First Office STAKS Assembly Instructions Manual

Crossover casegoods
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
STAKS
Crossover Casegoods
ASSEMBLY INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAKS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for First Office STAKS

Summary of Contents for First Office STAKS

  • Page 1 STAKS Crossover Casegoods ASSEMBLY INSTRUCTIONS...

  • Page 2: Table Of Contents

    10. Shared Shelf/Organizer Installation 39-40 11. Modesty Installation 41-42 120˚ PANEL GAUGE* 12. Privacy Panel Installation 43-45 13. Tackboard Installation 48-49 14. Seat Cushion Installation CANTILEVER GAUGE* 15. Wall Mounted Storage Installation STAKS Crossover Casegoods by FIRST OFFICE | 2...
  • Page 3 #8 X 2" BLACK PHILLIPS FLAT HEAD SCREW USE WHEN CLIP POCKET IS MACHINED ON EDGE OF PANEL USE TWO FOR EACH SCREW BLOCK 5/8" SHOULDER SCREW USE WHEN CLIP POCKET IS MACHINED ON FACE OF PANEL STAKS Crossover Casegoods by FIRST OFFICE | 3...

  • Page 4: Preparation

    Wall Panels PREPARATION - T - 3 PANEL CONNECTION Use Panel Connector Kits PCK-1 or PCK-5 for 33" - 35" STAKS Crossover Casegoods by FIRST OFFICE | 4...
  • Page 5 Wall Panels PREPARATION - X PANEL CONNECTION STAKS Crossover Casegoods by FIRST OFFICE | 5...
  • Page 6 Wall Panels PREPARATION - T - 2 PANEL CONNECTION STAKS Crossover Casegoods by FIRST OFFICE | 6...
  • Page 7 Wall Panels PREPARATION - IN-LINE PANEL TO PANEL CONNECTION STAKS Crossover Casegoods by FIRST OFFICE | 7...
  • Page 8 Wall Panels PREPARATION - L PANEL CONNECTION STAKS Crossover Casegoods by FIRST OFFICE | 8...
  • Page 9 Wall Panels PREPARATION - T - 3 PANEL CONNECTION (2) 42" OR 48" Tall Panels Connected to (1) 33" Panel STAKS Crossover Casegoods by FIRST OFFICE | 9...
  • Page 10 Wall Panels PREPARATION - X PANEL CONNECTION (2) 42" OR 48" Tall Panels Connected to (2) 33" Panel STAKS Crossover Casegoods by FIRST OFFICE | 10...
  • Page 11 Wall Panels PREPARATION - INTERSECTION HIGH POINT OF FLOOR INTERSECTION (2) 48" Tall Panels Connected to (1) 42" Panel STAKS Crossover Casegoods by FIRST OFFICE | 11...
  • Page 12 Start installing panels at an intersection. If possible start panels at the highest point of an uneven floor. Level all panels before attaching any other components. INTERSECTION INTERSECTION HIGH POINT OF FLOOR STAKS Crossover Casegoods by FIRST OFFICE | 12...
  • Page 13 Attach starter post to wall using fasteners that are appropriate for the wall. Mounting holes may require counter-boring so the fastener is not past flush the face of the starter post. Install panel clips in routed pockets. Fasten panel to post. STAKS Crossover Casegoods by FIRST OFFICE | 13...
  • Page 14 Position levelers in the holes of the lower gauge Place upper gauge on top edge of panels with panels against panel stop. The upper gauge will temporarily hold panels in place until secured by cantilevers and worksurfaces. STAKS Crossover Casegoods by FIRST OFFICE | 14...
  • Page 15 Use two more screws to secure bracket in place. Place worksurfaces on cantilever brackets with 1 1/2" space between tops and panels. Screw tops to cantilever brackets. Remove upper and lower panel gauges (panel jack may be needed). STAKS Crossover Casegoods by FIRST OFFICE | 15...

  • Page 16: Pedestal Installation

    Lift drawer front straight up until clear of tabs, then pull drawer forward. PRESS TABS IN ON BOTH SIDES IMPORTANT: REMOVE THIS SCREW BOTH SIDES STAKS Crossover Casegoods by FIRST OFFICE | 16...

