Page 1 Ver. 1 SERVICE MANUAL MODEL E2A E1C E1K EUT DN-V210 DN-V310 DVD VIDEO PLAYER 注意サービスをおこなう前に、このサービスマニュアルを必ずお読みください。本機は、火災、感電、けがなどに対する安全性を確保するために、さまざまな配慮をおこなっており、また法的には「電気用品安全法」にもとづき、所定の許可を得て製造されております。従ってサービスをおこなう際は、これらの安全性が維持されるよう、このサービスマニュアルに記載されている注意事項を必ずお守りください。 For purposes of improvement, specifications and ● 本機の仕様は性能改良のため、予告なく変更すること ● design are subject to change without notice. があります。...
Page 2: Safety Precautions
DN-V210/DN-V310 SAFETY PRECAUTIONS The following check should be performed for the continued protection of the customer and service technician. LEAKAGE CURRENT CHECK Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.
Page 3: Block Diagram
DN-V210/DN-V310 BLOCK DIAGRAM...
Page 4 DN-V210/DN-V310 SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. 主な半導体を記載しています。汎用の半導体は記載を省略しています。 IC's ● ZR36888HLCG (IC10) Pin Functions Dir. Description 1 GPCI/O[52] General purpose input/output, monitored/controlled by the CPU or DSP SW DVDVALID AV data valid input for FE by-pass. Programmable polarity...
Page 5 DN-V210/DN-V310 Pin Functions Dir. Description FGPCI/O[0] General purpose input/output, monitored/controlled by the V8 SW PM[5] Probe mux data output 11 MEMCS[1]# PNVM/SRAM chip select (active low) output GPCI/O[18] General purpose input/output, monitored/controlled by the CPU or DSP SW FCUIF[29] Flash card interface unit output signal MEMLSB PNVM/SRAM address I.s.
Page 6 DN-V210/DN-V310 Pin Functions Dir. Description PLLABYP PLLA by-pass selection input. Level sampled during RESET. In normal operation the pin must be low during RESET 38 GNDC Digital core ground of 1.8 V supply 39 MEMAD[10] PNVM/SRAM bi-directional data bus FCUIF[23]...
Page 7 DN-V210/DN-V310 Pin Functions Dir. Description 86 RAMCS[0]# SDRAM chip select (active low) RAMBA[1] SDRAM bank select output 87 RAMBA[0] SDRAM bank select output 88 GNDP Digital periphery ground of 3.3 V supply 89 RAMCS[1]# SDRAM chip select (active low) output...
Page 8 DN-V210/DN-V310 Pin Functions Dir. Description ADPWMN[2] Class D audio channel 2 output, negative signal PM[7] Probe mux data output 131 ALRCLK Digital audio left/right select output for the audio port. Square wave, at the sampling fre- quency. Programmable polarity GPCI/O[66]...
Page 9 DN-V210/DN-V310 Pin Functions Dir. Description PM[12] Probe mux data output 150 VID[1] Digital 4:2:2 video luma/chroma input/output, interleaved U, Y, V, Y GPCI/O[30] General purpose input/output, monitored/controlled by the CPU or DSP SW ADPWMN[6] Class D audio channel 6 output, positive signal...
Page 10 DN-V210/DN-V310 Pin Functions Dir. Description 195 ADCIN[G] ADC input signal (e.g. from OPU) 196 ADCIN[A] ADC input signal (e.g. from OPU) 197 VDDAFE Analog AFE 3.3 V supply 198 ADCIN[B] ADC input signal (e.g. from OPU) 199 VDDSAFE Analog AFE 3.3 V supply shield 200 VDDAFE Analog AFE 3.3 V supply...
Page 11 DN-V210/DN-V310 Pin Functions Dir. Description GPCI/O[41] General purpose input/output, monitored/controlled by the CPU or DSP SW 239 DUPRD0 First debug UART data input GPCI/O[35] General purpose input/output, monitored/controlled by the CPU or DSP SW 240 DUPTD0 First debug UART data input...
Page 12 DN-V210/DN-V310 M12L64164-7T (IC12)
Page 13 DN-V210/DN-V310 AM5888SLF (IC16) VINFC MUTE TRB_1 BIAS REGO 2 VINTK Block diagram VINSL+ TRB_2 REGO 1 VINLD Vcc1 VCTL VOTR- VOTR+ Vcc2 VOSL+ VOLD- VOSL- VOLD+ VOFC- VOTK- VOFC+ VOTK+ Pin description PIN No Pin Name Function VINFC Input for focus driver...
