USE & OPERATION (CONTINUED)
CLEANING THE HONEYCOMB COOLING MEDIA
The appliance is supplied with three Honeycomb Cooling Media pads.
The Honeycomb Cooling Media are located inside the Rear and Side Grills. Follow Steps 1 to 5
for instructions on how to remove them from the unit for cleaning and maintenance.
Do not run the unit in COOL mode with stale water in the tank. You must empty the water tank
and refill with fresh water, especially if the tank has not been cleaned in a long time.
The cleaning frequency for the Honeycomb media depends on local air and water conditions. In
areas where the mineral content of water is high, mineral deposits may build up on the
Honeycomb Cooling Media and restrict air flow. Draining the water tank and refilling with fresh
water at least once a week will help reduce mineral deposits. If mineral deposits remain on the
Honeycomb Cooling Media, the media should be removed and washed under fresh water. The
media should be cleaned every two months or sooner, depending on your needs.
For best results allow the Honeycomb Cooling Media to dry after each use by turning off the
cool function 15 minutes before turning the unit off.
Step 1:
Rear Grill
Screws
Step 3:
Rear
Honeycomb Pad
Screws
Removing the Honeycomb Cooling Media:
1.
Remove the screws from the Rear Grill of the Air Cooler.
2.
Carefully pull out the Rear Grill from the Air Cooler.
3.
The Honeycomb Cooling Pad is secured on the Rear Grill by two Horizontal Bars that are fixed
in place by two screws on the Left and Right Sides of these Horizontal Bars. Remove these
screws to release the Horizontal Bars.
4.
Pull out the Honeycomb Cooling Pad by sliding it out from the Rear Grill. Replace with the new
Honeycomb Cooling Pad by sliding into the grooves of the Rear Grill until it fits comfortably
and securely in place on the grill. Replace the Horizontal Bars back onto the Rear Grill by
replacing the Left and Right Side screws and tightening them in place. This secures the
Honeycomb Cooling Pad in place on the Rear Grill.
5.
Repeat steps 1 to 4 to remove the Honeycomb Cooling Pad on the Left and Right Side Grills.
WARNING: DO NOT operate the Air Cooler when any or all of the Rear or Side Grills are removed
from the Air Cooler, or if there is a loose-fitting Rear or Side Grill. Doing so can cause serious
injury or dangerous electrical shock.
Step 2:
Rear Grill
Step 4:
Horizontal
Bars
Honeycomb Pad
EN
4
Rear
Rear Grill
Rear Grill
