No Response to DMX

Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card
malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Problem Probable cause(s)
No power to the fixture
One or more
fixtures do not
function at all ArtNet protocol is not active
Fixtures reset The controller is not connected.
correctly, but all 3-pin XLR Out of the controller
respond
does not match XLR Out of the first
erratically or not
fixture on the link (i.e. signal is
at all to the
reversed)
controller
Poor data quality
Bad data link connection
Fixtures reset
Data link not terminated with 120
correctly, but
Ohm termination plug
some respond
Incorrect addressing of the fixtures
erratically or not
at all to the
controller
One of the fixtures is defective and
disturbs data transmission on the
link
3-pin XLR Out on the fixtures does
not match (pins 2 and 3 reversed)
LEDs damaged
The power supply settings do not
match local AC voltage and
frequency
Ordercode: 50802
Solution
• Check if power is switched on and
cables are plugged in
• Configure and activate ArtNet
• Connect controller.
• Install a phase reversing cable
between the controller and the
first fixture on the link
• Check data quality. If much lower
than 100 percent, the problem
may be a bad data link
connection, poor quality or
broken cables, missing termination
plug, or a defective fixture
disturbing the link
• Inspect connections and cables.
Correct poor connections. Repair
or replace damaged cables.
• Insert termination plug in output
jack of the last fixture on the link
• Check address setting
• Bypass one fixture at a time until
normal operation is restored:
unplug both connectors and
connect them directly together.
• Have the defective fixture
serviced by a qualified technician
• Install a phase-reversing cable
between the fixtures or swap pin 2
and 3 in the fixture that behaves
erratically
• Disconnect the fixture and return it
to your dealer
• Disconnect fixture. Check settings
and correct if necessary
