Summary of Contents for D.A.S. PA-500

  • Page 1 User’s Manual PA series Antes de utilizar el equipo, lea la sección “Precauciones de seguridad” de este manual. Conserve este manual para futuras consultas. Before operating the device, please read the “Safety precautions” section of this manual. Retain this manual for future reference.
  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS WARRANTY DECLARATION OF CONFORMITY INTRODUCTION FRONT PANEL DESCRIPTION Power switch Power LED Level controls Clip LED Protection LED Signal LED Cooling air grilles BACK PANEL DESCRIPTION Speaker outputs Inputs Mode switch Sensitivity mode Circuit breaker Power outlet Cooling air outlet grilles INSTALLATION Racking...
  • Page 3: Safety Precautions

    PA series Precauciones de Seguridad Safety Precautions Amplificadores de Potencia / Power Amplifiers Conserve y lea todas estas instrucciones. Keep these instructions. Siga todas las advertencias. Heed all warnings. Follow all instructions. El signo de exclamación dentro de un triángulo indica la The exclamation point inside an equilateral triangle indicates the existencia de componentes internos cuyo reemplazo puede existence of internal components whose substitution may affect...
  • Page 4: Warranty

    GARANTÍA Todos nuestros productos están garantizados por un periodo de 24 meses desde la fecha de compra. Las garantías sólo serán válidas si son por un defecto de fabricación y en ningún caso por un uso incorrecto del producto. reparaciones garantía pueden realizadas,...
  • Page 5: Declaration Of Conformity

    DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY D.A.S. Audio, S.A. C/ Islas Baleares, 24 - 46988 - Pol. Fuente del Jarro - Valencia. España (Spain). Declara que la serie PA: Declares that PA series: Cumple con los objetivos esenciales de las Directivas: Abide by essential objectives relating Directives: Directiva de Baja Tensión (Low Voltage Directive) 2006/95/CE...
  • Page 6: Introduction

    INTRODUCTION General Thank you for purchasing a D.A.S. power amplifier. It has been built with the most advanced modular technology, and has been designed through the use of computer-aided design for both the electronic and mechanical parts. Features Efficient linear power supply. Dual balanced XLR inputs.
  • Page 7: Back Panel Description

    BACK PANEL DESCRIPTION Model INPUT CH 1 CH 2 CH 1 CH 2 CH 2 CH 1 CH 1 SENSITIVITY MODE RESET OUTPUT 0.775V BRIDGE LOCK LOCK 1.4V STEREO CAUTION ATTENTION RISK OF ELECTRIC SHOCK DANGER D’ELECTROCUTION DO NOT OPEN NE PAS OUVRIR CH 2 CH 1...
  • Page 8: Installation

    INSTALLATION Racking ON / OFF All amplifiers are 19-inch rack mount width and The main power switch is a push button that are 2U DIN in height. turns the amplifier on/off. Four front-panel mounting holes are provided When the amplifier turns on, the power LED for use with M5 or M6 or 1/4”...
  • Page 9: Connections According To Operation Mode

    CONNECTIONS ACCORDING TO OPERATION MODE Stereo connection INPUT CH 1 CH 2 CH 1 CH 2 CH 2 CH 1 CH 1 SENSITIVITY MODE RESET OUTPUT 0.775V BRIDGE LOCK LOCK 1.4V STEREO CAUTION ATTENTION RISK OF ELECTRIC SHOCK DANGER D’ELECTROCUTION DO NOT OPEN NE PAS OUVRIR CH 2...
  • Page 10: Specifications

    SPECIFICATIONS Rated power /model PA-500 PA-900 PA-1500 PA-2700 1kHz(HIA)with0.5%THD 4Ω stereo(per channel) 250W 450W 750W 1350W 150W 350W 500W 1000W 8Ω stereo(per channel) 500W 900W 1500W 2700W 8Ω bridge mono Performance Frequency Response(at 1 Watt) 20Hz-20KHz,+0-1dB Total Harmonic Distortion (THD) <0.5%,20Hz-20kHz...
