flyfly hobby FF-B045 Manual

Scale Glider Radio control airplane Wingspan:2.6M

Basic parts

Carbon Rod 10*420mm for main wing joinner
1
PVC Servo cover 4pcs
2
3 M4*20 Butterfly Screws for lock the wings
4 Carbon pin 6*50mm 4pcs for stable wings
Push Rod M1.5*65 *5pcs for Flap,rudder and
5
004-00140 Hinges*3
6
Soft wire*2pcs for elevator
7
LL04-405B Horns 8pcs for push all the servos
8
Metal Pinned Hinges*4pcs for canopy
9
UNDER SAFETY PRECAUTIONS
This radio controlled plane is not a toy!
Always keep this instruction manual ready on hand for quick reference.
Assemble this kit only places out of children reach.
First-time builders of RC radio power model should seek the advice of experienced modellers
before beginning assembly and if they do not fully understand any parts of the construction.
Taking out liability insurance is recommended.
You are responsible for this model's assembly and safe operation.
Simple easy DG-505 Manual
Model No:FF-B044/FF-B045
10
11
12
13
14
15
16
Page 1
FF12-05 Linkage Stoppers*10/set
M3*10 Screws*4pcs for locking motor
Metal Collar*2/set
2*8mm Screws 35 pcs
Metal Clevis M1.5 *3pcs
M4*35 Screws*2/pcs for locking the stable tail
2*25mm 6pcs Pin for Wingtips
1
3
10
11
12
13
14
15
4
5
6
7
8
9
