DVD Player

DN-V300

Serial Control

Instructions
For product improvement or other reasons, specifications may be changed, deleted, etc., without prior
notice.
It is prohibited to reproduce these specifications or to distribute or transfer them to third parties without
the consent of Denon. Please return them if they are no longer needed.
Revision
Date
Description
1.0
2005-2-14
Original issue
Approved by Inspected by Person in charge
D&M Holdings Inc.
１

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DN-V300 and is the answer not in the manual?

Questions and answers

Related Manuals for Denon DN-V300

Summary of Contents for Denon DN-V300

  • Page 1: Dvd Player

    For product improvement or other reasons, specifications may be changed, deleted, etc., without prior notice. It is prohibited to reproduce these specifications or to distribute or transfer them to third parties without the consent of Denon. Please return them if they are no longer needed. Revision Date...
  • Page 2 History ・2005-2-14 – Original Issue ２...

  • Page 3: Table Of Contents

    Contents 1. Serial Remote Control Terminal ............４ 2. Serial Remote Control ................５ Basic Protocol for Sending and Receiving Commands Command format Command transmission and reply message Error codes Command reference Response 3. Description of PC Commands ............... ９ 4. Description of PS Commands ............１３ 5.

  • Page 4: Serial Remote Control Terminal

    Serial Remote Control Terminal Remote control of the DN-V300 is possible by connecting the serial interface of a PC, etc., to the serial remote terminal on the rear panel. The commands usable with serial remote are categorized in three groups, the PC group controlling the DN-V300, the PS group for acquiring information on the DN-V300’s operating status, and the PR group of status information issued asynchronously from the...

  • Page 5: Serial Remote Control

    ： The DN-V300 plays the assigned title and returns the error code 0 (no error). Command transmission and reply message When the DN-V300 receives a command and completes the instructed task or when an error occurs, the DN-V300 returns a reply message to the controller. The reply message consists of the sent command to which an error code is added.

  • Page 6: Error Codes

    Example: When playing a DVD, pause after playing Title 1. [PC,PlayT,1]<CR> → Command to play Title 1 sent from controller. [PC,PlayT,0] ← Reply of error code 0 (no error) from DN-V300. [PC,RC,48]<CR> → Pause command sent from controller. [PC,RC,0] ← Reply of error code 0 (no error) from DN-V300.
  • Page 7 Ⅱ. External Control Status: List of PS group status confirmation commands Command name Command Function Parameter range 10 Get player status GetStatus Get DN-V300’s operating status. 0 to 5 11 Get current disc type GetDiscType type disc loaded 0 to 4 DN-V300.
  • Page 8 DN-V300 Serial Remote Control V300 Response PC control PLAY PAUSE STOP VCD PBC OPEN LODING No Disc Menu RESUME PLAY group command VCD(PBC ON) VCD(PBC OFF) MP3/JPEG All Disc VCD: PBC OFF MP3/JPEG /other Play Doesn't use Code: Error code2, Disc difference Code: Error code10, Dimension over Code: Error code5 OK->Title Play...

  • Page 9: Description Of Pc Commands

    [PC,RC,44]<CR> → Code 44 (Play) is sent from the controller. [PC,RC,0] ← Error code 0 (no error) is returned from the DN-V300 and playback starts. ※ When in the power off standby mode, basically PS and PC group commands are not accepted.
  • Page 10 Example: To start playing title 1 chapter 5 [PC,PlayC,1,5]<CR> → The command to play title 1 chapter 5 is sent from the controller. [PC,PlayC,0] ← Error code 0 (no error) is returned from the DN-V300 and playback starts. １０...
  • Page 11 [PC,SetAST,1]<CR> → Audio stream 1 is sent from the controller. [PC,SetAST,0] ← Error code 0 (no error) is returned from the DN-V300 and the setting is made. Set sub-picture stream command ( SetSPST ) ---- Valid for DVDs <Format> [PC,SetSPST,Sub-picture stream No.]<CR>...
  • Page 12 [PC,OSD,OFF]<CR> → The command for turning the OSD off is sent from the controller. [PC,OSD,0] ← Error code 0 (no error) is returned from the DN-V300 and the setting is made. SW on/off local keyboard lock setting command ( LKC ) ---- Valid when the power is on <Format>...

