Tektronix 7A16P Instruction Manual page 154

R
e
p
laceable
E
lectrical Parts-7A161?
7- 1 4
R
EV F
E
B
1983
C
kt No .
Tektronix
P
art No . ,-__-
Serial/Model
E
ff_α
No .
Ds cont
N
ame & Description
Mfr
.__Co
d
e ._._ λMfr
P
art Number s ,
S50410 263-0020-00 SWITCH,PB ASSY :MOMENTARY
80009 263-0020-00
S50500 263-0020-00 SWITCH,Ρ B ASSY :MOMENTARY
80009 263-0020-00
S50508 263-0020-00
SWIΓCH,PB ASSY :MOMEN -ΓΑ RΥ
80009 263-0020-00
S50510 263-0020-00
SWI I- CH,PB ASSY :MOMEN'ΤΑ RΥ 80009 263-0020-00
Τ10418 120-0286-00
X FMR,TOROID :2 TURNS,BIFILAR 80009 120-0286-00
U10310
156-0854-00 MICROCIRCUI Γ,LI: OPERATIONAL AMPLIFIER 27014
LM308AN
U30020 156-0466-02
MICROCIRCUIΤ,
D
I : QUAD 2-ΙΝΡ
N
AND B
F
'R 01295 SN74LS37
U30120 156-0411-00
MICROCIRCUIT',LI :QUAD-COMP,SGL SUPPLY 27014
LM339N
U30210 156-0466-02
M
ICROCIRCUiT, ϋI : QUAD 2-ΙΝΡ NAND BFR 01295 SN74LS37
U
30220 156-0411-00
MICROCIRCUIT,LI:QUAD-COMP,SGL SUPPLY 27014
LM339N
U30410 156-0093-02
MICROCIRCUIT,DI :HEX INV BUF
F
ER,BURN-IN 27014
DM8016
U30420 156-0733-02 MICROCIRCUI Τ',DI : DUAL MONOSTABLE MV,SCRN
04713 SN74LS221 Ν/J
U30500 156-0385-02
MICROCIRCUIT,DI :HEX
I
NVERTER 01295 SN74LS04
U30600 156-0480-02
MICROCIRCUIT,DI :QUAD 2 ΙΝΡ & GATE 01295 SN74LSOSNP3
U30610 156-0382-02
ΜICROCIRCUIT,DI : QUAD 2-ΙΝΡ NAND GATE
01295 SN74LS00
U30630 156-0981-00 Β 010100 Β 041353 M
ICROCIRCUIT,DI :2048 Χ 8 ROM,CUSTOM MASK
80009 156-0981-00
U30630 160-1511-00 8041607 M
ICROCIRCUIT,DI :2048 Χ 8 EPROM,PROGRAMMED 80009
160-1511-00
U30700 156-0464-02 M
ICROCIRCUIT, DI : DUAL 4 ΙΝΡ
N
AND GATE
01295 SN74LS20
030710 156-0067-00
ΜICROCIRCU1 Τ,LI:OPERA Γ10 ΝΑ L AMPLIFIER
01295 MICROA741CP
030720 156-0467-02
ΜICROCIRCUΙT,DI : QUAD 2- ΙΝΡ
N
AND BFR,SCRN
01295 SN74LS38
030810 156-0927-00 M
ICROCIRCUI7,LI :DIGITAL TO ANALOG CONVERTER
80009 156-0927-00
030830 156-0980-00 8010100 Β 041353 M
ICROCIRCUIT,
D
I :2048 Χ 8 ROM,CUSTOM MASK
80009 156-0980-00
U30830 160-1512-00 Β041607 M
ICROCIRCUIT,DI :2048 Χ 8 EPROM, PROGRAMMED
80009 160-1512-00
U30900 156-0427-00 8010100 8040951
MICROCIRCUIT,DI:PERIPHERAL INTERFACE ADPTR 04713
MC6820(L OR Ρ)
U40900 156-0427-04 Β040952
MICROCIRCUIT',DI :PERIPHERAL
I
NTERFACE ADPTR
80009 156-0427-04
