RANGE
DIGITAL HANDSET OPERATION
OPERATION INSTRUCTIONS
1. Panel
1 Button: Preset 1
2 Button: Preset 2
" Increments
Display: Reads in
/
1
2
2. Initialization Procedure
The initalization procedure must be completed before the first running table after the
table is installed or parts replaced.
Press and Hold
&
down at half speed of normal operation.
Keep pressing the
&
2-5 mm, then stop.
Then release
&
together, the initialization process is complete.
3. Move Up & Down
Press and Hold
and the legs move up.
Release
and the legs stop.
Press and Hold
and the legs move down.
Release
and the legs stop.
4. Set Memory Positions
Press and Hold
&
Click button S, and then click button 1 , 2 , or 3 within next 3 seconds, this is how you save the positions.
5. Move to the Memorized Positions
Press and hold the button 1 , 2 , or 3, and the legs will return to corresponding positions saved.
6. Verify the Display Switch Data to Table Height
Check the switch display format in inches or centimeters and toggle to the unit you like and match
to the actual measurement. In inches format, the minimum adjustable height is 0.5 inches, while in
centimeters format is 1 centimeter.
Set the table at any height (reccommended at the bottom position), measure the table actual height
and write down the number in inches or in centimeters.
Press and Hold the button S, then press and hold
start flashing on the screen.
Release the buttons and click on either
increased or decreased to the first number you measured.
Click button S and the second number should start flashing on the screen.
Click
or
to change the number, the second number is being increased or decreased to the second
number you measured.
Click button S, the third number should start flashing on the screen.
Click
or
to change the number, The third number is being increased or decreased to the third
number you measured.
Click button S, completed.
3 Button: Preset 3
S Button: Select
simultaneously for more than 3 seconds, the legs begin to move
, notice the legs move down to the lowest position and rebound
, then release and run the legs to the position you want the table surface to be.
or
to change the first number. The first number is being
, keep for about 3 seconds. The first number should
INSTRUCTION SHEET #2577INS
PART #1730534
