  • Page 1 ® DataMan 300 Series Quick Reference Guide 04/26/2017 Version:5.7.0.361...
  • Page 2 CAUTION - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Do not attempt to service or repair this product -- return it to Cognex for service. Do not permit anyone other than Cognex Corporation to service, repair, or adjust this product.

  • Page 3: Product Overview

    Product Overview Laser aimer Illumination LED clusters External illumination mounting point Mounting holes (M3 x 5mm) Trigger button Power Train status Read/no-read indicator Network Error Peak meter Tuning button Ethernet External light control Power, I/O, and RS232...

  • Page 4: Dataman 300 Accessories

    DataMan 300 Accessories LENS OPTIONS AND COVERS 10.3 mm M12 lens with locking (DM300-LENS-10) and 10.3 mm IR M12 lens with locking (DM300-LENS-10-IR) Liquid lens module and pre-focused 10.3 mm or 10.3 mm IR M12 lens with wrench (DM300-LENS-10LL), (DM300-LENS-10LL-IR) 19 mm liquid lens module (DM300-LENS-19LL) 16 mm M12 lens with locking (DM300-LENS-16) 24 mm liquid lens module (DM360-LENS-24LL) 25 mm M12 lens with lens spacer and hex wrench (DM300-LENS-25) (also...
  • Page 5 Diffuse lens cover, red illumination (assembled), ESD safe (DM300-DLCOV- RE-ESD) Red LED high-powered integrated light (DM360-HPIL-RE), Polarized red LED high-powered integrated light, ESD safe (DM360-HPIL-RE-P) C-Mount cover for C-Mount lenses (DM300-CMCOV) Short C-Mount cover for C-Mount lenses (DM300-CMCOV-SH) EXTERNAL LIGHTS (RED LED) AND HIGH POWER ILLUMINATIONS Ring Light (CLRR-R7030G1CLR) Back light (CLRB-F100100G1) Coaxial (DOAL) light (CLRO-K5050G1)
  • Page 6 OTHER Connection cable 24V, I/O, RS-232 (CCB-M12x12Fy-xx) (y straight/angled, xx specifies length), and (CCBL-05-01) Power and I/O breakout cable, M12-12 (CCB-PWRIO- xx) (straight, xx specifies length: 5m, 10m, 15m), (CCB-PWRIO-xxR) (angled, xx specifies length: 5m, 10m, 15m) Connection cable RS-232 (CCB-M12xDB9Y-05) Ethernet M12 to RJ45 cable (CCB-84901-y00x-xx) (y straight/angled, x-xx specifies length) External light cable (CCB-M12x4MS-xxx) (xxx specifies length)
  • Page 7 Dimensions...

  • Page 8: Field Of View And Reading Distances

    Field of View and Reading Distances...

  • Page 11: Connecting The Reader

    Connecting the Reader...

  • Page 12: Installation

    Note: Cables are sold separately. If any of the standard components appear to be missing or damaged, immediately contact your Cognex Authorized Service Provider (ASP) or Cognex Technical Support. CAUTION: All cable connectors are "keyed" to fit the connectors on the DataMan system;...

  • Page 13: Connect The Ethernet Cable

    Connect the Ethernet Cable 1. Connect the Ethernet cable's M12 connector to the DataMan system's ENET connector. 2. Connect the Ethernet cable's RJ-45 connector to a switch/router or PC, as applicable. Connect the Breakout Cable Note: Unused wires can be clipped short or tied back using a tie made of non- conductive material.

  • Page 14: Install Software And Documentation And Connect The Reader

    DataMan support site: http://www.cognex.com/support/dataman. 1. After installing the software, connect the DataMan 300 Series reader to your PC. 2. Launch the DataMan Setup Tool and click Refresh. 3. Select your DataMan 300 Series reader from the list and click Connect.

  • Page 15: Dataman 300 Series Specifications

    DataMan 300 Series Specifications 165 g Weight 0ºC — 45ºC (+32ºF — 113ºF) Operating Temperature -10ºC — +60ºC (+14ºF — +140ºF) Storage Temperature Maximum Humidity < 95% (non-condensing) IP65 (with cable or protection cap attached to all connectors, front cover properly...
  • Page 16 24V +/- 10% Power Supply Requirements Options: Internal illumination (non-HPIL*): 250 mA maximum, 5 W Internal illumination (HPIL*): 2.2 A maximum, 6 W External illumination: up to 800 mA average, 20 W, peak current according to illumination, these values depend on the illumination and its configuration Supplied by LPS or NEC class 2 only *HPIL denotes one of the DM360-HPIL-RE or DM360-HPIL-RE-P accessories...

  • Page 17: Dataman 300 Series Imager Specifications

    DataMan 300 Series Imager Specifications Specification DataMan 300 Series Imager Image Sensor 1/1.8 inch CMOS 6.9 mm x 5.5 mm (H x V); 5.3 µm square pixels (DataMan 300 and 302), 4.5 µm square Image Sensor pixels (DataMan 303) Properties...
  • Page 18 However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Please read these guidelines carefully before using your device. Manufacturer: Cognex Corporation Regulator Specification FCC Part 15, Class A...

  • Page 19: Laser Safety Statement

    2014/30/EU Electromagnetic Compatibility Directive. For further information please contact: Cognex Corporation, One Vision Drive, Natick, MA 01760, USA . Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE.

  • Page 20: Led Safety Statement

    Risk Group 1 (Low-Risk). No further labeling is required. For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE).

  • Page 21: China Rohs

    The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration.
  • Page 22 Copyright © 2017 Cognex Corporation. All Rights Reserved.

This manual is also suitable for:

Dm300Dm302Dm303
