Soundigital LINHA EVOLUTION Owner's Manual

Evolution line

Advertisement

Quick Links

Manual SD5000.1D Evolution REV 1.6

Limited Warranty

SounDigital warrants the original purchaser that this
product shall be free of defects in materials and
workmanship for a period of ninety (90) days from the
original date of purchase. The warranty term is
extended to twelve (12) months if installation is
performed or approved by an authorized SounDigital
dealer (requires proof of installation or approval
required on purchase receipt).
This warranty is not transferrable and applies only to
the original customer from an authorized SounDigital
dealer.
Warranty is void when:
- Defect or problem caused by misuse of the product;
- Incorrect
installation or non-conformity with the
Manual;
- Maintenance made by unauthorized personnel;
- Alteration or removal of the seal/serial number;
- Exposure to adverse conditions (weather, humidity,
etc)
- Damage caused by fall or impact;
- Damage caused by natural depreciation;
- Damage caused by transport and/or handling, risks,
or smashings.
- Products was purchased more than 12 months ago.
Warranty covers:
- Component or material with manufacturing defects;
-Workmanship/service needed to repair the
equipment.
If you need service on your SounDigital amplifier, send
it (freight-prepaid) to SounDigital´s Amplifier Repair
Center through an authorized SounDigital dealer
(must be accompanied by proof of purchase).
- Any extra information you can get by contacting us at
the e-mail address: info@soundigitalusa.com;
- In case of manufacturing defect or bad quality of raw
material, the max compensation will be the
replacement of the product, not allowing any kind of
compensation payment;
- New modifications/iterations on a product don't
obligate the manufacturer to modify products formerly
produced.
Customer Service Phone - +55 51 3042 9001
General e-mail: info@soundigitalusa.com
Tech Support: tech@soundigitalusa.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the LINHA EVOLUTION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Soundigital LINHA EVOLUTION

  • Page 1: Limited Warranty

    - Component or material with manufacturing defects; -Workmanship/service needed to repair the equipment. If you need service on your SounDigital amplifier, send it (freight-prepaid) to SounDigital´s Amplifier Repair Center through an authorized SounDigital dealer (must be accompanied by proof of purchase).
  • Page 2 Gain positioning over the correct To avoid unwanted noise in the system, join the spot may cause noise, trigger ground points of the equipment and audio output to protection state or damage to the only one point. speakers. After the end of the electrical installation, connect the Adjust the Low and High pass filters according to your negative cable of the battery and, before starting the preference and needs of the speakers.
  • Page 3 Your Soundigital amplifier needs the correct cables and Securely mount the amplifier so that it does not come loose in the event of a collision or a sudden jolt to the electrical system vehicle. Avoid mounting it on metallic parts of the...
  • Page 4: Technical Specs

    Technical Specs 0.5V ~ 8V Operating Voltage Input Sensivity 5Hz ~ 80Hz Current Draw (Stand By) 530 A 80Hz ~ 20KHz Max Current Draw Current Draw (Music) 265 A Bass reinforcement frequency Power @ 12.6v (0.1% max THD+N) 5000W Power @ 12.6v (double impedance/0.1% max THD+N) 2600W Power @ 14.4v (0.1% max THD+N) 5600W...
  • Page 5 Audio Input RCA connector; Audio Output RCA connector; Variable high pass filter control (5Hz ~80Hz); Variable low pass filter control (80Hz ~20KHz); Variable signal gain control; Variable bass boost control (0dB - +12dB); Variable bass reinforcement frequency control (35Hz ~ 55Hz); Negative audio output connector (-);...
  • Page 6 Capacidade mínima da bateria Capacidade ideal da bateria...
  • Page 7 85 dB may cause irreversible hearing loss. - Efficiency – The Soundigital Class D amplifiers have a total efficiency (power source + output) higher than 70%, assuring a battery consumption and a heating Package contents lower than the expected.
