Alpine IVA-D310R Service Manual page 5

System Connections
To remote control
interface box
IVA-D310R/IVA-D310RB
Tuner BOX
POWER SUPPLY
REMOTE IN / OUT
NAVIGATION IN
DISPLAY OUT
SPEAKER
LEFT
FRONT
(White)
F-Lch
• Set the system switch to "NORM" when only a changer is connected (when the Ai-NET compatible equalizer is not used).
IVA-D310R/IVA-D310RB
<Monitor>
BATTERY
(Yellow)
SUBW.
PRE IN/OUT REAR
FRONT
Ai-NET
EXT.OUT
AV SELECTOR
CAMERA IN
AUX OUT
VIDEO
L
AUDIO
R
AUX IN
RADIO ANTENNA IN
SPEAKER SPEAKER
LEFT RIGHT
REAR REAR
(White/ (Green/ (Green)
(Violet)
Black) Black)
R-Rch
R-Lch
IVA-D310R/IVA-D310RB
ILLM
Not used
(Orange)
BATTERY
(Yellow)
GND
(Black)
REMOTE OUT
(White/Brown)
REMOTE IN
(White/Brown)
REVERSE
(Orange/White)
M.CONT
(White/Pink)
REMOTE
TURN-ON
(Blue/White)
P.ANT
POWER ANT
(Blue)
AUDIO
(Blue)
INTERRUPT IN
(Pink/Black)
PARKING
BRAKE
(Yellow/Blue)
ACC
ACC
(Red)
(Red)
BATTERY
(Yellow)
GND
(Black)
SPEAKER
RIGHT
FRONT
(Violet/
(Grey/ (Grey)
Black)
Black)
F-Rch
- 5 -
Antenna
To the instrument
cluster illumination
lead
GND
(Black)
To remote input
lead.
To remote output
lead.
To plus side of
the back lamp
signal lead of the
car
To monitor
control lead.
Note:
Be sure to connect the leads
correctly after identifying the
ISO connector terminals for
the Battery and lgnition
(ACC).
