UniTraQ MT-900M User Manual

Mini tracker for mobile phone
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mini Tracker
Model:MT-900M
Mini Tracker MT-900M
MT-900M for Mobile Phone

USER MANUAL

UniTraQ International Corp. All right reserved, © 2011
2F., No.136, Ziqiang S. Rd., Zhubei City, Hsinchu County 30264, Taiwan (R.O.C.)
TEL：886-3-6578491
FAX：886-3-6578492
MADE IN TAIWAN
UniTraQ International Corp.
RoHS compliance
.
2011,04, Version 1.2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT-900M and is the answer not in the manual?

Questions and answers

Related Manuals for UniTraQ MT-900M

Summary of Contents for UniTraQ MT-900M

  • Page 1: User Manual

    Mini Tracker Model:MT-900M Mini Tracker MT-900M MT-900M for Mobile Phone USER MANUAL UniTraQ International Corp. All right reserved, © 2011 2F., No.136, Ziqiang S. Rd., Zhubei City, Hsinchu County 30264, Taiwan (R.O.C.) TEL：886-3-6578491 FAX：886-3-6578492 MADE IN TAIWAN UniTraQ International Corp.

  • Page 2: Table Of Contents

    Mini Tracker MT-900M Contents 1. BEFORE GETTING STARTED................... 4 1.1 G ...................... 4 ENERAL INFORMATION 1.2 T ................. 5 RACKER ATTERY AFETY OTICES 1.3 P ....................5 OSSIBLE DDITIONAL 1.4 A GPS ........................5 BOUT 1.5 ABOUT SIM C PIN CODE & GPRS ................6 2.
  • Page 3 Mini Tracker MT-900M A.1 G ....................23 ENERAL PECIFICATION A.2 GSM/GPRS S .................... 23 PECIFICATION A.3 GPS S ....................... 24 PECIFICATION APPENDIX B CONFIGURATION BY PC SETTING PROGRAM..........25 APPENDIX C FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT ..............................29 APPENDIX C FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT ..............................

  • Page 4: Before Getting Started

    Mini Tracker MT-900M 1. BEFORE GETTING STARTED 1.1 General information 1. The operation and positioning accuracy of the Global Positioning System, GPS, is maintained by the Defense Department of the United States of America. Based on its public policy and national security, the US government reserves the right to alter the GPS system and its accuracy without forewarning.

  • Page 5: Tracker Battery Safety Notices

    Mini Tracker MT-900M 1.2 Tracker Battery Safety Notices Failing to use the battery correctly could be hazardous. Please pay attention to the following. 1. Your mini tracker is powered by a rechargeable battery that can be frequently charged and discharged. When the device's talk time and standby time becomes shorter than normal, it is time to replace the battery.

  • Page 6: About Sim Card Pin Code & Gprs

    Notice: SIM PIN should be unlocked before being inserted into the device. SIM PIN can be disabled through ordinary cell phone. 1. GPRS function of SIM card in MT-900M is NOT Necessary enabled for normal operation; but SMS function should be always enabled.

  • Page 7: Product Information

    Mini Tracker MT-900M 2. Product Information 2.1 Introduction The MT-900M is a portable compact tracking device for personal safety and asset monitoring. It combines high sensitivity GPS and quad band GSM/GPRS to perform the powerful security application. The MT-900M can, based on quad band GSM/GPRS network and GPS satellite positioning system, track far-way objects conveniently by Short Message or internet.

  • Page 8: What's In The Package

    Mini Tracker MT-900M  Outdoor recreation – tack data record for travel, hiking, bike riding Animal tracking – track pets’ location  2.4 What's In the Package Please unpack the product package with caution; inspect the items closely. If you find any damaged item, please contact your local distributor immediately.

  • Page 9: Installing Sim Card And Charging Battery

    Mini Tracker MT-900M 3. INSTALLING SIM CARD AND CHARGING BATTERY Picture 1 3.1Device Description (1). Strap Hole (GPS antenna side) (2). Mini USB Slot and Power Switch Button (3). SIM card Slot (4). SOS Button (5). GPS Status Indicator (6).

  • Page 10: Led Indication

    Mini Tracker MT-900M *NOTE: 1. Before installing the SIM card, use a cell-phone to unlock the card's PIN code. 2. Please note that the folded corner of the SIM card should be on the Upper Right side when you install the card. (See Picture 3) 3.

  • Page 11: Recharge

    (1) Plug the USB connector of the supplied USB cable to the USB connector of the cigarette lighter power adapter. (2)Connect the mini USB plug of the USB cable to the mini USB port of the MT-900M device. 3. Charging by AC adapter: Connect the supplied AC adapter to the mini USB port of the MT-900M device.

  • Page 12: Configuration And Operation By Sms

    Mini Tracker MT-900M 4. Configuration and Operation by SMS MT-900M provides several ways for control access or configuration. From the Short Message Service (SMS), and by PC Setting program (See Appendix B), users can use the defined number cell phone to control the tracker. After received the SMS, the tracker will perform as the request command and will response to the cell phone with SMS.

  • Page 13: Operation With Cell Phone Sms

    Mini Tracker MT-900M Set Report Time * tintsetup,xxxxx# “ID” tintsetup Interval “ID” FAIL tintsetup Set Current Location *setrept,text# “ID” report type setup OK/ report type *setrept,map# “ID” report type setup FAIL Enable and Setup * geofenceon,xxxxx# “ID” geofence ON, Geofence...

