- Page 1 INVERTER DC TIG ARC WELDER LONGRUN 500LT3 OPERATION MANUAL DO NOT INSTALL, OPERATE OR MAINTAIN THIS MACHINE WITHOUT READING THIS MANUAL AND PLEASE ALWAYS THINK BEFORE YOU ACT. WWW.WORLDWEL.COM...
- Page 2 ■ TECHNICAL SPECIFICATIONS - SUFFICIENT CAPACITY of main transformer by self-manufacturing - ELECTRIC SHOCK PROTECTOR reduces No load voltage to 14VDC for user safety when welder is not in use. - Easy to verify welding current during welding by DIGITAL AMMETER. - Optional REMOTE CONTROL BOX is available for adjusting output current without going back to power source.
- Page 3 General Safe Practices ■ Wear approved safety glasses with side shields under your welding helmet or face shield and at all times in the work area. ■ When working above floor level, use a safety belt to protect yourself from a fall should you get a shock.
- Page 4 Accidental contact can cause overheating and create a fire hazard. ■ Do not weld on drums, tanks, or any closed containers unless a qualified person has tested it and declared it or prepared it to be safe. ■ Connect the work cable to the work as close to the welding area as practical. Work cables connected to the building framework or other locations away from the welding area increase the possibility of the welding current passing through lifting chains, crane cables or other alternate circuits.
-
Page 5: Input Voltage Selection
※ Input voltage selection ․ Verify the connection of voltage selection terminal. √ If necessary to change it, Remove the cover of input voltage selection plate. ․ Position the wires for the voltage to be supplied from main power. ․ For 380V and 440V input, position a switch for the voltage would be used which is rear. -
Page 6: Output Connection For Stick Welding
Output connection for stick welding Connect the work cable (which is connected to the work clamp) to the TORCH terminal. ․ Connect the electrode cable (which is connected to the electrode holder) to the METAL terminal. ․ ■ FRONT PANEL... - Page 7 Ammeter Displays the welding current It indicates that the machine is on and input voltage is within Power Lamp acceptable range. It indicates that the machine is ready to run. If the warning lamp Ready Lamp is turn on, then it will be off. It indicates the thermal over load or output disabled by any electrical problems or the water pressure.
-
Page 8: Stick Welding
■ Start Up Stick Welding TIG Welding Turn On the main power supplied to welder Turn On the main power supplied to welder Select Crater Off or Crater On or Crater Repeat Select "STICK" from the welding mode selector from welding mode selector Adjust properly pulse... - Page 9 ■ Welding Mode Press and hold the torch switch, the machine will open the gas valve to start the flow of the shielding gas during the pre-flow time and then the arc is started at welding current. When finish to weld, release the torch switch, then the arc is off and flow the gas during the gas Crater Off after-flow time.
-
Page 10: Recommended Action
■ TROUBLESHOOTING SYMPTOMS REASON RECOMMENDED ACTION No input voltage Verify input voltage ․ ․ Cooling fan does not run when the power switch Fuse (3A) is blown Replace Fuse (3A) ․ ․ is turn on. Power switch broke down Replace Power switch ․... - Page 13 500LT3 PARTS LIST *Description can be changed by LOT number PART NAME DESCRIPTION QTY. Control Transformer 9645 Control Transformer 4114 Main PCB WNLT-01 HF PCB TMD-45A89 Control Transformer PCB VAC-02 PWM PCB WAPD-01 Relay HR710-2PB DC24V MF Condensor 20 /800V ㎌...
- Page 14 Please record your machine identification information below for future reference. This information can be found on the nameplate of your machine. Product Name INVERTER DC TIG ARC WELDER Model Number LONGRUN 500LT3 Date Manufactured Serial Number Date Purchased Where Purchased...
