Page 1
OWNER’S GUIDE GENTLE FLUID HEAT FOR THE PEOPLE YOU LOVE MOST For how-to videos or more information, please visit: http://cadetheat.com/install/softheat cadetheat.com/espanol/softheat ESPAÑOL ver la guía del propietario en cadetheat.com 855.CADET.US tested to UL standards Vancouver, Washington...
120 volt electrical supply will only give you one quarter of the heat output. Unanswered questions? Call our technical support team in Vancouver, Washington at 855.CADET.US (855.223.3887) or 360.693.2505. TOOLS REQUIRED Straight and Phillips Wire Strippers Wire Connectors 1½"...
If you’re wiring a BUILT-IN model EBKN thermostat, route the electrical supply wire from the circuit breaker directly to the baseboard. • SoftHEAT baseboards can only be wired on one side. They are available with either a left end wiring compartment, or a right end wiring compartment.
Page 4
B. for 120 volts, connect the neutral (white) tight. supply wire to the white heater wire (Figure 4. Screw the wiring compartment cover back on. The volume of the SoftHEAT wiring compartment is 36 cubic inches (589.9 cubic centimeters).
Page 5
3. Turn power back on at the main disconnect panel. Please verify installation After installation, operate your SoftHEAT baseboard for at least 30 minutes with the thermostat set to its maximum temperature. If your room doesn’t get warmer, please contact Cadet directly, as your electrical supply voltage may not match the heater voltage.
Page 6
This automatically resets after cooling. to/from heater In addition to the standard safety feature, 120 volt SoftHEAT baseboards have a unique built-in feature that stops electricity flowing to your heater if it’s connected to the wrong voltage.
Page 7
What is the fluid inside the element? The SoftHEAT fluid is a non-toxic mineral oil. No special first aid measures are needed if the fluid is swallowed, inhaled, or if it gets on your skin or in eyes; simply rinse or wash with soap and water.
1. Heater is 120 volts and connected to 240 volts. Replace Heats briefly then has tripped on initial startup heater with a model that is 240 volts. Call Cadet at 855.CADET. stops. or first use (120 volt models US (855.223.3887) or 360.693.2505 for assistance.
