Audiovox Jensen PS1220M Installation & Operation Manual

Audiovox electronics corp. amplifier installation & operation manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PS1220M
Audiovox Electronics Corporation
150 Marcus Boulevard
Hauppauge, NY 11788
1-800-323-4815
www.jensen.com
© 2004 Audiovox
v.030204
Contents
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Indicators and Controls. . . . . . . . . . . . . . . . . . . . . .8
Remote Level Control. . . . . . . . . . . . . . . . . . . . . . .8
Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Amplifier
R
Installation
&
Operation
Manual
Introduction
Thank you for purchasing a Jensen amplifier. PS series amplifiers offer extreme value and performance. Proper installation
is essential for optimal performance and long-term reliability. Please read through this manual to familiarize yourself with
your amplifier and its functions.
Warranty Service
If your Jensen amplifier should ever require service, you will need to have the original dated receipt. If you need to return
the unit for any reason, always include the receipt with the product.
Installation Assistance
For installation assistance, call 1-800-323-4815 during normal business hours, or visit www.jensen.com at any time.
Features
•
State-Variable crossover design for precision frequency adjustment
•
12dB/octave Butterworth alignment
•
40Hz – 200Hz crossover frequency range
•
iX² Bass with continuously variable 0dB to +18dB bass boost centered at 45Hz
•
Input level control with a 300mV to 8V input range
•
High level inputs for interfacing with OEM/factory head units
•
Full range pre-amp output for installation flexibility
•
Dual status LED diagnostic indicator
•
Thermal, short circuit and low impedance protection circuitry
•
Unregulated Pulse Width Modulated (PWM) power supply for extended dynamic range
•
Balanced driver circuitry and complementary output stage design for low distortion and unparalleled stability
•
High current output stage easily drives 2 ohm loads

Advertisement

Table of Contents
loading

Related Manuals for Audiovox Jensen PS1220M

Summary of Contents for Audiovox Jensen PS1220M

  • Page 1 PS1220M Audiovox Electronics Corporation 150 Marcus Boulevard Hauppauge, NY 11788 1-800-323-4815 www.jensen.com © 2004 Audiovox v.030204 Contents Introduction.......1 Features .

  • Page 2: Table Of Contents

    PS1220M Manual de Instalación y Operación Contenido Introducción ..............2 Características .
  • Page 3 PS1220M Installation This device is a high-power audio amplifier intended for installation in vehicles with a 12-Volt negative ground electrical system. Attempting to connect or operate the amplifier in another type of electrical system may cause damage to the amplifier or the electrical system. Supplies and Tools Needed To install the amplifiers, you will need tools, supplies and adapters.

  • Page 4: Instalación

    Instalación Este dispositivo es un amplificador de sonido de alta potencia. Este amplificador ha sido diseñado para ser instalado en vehículos con un sistema eléctrico de 12 voltios y masa negativa. El intento de conectar o hacer funcionar el amplificador en otro tipo de sistema eléctrico puede causarle daños al amplificador o al sistema eléctrico.

  • Page 5: Wiring

    Wiring Power Wiring Power Terminal (+12V) Connect directly to the vehicle battery positive (+) terminal with a minimum of 10-gauge wire. Remote Terminal (REM) Connect the power antenna or amplifier turn-on lead from the receiver to the amplifier remote terminal. Ground Terminal (GND) Connect to a good chassis ground.
  • Page 6 Wiring (continued) Speaker Wiring The Speaker Wiring diagrams illustrate options for connecting one or two subwoofers. One Subwoofer Un Subwoofer Un Subwoofer 4 ohm nominal Pass-Thru RCA Outputs The output signal allows you to conveniently connect other amplifiers to each other. RCA Output Cableado de la Salida Câblage de Rendement...

  • Page 7: Cableado

    PS1220M Cableado Alimentación Terminal Eléctrica (+12V) Conecte directamente a el terminal positivo (+) de la batería del vehículo de calibre 10 (PS260 y PS285) o de calibre 8 IPS2130) como mínimo. Terminal Remota (REM) Conectar la antena o la cabeza de encendido del amplificador desde el receptor a la terminal remota del amplificador.

  • Page 8: Indicators And Controls

    Indicators and Controls Power Indicator The power indicator provides a visual indication that the amplifier is turned on. Level The input level control matches the output of your radio to the input of the amplifier. After the installation is complete, make sure the input level control on the amplifier is turned down all the way (counterclockwise or all the way to the left).

  • Page 9: Caindicadores Y Controles

    PS1220M Commande à Distance de Niveau Le commande à distance de niveau permet que le niveau d'entrée soit ajusté dès une position alternative. Le même peut être s'installé dessous du planche ou dans le planche. Quand on utilise l'amplificateur par transmettre haut-parleur des bas et la croisée de bas pas est activé, le comande à...

  • Page 10: Pruebas

    Indicadores y Controles Indicador de energía Proporciona una indicación visual de que el amplificador está encendido. Nivel de Entrada El control de nivel de entrada iguala la salida de su radio con la entrada del amplificador. Después que la instalación se complete, asegúrese de que el control de nivel de entrada en el amplificador esté girado completamente hacia la izquierda (en el sentido contrario a las agujas del reloj).

  • Page 11: Hauppauge, Ny

    Specifications subject to change without notice. 12-Month Limited Warranty AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor.

  • Page 12: Localización De Problemas

    Las especificaciones están sujetas a cambio sin previo aviso. Garantia Limitade de 12 Meses AUDIOVOX CORPORATION (la Compañía) garantiza al comprador minorista original del presente producto que en el caso de que este producto o cualquiera de las partes del mismo, bajo circunstancias y condiciones de uso normal, tuviera algún defecto, tanto en el material como en la mano de obra, dentro de un plazo de 12 meses a partir de la...

  • Page 13: Localisations De Problèmes

    Garantie Limitée de 12 Mois AUDIOVOX CORPORATION (la Société) garantit à l’acheteur initial du produit que si tout ou partie de ce produit, en cours d’utilisation et sous des conditions normales, venait à présenter des vices de matière primitive ou des défauts de fabrication, dans les 12 mois suivant la date d’achat initial, ce(s) défaut(s) sera(seront) réparé(s) ou remplacé(s)
  • Page 14 PS1220M...