  • Page 17: Pedestal Installation

    Remove four screws from L-brackets that hold shelf in place. Do not remove screws from end panels. Remove shelf. Replace shelf and secure with screws after installation. REMOVE 4 SCREWS ON SHELF STAKS Crossover Casegoods by FIRST OFFICE | 17...
  • Page 18 Place riser beam on pedestal assembly with 4" spacing on both sides and 2" spacing on the front. Attach riser beam to pedestal assembly by screwing L-brackets to pedestals using #8 x 5/8" pan head screws (Hardware Kit HK-9). STAKS Crossover Casegoods by FIRST OFFICE | 18...
  • Page 19 UNFINISHED BACK 36" Wide Pedestal 4-5" UNFINISHED BACK 24" Wide Pedestal FOLD-DOWN BACK 30" Wide Pedestal "Z" BRACKET ATTACHED TO BACK PANEL (TOP VIEW) "L" BRACKET ATTACHED TO INSIDE OF END PANEL STAKS Crossover Casegoods by FIRST OFFICE | 19...
  • Page 20 Pedestal Installation STAKS Crossover Casegoods by FIRST OFFICE | 20...
  • Page 21 Pedestal Installation PEDESTAL ATTACHED TO END PANEL Pedestal Attached to End Panel STAKS Crossover Casegoods by FIRST OFFICE | 21...
  • Page 22 Any span of over 42" between supports needs an additional cantilever bracket. Use two screws in slotted holes. Make sure top of bracket is 21 3/8" from bottom edge of panel, adjust if needed. Use two more screws to secure bracket in place. STAKS Crossover Casegoods by FIRST OFFICE | 22...
  • Page 23 Any span of over 42" between supports needs an additional cantilever bracket. Use two screws in slotted holes. Make sure top of bracket is 27 3/8" from bottom edge of panel, adjust if needed. Use two more screws to secure bracket in place. STAKS Crossover Casegoods by FIRST OFFICE | 23...
  • Page 24 Refer to electrical plan drawing to determine grommet locations. Drill 2 3/8" diameter holes through panels where indicated. Install grommets in panels. Power infeed must be installed by licensed electrician. Model# DSCGB-1 (ships separately) STAKS Crossover Casegoods by FIRST OFFICE | 24...
  • Page 25 Snap blocks and jumpers together to create chain according to electrical plan drawing. Attach power infeed to chain. Leave chain in place until worksurfaces and pedestals have been installed. STAKS Crossover Casegoods by FIRST OFFICE | 25...
  • Page 26 If receptacle locations do not match plan drawing, circuits can be overloaded. Push receptacle straight back into opening in block face. Slide receptacle to the left until locked into place. BLOCK CLIP .375 STAKS Crossover Casegoods by FIRST OFFICE | 26...
  • Page 27 Refer to electrical plan drawing to determine grommet locations. Drill 2 3/8" diameter holes through panels where indicated. Install grommets in panels. Power infeed must be installed by licensed electrician. Install in wall or floor outlet. STAKS Crossover Casegoods by FIRST OFFICE | 27...
  • Page 28 Snap blocks and jumpers together to create chain according to electrical plan drawing. Attach power infeed to chain. 10. Leave chain in place until worksurfaces and pedestals have been installed. STAKS Crossover Casegoods by FIRST OFFICE | 28...
  • Page 29 Hold receptacle in specified location against bottom of worksurface and pencil mark clip location; approximately 1/2" from back edge of worksurface. Remove receptacle and screw clip in place. Snap receptacle into clip. RECEPTACLE CLIP STAKS Crossover Casegoods by FIRST OFFICE | 29...

  • Page 30: Straightener Rail Installation

    67-78" unsupported area use Hardware Kit HK-25 Center the rail in the unsupported area and space as shown on diagram below. Use screws (size??) from hardware kit provided to secure worksurface. STAKS Crossover Casegoods by FIRST OFFICE | 30...

  • Page 31: H-Base Installation

    H-Base Installation #12 x 3/4" PAN HEAD BACK/APPROACH EDGE TOP FACE DOWN USER EDGE 1/32" POSITION BASE OFF BACK/APPROACH EDGE 1/32" STAKS Crossover Casegoods by FIRST OFFICE | 31...

  • Page 32: Worksurface Support Installation

    Screw L-brackets to top using #10 x 5/8" pan head screws (Hardware Kit HK-10). Screw drop bracket to top and end panel using DROP BRACKET #10 x 3/4" pan head screws (Hardware Kit HK-9). STAKS Crossover Casegoods by FIRST OFFICE | 32...

  • Page 33: Worksurface Support Installation

    Screw to wall panel and worksurface using #10 x 5/8" Screw to back panel and worksurface using #10 x 5/8" pan head screws (Hardware Kit - HK-9). pan head screws (Hardware Kits - HK-10 & HK-11). STAKS Crossover Casegoods by FIRST OFFICE | 33...
  • Page 34 (see next page). Consult worksurface plan drawing for proper placement. Verify if 1 1/2" cable management gap is required or if worksurfaces are to mounted directly to wall panels. 1 1/2" 1 1/2" STAKS Crossover Casegoods by FIRST OFFICE | 34...
  • Page 35 Worksurface Installation CLAMP PLATE INSTALLATION Clamp plates available from item # CP-1 & Hardware Kit HK-6. Attach clamp plates. Connect spine wall worksurfaces. Attach run off worksurfaces. Secure worksurfaces to cantilever brackets. STAKS Crossover Casegoods by FIRST OFFICE | 35...
  • Page 36 Move storage tower into position. Back of storage tower should be flush to back end of worksurface. Position worksurface on cantilever brackets and L-bracket. Keep 1 1/2" gap for wire management, if needed. Attach with screws. STAKS Crossover Casegoods by FIRST OFFICE | 36...
  • Page 37 Replace upper top with attached riser support. From underneath lower top, pilot bore three 1/8" holes into bottom of riser support. 10. Screw lower top to riser support using three screws (Hardware Kit - HK-12). STAKS Crossover Casegoods by FIRST OFFICE | 37...
  • Page 38 Attach T-support to upper worksurface by aligning the mini-fix bolts with the mini-fix cams on the T-support. Secure mini-gix by turning mini-fix cams clock-wise one half turn. Continue with steps 4-10 on riser support installation instructions on previous page. STAKS Crossover Casegoods by FIRST OFFICE | 38...