  • Page 14: Calling For Help In An Emergency

    Mini Tracker MT-900M the GPS signal search function to save power (we called it get into sleep mode). If the tracker is doing report activity and can not get fixed GPS Position, it will report a possible range estimated from nearest cell phone base station.

  • Page 15: Start Tracking - Request Position

    Mini Tracker MT-900M cell phone. (2).Report location on Google Map When you send Inquire Current Location SMS(*gpsinq#) to mini tracker, mini tracker will reply an URL to your cell phone, you can hyper link this URL to internet , then you will see the location and the address on the Google map from the internet browser.

  • Page 16: Sms Commands For Inquiry

    | Cell Info} ]# “ID” gpsinq FAIL 4.2.6 SMS Commands for inquiry MT-900M provides several inquiry commands by SMS:  Inquire Current Location: Inquire the location information from the tracker. Inquire IMEI code: Inquire the GSM IMEI code from the tracker.

  • Page 17: Operation With Android App "Locu

    Mini Tracker MT-900M  Get product ID (serial number): Command Name Commands from cell phone Tracker response Inquire Current *gpsinq# *ID,pos,Date,Time,Speed, Location Course,Voltage,Device State,[ http://..{POS | Cell Info} ]# “ID” gpsinq FAIL Get Product ID (Serial *getpid# “ID” [{PID}] of PID Number) “ID”...
  • Page 18 Mini Tracker MT-900M (4) History: storage of SMS and POS records. 5.4 Setting You should run “Setting” before you start to use Tracking function. 1. Setting (1). System setting Cell phone Number: fill you Cell phone’s number to this column, it will be written to ...
  • Page 19 Mini Tracker MT-900M After setting, please press “save” and then “Go back” to Main Menu. 2. Members  Select “Member” function UniTraQ International Corp. RoHS compliance 2011,04, Version 1.2...
  • Page 20 Mini Tracker MT-900M  “Add” and “delete” members in members list. After member account is created, you can set the parameters into each member’s device.  Select “Member account”  Member Name: Assign a name that you can easily verify from the others.
  • Page 21 Mini Tracker MT-900M  After setting, please press “save” and then “Go back” to Member Menu. If the member account exists, please press “Inquiry Setting” to make sure the  setting is synchronized with the setting from the other way(e.g.:by USB) 3.
  • Page 22 Mini Tracker MT-900M  Pos: to locate the member BAT: to inquire Battery status   Voice M.: to hear surround voice from Mini Tracker from Cell phone.  Alarm Icon 1.SOS 2.Geofence 3.Over Speed Battery Status Geofence: light up when Mini Tracker is out of setting radius.

  • Page 23: Appendix A. Specifications

    Mini Tracker MT-900M Appendix A. Specifications A.1 General Specification Parameter specification Operating Voltage 3.4 V Operating Temperature 55 ℃ ℃ Storage Temperature ~ +85 ℃ ℃ Normal 150 mA Power Consumption Idle mode < 6 mA Battery 600mAh USB Power Input...

  • Page 24: Gps Specification

    Mini Tracker MT-900M A.3 GPS Specification Parameter specification Frequency L1, 1575.42MHz Channels 50 channel all in view Cold Start -143dBm Tracking sensitivity -160dBm Acquisition sensitivity -160dBm TTFF hot start < 1 sec warm start < 29 sec cold start < 29 sec Signal Reacquisition <1s...

  • Page 25: Appendix B Configuration By Pc Setting Program

    Step 1: Link COM Port Please make sure you have already installed the PC driver for MT-900M first, then use USB cable to connect MT-900 device with PC. If the device is installed properly, you will see "Connected" in message.
  • Page 26 Mini Tracker MT-900M operator's help desk to get the right one. Notice: PIN CODE of SIM card should be unlocked before being inserted into the mini tracker. SIM PIN CODE can be disabled through ordinary cell phone. The default PIN code in device is “0000”. If SIM lock is enabled and password is incorrect, power on/off device three times will make the SIM card locked permanently.
  • Page 27 Mini Tracker MT-900M Step 4: SMS & Phone Setting Enter the cell phone numbers for the tracker to report its position to via short messages. Users can configure three sets (Phone 1 to 3) of caller cell phone numbers. Only do the numbers set in the list receive returning message.
  • Page 28 Mini Tracker MT-900M Step 6: Log Data Users can download the GPS Log data to view the routes records during the past time. 1. Turn on the tracker’s power, connect it with PC. 2. Click "Get Log Data" button, and specify the path in PC to store the log data.

  • Page 29: Appendix C Federal Communication Commission Interference Statement

    Mini Tracker MT-900M Step7: Update Firmware The firmware of tracker will be updated to modify some errors. Please download the latest version and update the firmware. 1. Please click "Check New Firmware" to verify the latest version from website. 2. Download the firmware in specified path of PC.

  • Page 30: Appendix C Federal Communication Commission Interference Statement

    Mini Tracker MT-900M Appendix C Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 31 © 2011 UniTraQ International Corp. All rights reserved. Not to be reproduced in whole or part for any purpose without written permission of UniTraQ International Corp (“UniTraQ”) Information provided by UniTraQ is believed to be accurate and reliable. These materials are provided by UniTraQ as a service to its customers and may be used for informational purposes only.
