Soundigital 3000.1D NANO Owner's Manual

Hide thumbs Also See for 3000.1D NANO:

Advertisement

Quick Links

Download this manual
OWNER´S MANUAL
1 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3000.1D NANO and is the answer not in the manual?

Questions and answers

Related Manuals for Soundigital 3000.1D NANO

Summary of Contents for Soundigital 3000.1D NANO

  • Page 1 OWNER´S MANUAL...

  • Page 2: Table Of Contents

    Introduction..............................3 Package contents............................3 Safety instructions ............................. 4 Assembling and Disassembling the plastic cover ..............5 Panels description Controls, Audio inputs and outputs ............... 6 Power supply ........................7 Installation sequence ..........................8 Electrical Dimensioning.......................... 9 Audio inputs RCA inputs ........................... 9 Procedure for setting the Gain......................

  • Page 3: Introduction

    INTRODUCTION Dear Consumer, Congratulations, you have just acquired a SounDigital product of the highest technology and quality, so we thank you for your trust. SounDigital products are made with raw materials of the highest quality standards, and the most modern processes, equipment and technology are used in their production.

  • Page 4: Safety Instructions

    Wear gloves, safety glasses firmly. Avoid fixing to metallic and all necessary PPE during parts of the vehicle, as this the installation of SounDigital procedure may cause ground amplifiers. looping (noise); THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT FOLLOWING THESE INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR DAMAGE TO THE EQUIPMENT.

  • Page 5: Assembling And Disassembling The Plastic Cover

    ASSEMBLING AND DISASSEMBLING THE PLASTIC COVER The plastic covers are used to finish and hid the amplifier ’s fixing screws. To disassembl and assembl them, follow the instructions below. DISASSEMBLING OF THE PLASTIC COVER 1. Carefully pull out the top of the plastic cover to release the upside latches, as shown in picture 1. 2.

  • Page 6: Panels Description

    PANELS DESCRIPTION Controls, Audio inputs and outputs 10 11 12 Audio output RCA connectors Audio input Variable "HIGH PASS" filter control (5Hz ~ 80Hz) Variable "LOW PASS" filter control (80Hz ~ 20kHz) Variable Gain control Variable "BASS BOOST" control 50Hz (0dB ~ +12dB) Blue "POWER ON"...

  • Page 7: Power Supply

    PANELS DESCRIPTION Power supply 14 15 Positive power supply connector (+12VDC) BATT Remote power supply connector Negative power supply connector...

  • Page 8: Installation Sequence

    INSTALLATION SEQUENCE BEFORE PROCEEDING WITH THE INSTALLATION, UNPLUG THE NEGATIVE TERMINAL FROM ALL OF THE BATTERIES, TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND THE USER HIMSELF. Warning! Ø Mount the amplifier in such a way you have access to the connectors; Ø...

  • Page 9: Electrical Dimensioning

    ELECTRICAL DIMENSIONING AND AUDIO INPUTS ELECTRICAL DIMENSIONING For proper operation of your SounDigital amplifier, you need the proper dimensioning of the electrical system and the cables used. The table below shows the minimum section of GND cables, +12VDC cables and speaker output cables according to the power generated by the amplifier.

  • Page 10: Procedure For Setting The Gain

    GAIN SETTING Necessary equipament: Ø Set the variable "LOW" crossover in Ø Digital AC voltmeter; 20kHz; Ø Media with sine wave test tone 60Hz Ø Set the variable "HIGH" crossover in recorded at 0db; 5Hz; Ø Screwdriver 1/8" (for gain setting). Ø...

  • Page 11: Bass Boost Set Up

    BASS BOOST AND CROSSOVER SET UP Using Bass Boost The Amplifier Bass Boost setting enables the user to boost the sound intensity at low frequencies of the sound system, where boost intensity can be adjusted. This is a semi-parametric equalizer type circuit with ''Q'' value for the fixed filter, with an intensity boost adjustment from 0 to +12dB (16 times), and a central frequency adjustment of the filter in 50Hz, making it versatile for several types of sound systems.

  • Page 12: Wiring Diagram

    13 +12V Model Minimum impedance 3000.1D NANO 1Ω 1Ω 3000.1D NANO 2Ω 2Ω UNPLUG THE NEGATIVE (-) TERMINAL OF THE BATTERY BEFORE PROCEEDING WITH ANY ELETRICAL INSTALLATION IN THE VEHICLE TO AVOID FIRE STARTS, WOUNDS OR DAMAGE TO THE AMPLIFIER.

  • Page 13: Battery Connection Diagram

    BATTERY CONNECTION DIAGRAM When necessary the association of one or more battery banks to supply the necessary current to the amplifier, it is recommended to use batteries of the same brand, model, and if possible the same manufacturing lot so that the system has the maximum performance.

  • Page 14: Technical Specs

    The values presented are based on measurements performed in Updates of information made in this document will always be SounDigital's laboratories. All the equipment used in the assays, tests, published and made available for consumer consultation, free of measurements and gauging of the technical parameters of SounDigital charge, on the brand's websites.