  • Page 39: Shared Shelf/Organizer Installation

    Check press fit brackets to ensure they are securely affixed to panels for maximum rigidity. Screw brackets to shelf/organizer. PLACE BRACKETS POCKETS ON PANELS. DO NOT TIGHTEN! Midpoint Midpoint THREE BRACKETS TWO BRACKETS TIGHTEN STAKS Crossover Casegoods by FIRST OFFICE | 39...

  • Page 40: Shared Shelf/Organizer Installation

    SHELF MOUNTED INSTALLATION Place organizer on shelf. Position organizer on shelf so bottom is flush with shared shelf. Replace shelf screws with longer screws provided with organizer (Hardware Kit - HK-16). FLUSH FLUSH STAKS Crossover Casegoods by FIRST OFFICE | 40...

  • Page 41: Modesty Installation

    Position modesty 4" from edge of pedestal pressed against pedestal back panel. Screw brackets to bottom of worksurface. ASSEMBLED BRACKET AND MODESTY PANEL PRESSED AGAINST BACK OF PEDESTAL STAKS Crossover Casegoods by FIRST OFFICE | 41...

  • Page 42: Modesty Installation

    FRONT EDGE MODESTY PANEL Item # 6-WEMW, 6-WEMK, 6-WEMA, 6-WEMP Attach brackets (Item # WEBKT-1, WEBKT-2) to modesty panel. Tighten screws. Attach assembled modesty panel to approach edge of worksurface. Tighten screws. STAKS Crossover Casegoods by FIRST OFFICE | 42...

  • Page 43: Privacy Panel Installation

    Tighten screws to secure panel in place. Hang completed assembly on top edge of wall panel, leaving 1" gap on either side of privacy panel. Panel and bracket locations may vary. Consult plan drawing. STAKS Crossover Casegoods by FIRST OFFICE | 43...

  • Page 44: Privacy Panel Installation

    Tighten bolt on bottom of brackets to hold in place. Assemble two halves of brackets with privacy panel between two halves. Tighten screws to secure panel in place. STAKS Crossover Casegoods by FIRST OFFICE | 44...

  • Page 45: Tackboard Installation

    Peel backers off of velcro strips. Carefully position tackboard in desired location. Apply pressure to tackboard for good adhesive bond. HOLD FLUSH TO TOP EDGE PEEL BACKERS OFF OF VELCRO STRIPS TACKBOARD WITH TOOLBAR STANDARD TACKBOARD STAKS Crossover Casegoods by FIRST OFFICE | 45...

  • Page 46: Tackboard Installation

    It is important the tackboard be in the correct position the first time. Do not attempt to reposition tackboard as this will weaken the bond. STAKS Crossover Casegoods by FIRST OFFICE | 46...
  • Page 47 Line up bottom of wall bracket with scribed line on wall and mark location of fasteners. Attach to wall with appropriate fasteners for wall conditions. Lower tackboard into wall hanger. TACKBOARD SCRIBED LINE 14.875" WALL HANGER WALL HANGER SCRIBED LINE STAKS Crossover Casegoods by FIRST OFFICE | 47...

  • Page 48: Seat Cushion Installation

    Usually the cushion will also be flush to the side of the case. There will be 7/8" overhang to the top, 1/8" overhang to the drawer front, if present. Apply pressure to cushion to seat the adhesive. LOW HEIGHT BENCH HEIGHT STAKS Crossover Casegoods by FIRST OFFICE | 48...

  • Page 49: Wall Mounted Storage Installation

    Align bottom edge of mounting rail on line B and mark location of mounting holes. Fasten mounting rail to wall. Hang cabinet on mounting rail. The mounting rail attached on the back of the cabinet will rest on the mounting rail on the wall. STAKS Crossover Casegoods by FIRST OFFICE | 49...
  • Page 50 an OFS Brands™ company • 1204 East Sixth Street Huntingburg, IN 47542 • 800-983-4415 • firstoffice.com 11.16...
