Page 1: Installation Guide
Integrated High Speed Dome Camera Outdoor Dome Installation Guide Version 1.3 00P677280ZSEB3... - Page 2 Installation Guide Preface Information given in this manual was current when published. The company reserves the right to revise and improve its products. All specifications are subject to change without notice. Notice This manual provides installation information for the outdoor integrated high speed dome.
- Page 3 Installation Guide This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
-
Page 4: Warnings And Cautions
Installation Guide Warnings and Cautions • Handle the camera carefully Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged by improper handing or storage. • Installing electricity wiring carefully Ask qualified personnel of electrical wiring for the installation. Please note that input electricity to the unit is at tolerance of DC12V/AC24V ±... -
Page 5: Table Of Contents
Installation Guide Table of Contents Introduction........................5 Standard Package Content ..................6 Dome Setups and Cable Connection ...............7 Preparations for Dome Setups ................7 Dome Setups ....................9 3.2.1 Switch Definition ..................9 3.2.2 Communication Switch Setting ............10 3.2.3 Dome ID Setting ................10 3.2.4 Dome Control Protocol Setting ............11 Dome Cable Definition and Requirements ............12 3.3.1 Cable Requirements ................12... -
Page 6: Introduction
Installation Guide Introduction With weather resistant feature, the Integrated High Speed Dome Camera is applicable to outdoor installation. The dome camera supports one cabling for easy installation, and can be integrated with CCTV products, such as DVRs, Control Keyboards, and CCTV accessories for a total surveillance solution. In addition, large set of built-in protocols provide connectivity to other surveillance systems. -
Page 7: Standard Package Content
Installation Guide Standard Package Content Before proceeding, please check the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. 50-cm Data Cable for power Screws Dome Body supply, video and telemetry... -
Page 8: Dome Setups And Cable Connection
Installation Guide Dome Setups and Cable Connection Before installing or connecting the dome camera, please refer to this section and complete preparations for dome setups and various switch settings. Preparations for Dome Setups The following installation procedure is for the outdoor dome equipped with the sunshield housing. - Page 9 Installation Guide STEP 4 Attach the dome cover to the dome body. Before doing that, apply some lubricant on the cover’s water-proof rubber to make the installation process smoother. Note that the tiny protrusion on the dome cover must align with one of the four holes on the dome body.
-
Page 10: Dome Setups
Installation Guide STEP 7 Set the switches located on the bottom of the dome body. Refer to section 3.2 Dome Setups for detailed information about various switch setting. Dome Setups Before connecting the dome camera to other devices of CCTV system, please complete the dome ID and communication switch settings. -
Page 11: Communication Switch Setting
Installation Guide 3.2.2 Communication Switch Setting The table below shows the function of each switch within the Communication Switch. Communication Switch SW 1 RS-485 Setting SW 2 Termination SW 3 Line Lock SW 4 System Initialization SW 5 Reserved SW 6 RS-485 is the interface that communicates the dome camera and its control device;... -
Page 12: Dome Control Protocol Setting
Installation Guide Centesimal Digit Decimal Digit Single Digit NOTE: The number “0” should locate upwards as shown in above diagram for correct switch definition. 3.2.4 Dome Control Protocol Setting Define the protocol you are going to use basing on the devices of your surveillance system. -
Page 13: Dome Cable Definition And Requirements
Installation Guide Decimal Digit Single Digit NOTE: The number “0” should locate upwards as shown in above diagram for correct switch definition. Dome Cable Definition and Requirements For operation, the integrated dome camera requires the video cable to carry the video signals to the remote viewing site, power cable to power the dome and RS-485 data cable to carry commands from the control device. -
Page 14: 22-Pin Data Cable
Installation Guide 3.3.2 22-Pin Data Cable 3-Pin Terminal Block Power Input Video BNC connector Output 4-wire RS485 Connector 2-Wire NOTE: Be careful not to pull the cables improperly during installation. Additionally, it is suggested to fasten the cables after cable connection is completed. -
Page 15: Rs-485 Connector Definition
Installation Guide The 22-pin connector definition is listed as below. Definition Cable AC 24-1/DC (＋) 20AWG ALM NC AC 24-2/DC (－) 20AWG ALM NO 20AWG ALM COM 24AWG ISOG ALM-1 ALM-3 ALM-2 ALM-4 ALM-5 ALM-6 ALM-7 ALM-8 ALM GND VGND 24AWG Video NOTE: For alarm connection, please refer to section 3.3.5 Cable... -
Page 16: Cable Wiring And Connection
Installation Guide Corresponding Pins Definition (22-Pin Connector) 7,10 T+, R+ (D+) Reserved T-, R- (D-) 3.3.5 Cable Wiring and Connection Users may need to do cable wiring when: (1) Connecting self-provided cords to the connector housing instead of using the equipped data cable or (2) Connecting alarm input and output devices. - Page 17 Installation Guide Connect the 22-pin connector to the dome camera.
