LTV -ICDM2-723L-F4 User Manual

H.264
Hide thumbs
Table of Contents

Advertisement

Quick Links

H.264 Network Camera
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTV-ICDM2-723L-F4 and is the answer not in the manual?

Questions and answers

Related Manuals for LTV LTV-ICDM2-723L-F4

Summary of Contents for LTV LTV-ICDM2-723L-F4

  • Page 1 H.264 Network Camera User’s Manual...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.

  • Page 3: Table Of Contents

    Contents Product Features ..........................4 Accessing the Camera ........................9 Access from a browser ......................... 9 Accessing the camera from the Internet ..................10 Adjusting the Image ........................10 The Live View page........................10 Video stream types ........................11 How to stream H.264 ........................11 The Setup ............................

  • Page 4: Product Features

    1. Product Features The NMDI is a high performance H.264 network camera, designed for demanding security installations. It delivers crisp, clear images, disclosing every detail, thanks to its top quality 3.0 Megapixel progressive CMOS sensor and advanced image processing. Supported by the industry’s largest base of video management software, the NMDI provides the perfect solution for securing bank offices, airports and other facilities, and for traffic surveillance, over IP based networks.
  • Page 5 3.How to install 1) Remove Dome Cover - Please turn counterclockwise the dome cover by grasping the bottom of the camera. 2) ADJUST IMAGE POSITION - The orientation of the camera up and down on the position of the image you want, please adjust left and right.
  • Page 6 3) PORTS AND BUTTONS...
  • Page 7 Mounting to a ceiling / wall 1) IN CEILING MOUNT...
  • Page 8 2) SURFACE MOUNT...

  • Page 9: Accessing The Camera

    2. Accessing the Camera Follow the instructions in the NMDI Installation Guide to install the camera. The NMDI could be accessed with most standard operating systems and browsers. The recommended browser is Internet Explorer for Windows with other operating systems. 2.1 Access from a browser 1.

  • Page 10: Accessing The Camera From The Internet

    2.2 Accessing the camera from the Internet Once installed, the camera is accessible on the local network (LAN). Configure the router/firewall to allow incoming data traffic to access the camera from the Internet. For security reasons this is usually done on a specific port. Please refer to the documentation for router/firewall for further instructions.

  • Page 11: Video Stream Types

    2.5 Video stream types H.264 protocols and communication methods • RTP (Real-time Transport Protocol) is a protocol that allows programs to manage the real-time transmission of multimedia data, via unicast or multicast. • RTSP (Real Time Streaming Protocol) serves as a control protocol, to negotiate the type of transport protocol to use for the stream.

  • Page 12: The Setup

    RTP/RTSP/Unicasting should be used for video-on-demand broadcasting, so that there is no video traffic on the network until a client connects and requests the stream. However, as more and more unicast clients get connected, the traffic on the network will increase and may cause congestion. Although there is a maximum of 10 unicast viewers, note that all multicast users combined count as 1 unicast viewer.

  • Page 13: Installation

    4. Installation The following descriptions show examples of some of the features available in the NMDI. 4.1 Installation Setup Analog Output allows use of the analog BNC output from the camera to connect the camera NTSC, PAL: Analog Output is enabled. OFF: Analog output will be disabled.

  • Page 14: Camera And Image

    5. Camera and Image The following descriptions show examples of some of the features available in the NMDI. 5.1 Video Codec These are the tools for adjusting the H.264 settings and controlling the video bit rate. H.264 This is a video compression standard that makes good use of bandwidth and which could provide high-quality video streams at less than 1 Mbit/s.

  • Page 15: Codec

    Codec H.264 Size Video output resolution. See the next page for the output resolution table. Image rate 1~30fps in normal mode (1~15fps for slow shutter mode) Note: If the slow shutter mode is turned on and the low light condition is met, the frame rate is automatically goes down.

  • Page 16: Camera

    5.2 Camera This section allows you to adjust various camera settings. 5.2.1 Exposure Control Exposure Mode AUTO: Use this setting for automatic exposure control. MANUAL: Use these settings to control camera exposure manually. To compensate for poor lighting conditions, you can adjust the Color level, Brightness, Sharpness, Contrast and Exposure control.

  • Page 17: Day & Night Control

    Max AGC Gain For low light conditions, adjust to a higher value, such as 30dB. BLC Control (Back Light Compensation) The BLC adjusts the exposure of scenes with strong backlight in the center-bottom of the image. When the image background is too bright, or the subject too dark, backlight compensation makes the subject appear clearer.

  • Page 18: Network

    6. Network 6.1 Network > IP Setup Network Settings Click the Setup > Network > IP Setup to see the current network settings. IP Address Configuration - The NMDI supports both IP version 4 and IP version 6 (IPv6 will be supported in V3.00).
  • Page 19 •Primary DNS server Enter the IP address of the primary DNS server for your network. •Secondary DNS server Enter the IP of the Secondary DNS, which is used if the Primary DNS server is unavailable How to assign IP address Default setting is set to “DHCP”...

  • Page 20: Network > Service Port

    6.2 Network > Service Port Service Port Set the HTTP port and RTSP port manual values. Port Forwarding Port forwarding – Automatically sets the connection port of the Router.  Must support the uPnP feature in Router. External IP – If you successfully set the Port Forwarding, IP can be accessed by Web Address will be displayed.

  • Page 21: Network > E-Mail

    6.3 Network > E-mail Notification On/Off – Set the E-mail notification function enable or disable select Frequency – E-mail Notification frequency setup (1, 5, 10, 15, 30, 60 min) E-mail SMTP Server setup Server – server IP or address Port – E-mail SMTP server port Security –...

  • Page 22: Network > Ddns

    6.3 Network > DDNS DDNS Setup On/Off – Set the DDNS function enable or disable select User Set URL – Set URL Hostname manual value input.

  • Page 23: System

    7. System 7.1 System > User User Management ADD or EDIT User setting. Group authority Admin – Settings can be changed and live view User – Live view only...

  • Page 24: System > Date/Time

    7.2 System > Date / Time Date / Time Setup Current Server Time – current Network camera’s system time and date. Setting the server to synchronize Setting the server to synchronize from NTP Server, Manual or PC sync NTP server IP can be changed. Time zone and D.S.T(Day summer time) setting...

  • Page 25: System > Maintenance

    7.3 System > Maintenance System Name Choose a system name to identify the camera. System Reboot Reboot the camera. Factory Default Toreset the camera back to the original factory default settings. Firmware Update From time to time, ITX will release firmware updated for the NMDI camera, which will contain feature additions and other improvements.
  • Page 26 4. In the Firmware Update section, browse to the desired firmware file on your computer. Click OK. NOTE: Do not disconnect power to the unit during the upgrade. The unit will restart automaticallyafter the upgrade has completed. (1~5 minutes) 4. If you suspect the firmware upgrade for the camera has failed, always wait at least 5-10 minutesbefore restarting the upgrade process.

  • Page 27: System > Information

    7.2 System > Information System Information After updating firmware, you can confirm the new F/W version here. Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60065.

  • Page 28: Dimension

    8.DIMENSION (mm)
