Altivar Process ATV630 Installation Manual page 16

Catalog Number Description
NOTE: see the catalog for possible combinations.
Nameplate example
The nameplate contains the following data:
“
•
—
˜
Product type
Firmware version
Fuses and overload protection information
Degree of protection
16
Altivar 630
ATV630U40N4
4kW - 5HP
V1.0 IE00
Input
U (V~) 380 - 480
kW
F (Hz) 50 / 60
I (A)
7.6 max
U (V~) 380 - 480
F (Hz) 50 / 60
I (A)
7.6 max
HP
SCCR : for rating and protection refer to Annex
of the getting started
Internal Motor Overload Protection - Class 10
Cu AWG14 75° C
15.9 lb.in 1.8 N.m
6W0502001001
FR 92506 Rueil Malmaison
Made in Indonesia
Catalog number
Power part supply
Certifications
Output
3 0...380 - 480 3
0...500
9.3
3 0...380 - 480 3
0...500
9.3
”
IP21
–
Power rating
Power part cable information
Serial number
EAV64301 01/2015