-
Page 18: Dome Installation
Installation Guide Dome Installation Basing on user’s installation environments, the dome can be installed on ceiling, on wall or on pole. In the following section, various dome installation accessories, installation methods and installation procedures will be described in detail. Dome Dimension The dome dimension is 172 x 302.5mm (6.7x11.9 Inches) and 190 x... - Page 19 Installation Guide Security Screw Set (equipped with Vandal Proof Cover) Power Adapter 77H07-A1030 (Input: 100~115VAC/Output: 24VAC 72VA) 77H07-A2030 (Input: 220~230VAC/Output: 24VAC 72VA) NOTE: When wiring, make sure the G/Y wire (Ground) inserted into the mid-pin of the terminal block. Mounting Accessories Gooseneck Tube White, Iron, 298×385 mm (11.73×15.56 inches) ;...
- Page 20 Installation Guide Straight Tube White, Iron, Height: 250/500 mm (9.8/19.7 inches) ,Diameter: 50 mm (2 inches) 1 kg (2.2 lbs) / 1.8 kg (4 lbs), Supplied with rubber washer-8×1, pendant tube washer×1, spring washer-8×1 and waterproof rubber×1, M8*12 screw×1. Corner Standard Mounting Plate White, 222(L)×204(W)×117(D) mm (8.7×8×4.6 inches);...
- Page 21 Installation Guide Pole Wide Direct Mounting White/Ivory; 270(L)×170(W)×60(D) mm (10.6×6.7×2.4 inches); Diameter: 112~130 mm (4.4~5 inches); 1 kg (2.2 lbs). Supplied with stainless steel straps×4, M8*16 screw×4, washer×4, spring washer×4 Corner Thin Box White/Ivory, 300(L)×164(W)×222(D) mm (11.8×6.5×8.7 inches); 3 kg (6.7 lbs); Supplied with washer×4, M8*16 screw×4 and spring washer×4.
- Page 22 Installation Guide Pole Thin Box White/Ivory; 291(L)×136(W)×245(D) mm (11.5×5.3×9.5 inches); 3.1 kg (6.9 lbs); Supplied with M8*16 screw×4, washer×4, spring washer×4, stainless steel straps×4. Power Box can be set inside the thin box. Pole Wide Box White/Ivory, 270(L)×166(W)×155(D) mm (10.6×6.5×6.1 inches); 3.2 kg (7.1 lbs); Supplied with M8*16 screw×4, washer×4, spring washer×4, stainless steel straps×4.
- Page 23 Installation Guide Pole Wide Direct Mount White/Ivory, 270(L)×170(W)×60(D) mm (10.6×6.7×2.4 inches); Diameter: 112~130 mm (4.4~5 inches); 1 kg (2.2 lbs); Supplied with stainless steel straps×4, M8*16 screw×4, washer×4, spring washer×4 Wall Box Mounting White/Ivory, 270(L)×166(W)×95(D) (10.6×6.5×3.7 inches); 2.2 kg (4.84 lbs); Supplied with M8*16 screw×4, washer×4, spring washer×4 Power Box can be set inside the wall box.
-
Page 24: Ceiling Mounting With Straight Tube
Installation Guide Other Application Accessories Repeater/Converter D77R1: RS-485/RS-232 Converter D77R2: RS-232 between RS-485/RS-442 D77R3: Bi-phase to RS-485/RS-422 D77R1 D77R2 D77R3 Power Box White, 186.5×147 mm (7.3×5.8 inches); 2.6 kg (5.8 lbs) P1030 (Input: 110~115VAC/Output: 24VAC 72VA) P2030 (Input: 220~230VAC/Output: 24VAC 72VA) Signal Distribution Unit Relay control codes to speed dome cameras. - Page 25 Installation Guide • Straight Tube and other equipped items (optional accessory) • Waterproof Rubber (supplied) • Screws and Screw Anchors for fixing the straight tube onto the ceiling (not supplied) Tools Needed: • Tool for drilling • Tool for screwing Follow the steps to mount the dome with the straight tube.
