Summary of Contents for Ariterm Bionet 12
- Page 1 INSTALLATION, OPERATION AND MAINTENANCE • Bionet 12...
-
Page 2: Table Of Contents
Make sure to cut the power supply to the boiler before removing the burner housing. Maintenance contract Ariterm recommends the boiler installation to be made by a company with professio- nal competence. For more information please contact your Ariterm retailer. -
Page 3: Dimensions / Items Included / Technical Data
• Installation kit for solar energy powered hot water supplier (part nr 1300-55241C00) • Draught regulator Tigex Ø102 Comb. fl ue pipe Kombinationsrökrör TECHNICAL DATA Bionet 12 1. Shunt outlet DN 25 male Performance Output using pellets 12 kW 2. Return line 3. Flame observation... -
Page 4: Operating Principle
OPERATING PRINCIPLE Th e convenience, environmental performance and effi ciency are optimised to meet the demands of ease-of-use and effi cient pellet combustion. Ariterm Bionet has a vertical convection system that reduces deposition, which allows the boiler to retain a high coeffi... -
Page 5: Installation
All work on the boiler must be carried out by a qualifi ed electrician. ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 5/12... -
Page 6: Water Piping
Boiler cement is suitable for sealing. Recommended fl ue gas requirements for Bionet 12: brick chimney lined with a Ø 100 mm acid proof thin-walled tube or an acid proof Ø 100-120 mm:s element chimney. Recommended underpressure in In the following table, you will fi... -
Page 7: Filling Of Water
(recommended setting = 80°C). Th e temperature on the boiler must never be set so low that condensation forms in the boiler. ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 7/12... -
Page 8: Maintenance
ATTENTION! Show a great care when emptying the ash as it might be glowing hot. Ash must be kept in a fi reproof container. ATTENTION! Pay special attention to the pellets quality when you receive a new delivery or when you change supplier. ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 8/12... -
Page 9: Storage Planning
Th e pellet store should be designed to eliminate the risk of contamination and moisture penetration. Take special care to avoid damp penetration through the walls and fl oor. It is also important that pellets are not exposed to direct contact with water Store pipe (delivered by Ariterm), 2 x horizontal 80 mm see previous page. -
Page 10: Installation Protocol
If these instructions are not followed during installation, operation and maintenance, the obligations of Ariterm AB under the warranty regulations are no longer binding. Ariterm reserves the right to alter any details and specifi cations without prior notice. ARITERM SWEDEN AB... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY NOTES ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 11/12...