  • Page 13: Description Of Ps Commands

    DN-V300’s status. ・During loading, the DN-V300 does not respond to the command, and the received command is not valid. Send the command again after loading is completed or until there is a response.
  • Page 14 (For the error codes, refer to the list of error codes on page 6.) <Details> ・In the play or pause mode on a DVD, requests the currently selected audio stream setting. ・In response to the request, the DN-V300 returns the error code corresponding to the sent command and the current audio stream number.
  • Page 15 (For the error codes, refer to the list of error codes on page 6.) <Details> ・In the play or pause mode, requests the current title number and chapter number. ・In response to the request, the DN-V300 returns the error code corresponding to the sent command and the current title number and chapter number.

  • Page 16: Description Of Pr Commands

    <Details> ・If playback of a new chapter has started due to the play or skip operations, etc., the change is status is notified. ・When playback of a chapter starts, the DN-V300 issues a message consisting of this command, the operating status error code, and the number of the title and chapter which has started playing.
  • Page 17 Pause Still or pause mode condition Example: If the DN-V300’s operating status has changed from the stop to the play condition [PR,StatusChange,0,4] ← Operating status error code 0 (no error) and play mode status code 4 are sent from the DN-V300.

  • Page 18: Appendix 1 Pr Group Commands And Changes Of Status

    Appendix 1 PR Group Commands and Changes of Status With the DN-V300, the changes of status (or mode) differ for different types of discs. The diagrams below show the relationship between the changes of status and the commands for the different types of discs.
  • Page 19 Appendix 1 PR Group Commands and Changes of Status (continued) ■ Status change diagram for when a VCD is loaded and PBC is off Mode Change & PR command 〔VCD PBC:OFF〕 Status4 No Change Status4 No Change PLAY SKIP RC Skip Skip PlayT →Play...
  • Page 20 Appendix 1 PR Group Commands and Changes of Status (continued) ■ Status change diagram for when an MP3 disc is loaded Mode Change & PR command 〔MP3〕 Status4 No Change Status4 No Change PLAY SKIP RC Skip Status2 Status2 RC Play RC 10key No Disc DiscErr...

  • Page 21: Appendix 2 Example Of Jpeg Pause Playback Using The Pc Rc Commands

    Appendix 2 Example of JPEG Pause Playback using the PC RC Commands With the DN-V300, pause playback of still JPEG images using serial remote can be performed using a sequence of PC RC commands. In concrete terms, there are two ways of doing this: by using the digit 0 to 9 and +10 key codes, and by using the SKIP key code.
  • Page 22 Appendix 2 Example of JPEG Pause Playback using the PC RC Commands (continued) 2. Using the SKIP key code Controller DN-V300 Power ON ↓ [PR.StatusChange,0,4] (auto playback when power is turned on) [PC,RC,48] (Pause) [PC.RC,0] (No Error) [PR,StatusChange,0,5] (status changes to pause)

  • Page 23: Appendix 3 Stopping And Resuming Status Of Dvd

    Appendix 3 Stopping and Resuming Status of DVD With the DN-V300, when playing a DVD, when the stop operation is performed or the stop command is issued for the first time, the DN-V300 changes to the resume mode, and when the stop operation is performed or the stop command is issued for a second time, the DN-V300 changes to the stop mode.

  • Page 24: Appendix 4 Hyper Terminal Settings

    1. Connecting the personal computer and DN-V300 ・When connecting the personal computer, use a male-female serial straight cable. ・To prevent malfunction, make sure the power of both the DN-V300 and personal computer are off when connecting the serial straight cable to the serial terminals.
  • Page 25 “OK”. The window in 6 above reappears. Click “OK”. This completes the Hyper Terminal settings. 8. Checking the connection ・When the DN-V300’s tray opens, [PR,StatusChange,1] should appear on the Hyper Terminal window. ・When a CD-DA disc is loaded and [PC,PlayT,1] is sent, Track 1 should be played.