-
Page 26: Wall Mount
Installation Guide Wall Mount 4.4.1 Wall Mounting with Gooseneck Tube The following figures show how cables run through the tube in different ways. Cables exposed Cables recessed Items Needed: • Dome Camera • Gooseneck Tube and other equipped items (optional accessory) •... -
Page 27: Mini Pendant Mount
Installation Guide and top holder. 5) Connect the cables to the dome camera. Then attach the dome to the top holder and fix them with the supplied screw. Wall Mount: Gooseneck Tube + Waterproof Rubber 4.4.2 Mini Pendant Mount Items Needed: •... -
Page 28: Wall Box Mounting
Installation Guide below. Sponge Sponge 3) Thread the cables through the Mini Pendant Mount and fix the pendant mount on the wall with proper screws and screw anchors (not supplied). 4) Thread the cables through the top holder and fix it to the Mini Pendant Mount with the supplied screws and washers. -
Page 29: Corner Mount
Installation Guide 1) Fix the Wall Box on wall with proper screws and screw anchors (not supplied). 2) Fasten the gooseneck tube on the wall box with the supplied screws and washers. Please replace the rubber equipped with the gooseneck/straight tube, with the waterproof rubber packed in the standard package (See 2. - Page 30 Installation Guide • Waterproof Rubber (standard accessory) • Screws and Screw Anchors for fixing the Corner Standard Mounting Plate (not supplied) Tools Needed: • Tool for drilling • Tool for screwing Follow the steps below to mount the dome camera with the corner standard mounting plate and gooseneck tube.
-
Page 31: Corner Thin/Wide Box Mounting
Installation Guide 4.5.2 Corner Thin/Wide Box Mounting The corner thin/wide box is designed to be installed with a gooseneck tube. Items Needed: • Dome Camera • Gooseneck Tube and other equipped items (optional accessory) • Corner Thin/Wide Box (optional accessory) •... -
Page 32: Pole Mount
Installation Guide Corner Box Mounting: Corner Thin/Wide Box + Gooseneck Tube + Waterproof Rubber Pole Mount 4.6.1 Pole Thin/Wide Direct Mounting The dome can be installed on a pole with a thin/wide direct mounting accessory and a gooseneck. Items Needed: •... -
Page 33: Pole Thin/Wide Box Mounting
Installation Guide screws and washers. Please replace the rubber equipped with the gooseneck/straight tube, with the waterproof rubber packed in the standard package (See 2. Standard Package Content). 3) Thread the cables through the gooseneck tube and the top holder. 4) Fix the top holder to the gooseneck tube with the supplied screws and washers. - Page 34 Installation Guide washers. If use an outdoor dome, please replace the rubber equipped with the gooseneck/straight tube, with the waterproof rubber packed in the standard package (See 2. Standard Package Content). 3) Thread the cables through the gooseneck tube and the top holder. 4) Fix the top holder to the gooseneck tube with the supplied screws and washers.
-
Page 35: System Expansion
Installation Guide System Expansion Connecting with Power Box A power box contains a 24V AC adapter, two terminal blocks (for communication and power) and one alarm board. With an IP66 case, the Power Box is ideal for outdoor installation environment. Two models are available: 100~115V AC power input (P1030) and 220~230V AC (P2030). -
Page 36: Data Formats Transforming
Installation Guide Data Formats Transforming To integrate other surveillance devices with the high speed dome cameras or to extend the distance of communications, users could employ three kinds of repeater/converter, as shown below. With the advanced circuit design, these repeaters/converters offer 1KVrms isolation voltage and surge protection capability. -
Page 37: Signal Distribution
Installation Guide Signal Distribution The RS-485 Signal Distribution Unit (SDU) is designed to relay control codes to speed dome cameras. It is capable of communicating with cameras up to 1.0 kilometers away. Additionally, the SDU can be installed in either “star” or “daisy chain”... -
Page 38: Coaxial Telemetry
Installation Guide Coaxial Telemetry The Coaxial Telemetry is a low-cost solution to long distance connection between dome cameras and controlling devices (e.g. DVR and keyboard). It simplifies the work of wiring by transmitting video and RS-485 control signals via one BNC line, so that to bring users economical benefits. The following is the coaxial telemetry application diagram. -
Page 39: System Integration
Installation Guide System Integration The dome camera is allowed to be integrated into other suppliers' surveillance systems with large set of built-in protocols. Refer to the following sections for more information. Using Pelco Keyboard The speed dome camera can be controlled through a Pelco keyboard which built in with D protocol and P protocol. -
Page 40: Using Philips Allegiant Keyboard
Installation Guide Cable Definition (D Protocol Keyboard to PTZ Camera) T x+ Tx - T x+ T x- Rx + For D Protoc ol Ke yb oa rd Fo r Sp ee d Dom e Using Philips Allegiant Keyboard The dome cameras can be integrated into Philips Allegiant systems through D77R3 repeaters. -
Page 41: Appendix A: Technical Specification
Installation Guide Appendix A: Technical Specification Items R Model K Model CAMERA 1/4" CCD 1/4" CCD CCD Sensor Progressive Scan 22× Optical Zoom 1×~ 12× variable Digital Zoom NTSC 380k Effective Pixels 440k NTSC 480 TVL Horizontal Resolution 480 TVL NTSC / PAL Scanning System Internal / Line Lock...
