Analog way RK-300 Quick Start Manual

QUICK START GUIDE
Thank you for choosing Analog Way
and use your powerful remote Control Keypad within minutes. Discover the
interface while configuring your first show, and unleash your creativity for a new experience in show and event
Analog Way.
management by
What's in the box
1 x RK-300 (RK-300)
1 x Power supply Cord
1 x DB9 (M/F) Cable
1 x Carrying Case
1 x Quick Start Guide *
* Download on our website:

RK-300 settings

• The RK-300 automatically detects the right versions
of the product to control. Connect the DB9 cable
supplied or an Ethernet crossover cable using the
same protocol as the unit connected.
• To control the following Seamless Switchers:
Control Seamless Seamless
Mode Mixer
EKS500 x
EKS400 x
OPS300 x
OPS200 x
PLS300
x
PLS200
x
SVU300 x
SVU200 x
SMX100
SMX200
STE100
SQD200
We recommend using the Advanced Seamless Matrix Mode with
(1)
an ORCHESTRA or a Remote Control Software (RCS).
Navigation Menu:
To access the RK-300 menu, press the [EXIT/MENU]
button in the control section. To highlight items in the
menu which will appear on the VFD screen, turn the
scroll knob left or right to the desired menu item. When
you have reached the desired menu item, press the
[ENTER] button in the control section to access that
menu function.
and the RK-300. By following these simple steps, you should be able to setup
http://www.analogway.com
Quadra- Soft Edge
Matrix vision Blending
x x
(1)
x
(1)
x
x
x
(1)
x
x
RK-300 - Ref. RK-300
RK-300 extensive capabilities and intuitive
Pressing the [ENTER] button when a selection has been
made sets the value to that selection in the RK-300
memory. When all settings have been made, press the
[EXIT/MENU] button to exit sub-menus and return to the
main menu.
IMPORTANT: simply selecting a menu item will not set it
to that value. Be sure to press the [ENTER] button when
parametering the menu items.
Once you have connected your RK-300 to your switcher,
configure the connection settings on both devices.
For a serial connection, select RS232 from the RS232/
LAN menu on both devices.
For a LAN connection, select LAN from the RS232/LAN
menu on both devices, and configure each device with
a unique IP in the LAN setup - > RK-300 address menu.
The default IP on the RK-300 is 192.168.0.15. Next,
enter the IP of the device you wish to control in the Lan
Setup - > Device address menu.
Once your settings are correct, the RK-300 will begin to
synchronize with the device, and you will be ready to begin.
Button Color Usage:
#1 = Source is on the main outputs
Solid red:
#2 = Freeze enable
#3 = Stand-by button
#4 = Preset Selection
Solid green: #1 = Source is on Preview
#2 = Function available for modification
Solid orange:
Unlocked sources
Blinking red: Layer/source selected, and is currently
active on the main output
Blinking green: Layer/source selected, and is not currently
active one the main output
