the Video (1) Connect the DV9 camera to computer, press and hold the Power button for 2 seconds to tum on the camera or take out the microSD, insert it into the card reader (included), then connect the card reader to computer. -
Page 17: Led Status
LED status Operation LED status indication Normally the blue LED indicator will stay on. Power On If no microSD, the blue LED flashes (Press and hold the Power button for 10 seconds then powers off. for 2 seconds) The camera powers Off after 60 seconds if there is no any operation. -
Page 18: Technical Specifications
Technical specifications Item Parameter Dimensions 21*15*4CM Net weight 415g Battery Capacity 10000mAh Stand-by power consumption 10uA PIR detection angle 60 degrees PIR detection distance 5-8 meters Camera angle 75 degrees Max PIR stand-by time 2 years Day time recording power 220 mA consumption Max day time recoridng... -
Page 19: Faqs
FAQs 1. Q: "The battery standby time up to 2 year when the camera is fully charged." Do you really mean 2 years? or 2 days? A: It's two years! This camera has a 10000mAh built-in rechargeable battery. When it is in motion detection mode, the battery standby time up to 2 year because it consumes a little power. - Page 20 The user manual said it works only up to 32Gb microSD card. A: The software version for this Conbrov book camera supports a microSD card up to 32Gb. We will inform you if we upgrade it to 64Gb later.
-
Page 21: Warranty
Warranty All products sold by the Conbrov Group are covered by a 12-month full replacement warranty. Happy with it? Share your experience with an Amazon review. Or any questions? Our friendly customer services team are ready to help: support@conbrov.com Contacting us via the above email address is the quickest way to reach our support team. - Page 22 All trademarks or registered trademarks are the property of their respective owners. About Us Conbrov Electron Co., Ltd. founded in 2003 is an innovative technology research company specialized in personal surveillance cameras and on-dash cameras. Conbrov products and technology are patent protected by PCT or U.S. Patent Office.
