Altivar Process
EAV64301 01/2015
Chapter 5
Checking Installation
Checking Installation
Check List Before Switching On
Mechanical Installation
Verify the mechanical installation of the entire drive system:
Step
Electrical installation
Verify the electrical connections and the cabling:
Step
Covers And Seals
Verify that all covers and seals of the control cabinet are properly installed to meet the required degree of
protection.
EAV64301 01/2015
Action
1
Does the installation meet the specified distance requirements?
2
Did you tighten all fastening screws with the specified tightening torque?
Action
1
Did you connect all protective ground conductors?
2
Do all fuses and circuit breaker have the correct rating; are the fuses of the specified type? (refer to
the catalog and the Getting Started Annex available with the product).
3
Did you connect or insulate all wires at the cable ends?
4
Did you properly connect and install all cables and connectors?
5
Do all plug-in terminals colors and markings correspond to the colors and marking of the control
block?
6
Did you properly connect the signal wires?
7
Are the required shield connections EMC-compliant?
8
Did you take all measures for EMC compliance?
91