U30920 156-0426-00 Β010100 8030569 MICROCIRCUI
T
,DI:MICROPROCESSOR 04713 MC6800S
U30920 156-0426-05 Β030570
MICROCIRCU ΓΤ',DI :MICROPROCESSOR,SCRE
E
NED 80009
156-0426-05
U31630 160-1511-00 Β041354 Β041606
MICROCIRCUIT, DI :2048 Χ 8 EPROM,PROGRAMM
E
D 80009 160-1511-00
031830 160-1512-00 Β041354
8041606 MICROCIRCUIT,DI:2048 Χ 8 EPROM,PROGRAMMED 80009
160-1512-00
060240 155-0078-10
MICROCIRCUI
T
,LI:ML,VERTICAL AMPLIFIER
80009 155-0078-10
U
60340 155-0078-10
MICROCIRCUIT,LI:ML,VERTICAL AMPLIFIER 80009
155-0078-10
U
60440 155-0078-10
MICROCIRCUIT,LI:ML,VERTICAL AMPLIFIER
80009 155-0078-10
U
60540 155-0078-10
MICROCIRCUIT,LI:ML,VERTICAL AMPLIFIER 80009
155-0078-10
060610 156-0479-02
Μ ICROCIRCUIT,DI : QUAD 2- ΙΝΡ OR GATE
01295 SN74LS32NP3
U60710 156-0385-02
M
ICROCIRCUIT,DI :HEX INVERTER 01295
SN74LS04
U
60810 156-0140-02
M
ICROCIRCUIT,DI :HEX BUFF
E
RS
W
/OC HV OUT 27014 DM8017NA +/JA+
U60910 156-0093-02
M
ICROCIRCUIT,DI :HEX INV BUFF
E
R,BURN-1 Ν 27014
DM8016
U301000 156-0427-00 Β010100 8040951 MICROCIRCUIT,DI :PERIPHERAL INTERFACE ADPTR
04713 MC6820(L OR Ρ)
U301000 156-0427-04 Β040952
MICROCIRCUIT,DI :PERIPHERAL INTER
F
ACE ADPTR
80009 156-0427-04
U301030 156-0716-00 MICROCIRCUIT,DI :RAM,128 Χ 8 STATIC
04713
M
CM6810S
0301200 156-0427-00 8010100 8040951 MICROCIRCUIT,D
L PE
R
IPHERAL INTERFACE ADPTR 04713 MC6820(1- OR Ρ)
0301200 156-0427-04 8040952
M
ICROCIRCUIT,D
L
PEHIPHERAL INTERFACE ADPTR
80009 156-0427-04
0301220 156-0736-02
MICROCIRCUIT,DI:BCD TO DECIMAL DCDR 80009
156-0736-02
0301226 156-0382-02
MICROCIRCUIT, DI : QUAD 2- ΙΝΡ NAND GATE
01295 SN74LS00
U
301230 156-0656-02
MICROCIRCUIT, DI : DECADE COUNTER,BURN- IN 01295
SN74LS90
U
301310 155-0135-00
MICROCIRCUIT,DI:DUAL IN
L
INE,20 LEAD
80009 155-0135-00
U301320 156-0541-02
M
ICROCIRCUIT,DI :DUAL 2 ΤΟ 4
L
INE DCDR 01295
SN74LS139NP3
U301330 156-0479-02
M
ICROCIRCUIΤ,DI:QUAD 2-ΙΝΡ OR GΑΤΕ 01295 SN74LS32NP3
U301420 156-0386-02
M
ICROCIRCUf Γf,DI :TRIPLE 3-ΙΝΡ
N
AND GATE 27014 DM74LS10N
U301430 156-0405-03 MICROCIRCUIT,DI :DUAL RETRIG M
ONOSTABLE MV 07263 9602
U301500 155-0164-00 MICROCIRCUIT,DI:TIME SLOT SWITCH
80009 155-0164-00
U301520 156-0645-02 MICROCIRCUIT,DI:HEX INV ST NAND GATES,SCRN
01295 SN74LS14