Page 14 DN-V210/DN-V310 PT6315LQ (IC31) BLOCK DIAGRAM...
Page 15 DN-V210/DN-V310 ST72F324BJ4T6 (IC51) 44 43 42 41 40 39 38 37 36 35 34 RDI / PE1 SS_1 DD_1 PA3 (HS) PC7 / SS / AIN15 PC6 / SCK / ICCCLK (HS) PB4 PC5 / MOSI / AIN14 AIN0 / PD0...
Page 16 DN-V210/DN-V310 BH7862FS (IC81) BA7660FS (IC82)
Page 17: Pin Connection
DN-V210/DN-V310 FL DISPLAY HNV-06SC15T (FIP1) ● PIN CONNECTION GRID ASSIGNMENT ANODE CONNECTION...
Page 18 PRINTED WIRING BOARDS DN-V210/DN-V310 CUP11987 AV P.W.B. UNIT ASS'Y COMPONENT SIDE...
Page 19 DN-V210/DN-V310 CUP11987 AV P.W.B. UNIT ASS'Y FOIL SIDE...
Page 20 DN-V210/DN-V310 CUP11958 MPEG P.W.B. UNITASS'Y COMPONENT SIDE...
Page 21 DN-V210/DN-V310 CUP11958 MPEG P.W.B. UNITASS'Y FOIL SIDE...
Page 22 DN-V210/DN-V310 CUP11840 SMPS P.W.B. UNIT ASS'Y FOIL SIDE COMPONENT SIDE...
Page 23: Note For Parts List
DN-V210/DN-V310 NOTE FOR PARTS LIST 部品表について • Parts for which "nsp" is indicated on this table cannot be supplied. １．部品表に "nsp" と記載されている部品は供給できません。 • When ordering of part, clearly indicate "1" and "I" (i) to avoid mis- ２．部品を発注する際は特に数字の " １ " と英字の "Ｉ" との区別をはっき...
Page 24: Parts List Of P.w.b. Unit
DN-V210/DN-V310 PARTS LIST OF P.W.B. UNIT ＊本表に "nsp" と記載されている部品は供給できません。＊ Parts for which "nsp" is indicated on this table cannot be supplied. ＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Page 25 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New R271 RES , CHIP CRJ10DJ182T CAPACITORS GROUP C101 CAP , CHIP TANTAL(A TYPE, 22uF) CCSJA0J220B C102 CAP , CHIP 0 CCUS1H103KC C103 CAP , CHIP 0 CCUS1H103KC C104 CAP , CHIP 0...
Page 26 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New C166 CAP , CHIP ELECT 100UF/6.3V HCEC0JRV2101T C167 CAP , CHIP 3 CCUS1H330JA C168 CAP , CHIP 3 CCUS1H330JA C169 CAP , CHIP 3 CCUS1H330JA C170 CAP , CHIP 3...
Page 27 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New C232 CAP , CHIP ELECT 47UF/6.3V HCEC0JRV2470T C233 CAP , CHIP 0 CCUS1H104KC C234 CAP , CHIP 0 CCUS1H104KC C250 CAP , CHIP ELECT 47UF/6.3V HCEC0JRV2470T C252 CAP , CHIP ELECT 47UF/6.3V...
Page 28 DN-V210/DN-V310 COP11840 SMPS P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP IC91 00D 943 0209 109 I.C, PWM SG6848DZ BVISG6848DZ IC92 90M -HC 3007 70R I.C, REGULATOR KIA431B HVIKIA431BAT D901 00D 943 0153 405 DIODE...
Page 29 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New C905 00D 943 0057 404 CAP , SEMICONDUCTOR 0 CCFT1H104ZF C906 00D 943 0073 103 CAP , CERAMIC 10 CCKT1H101KB C907 00D 943 0175 108 CAP , ELECT 10UF 50V...
Page 30 DN-V210/DN-V310 COP11987 AV P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP IC31 00D 943 0155 209 I.C VFD DRIVER PT6315 HVIPT6315LQ IC51 00D 943 0209 604 IC , FLASH U-COM TLCS-870/C SERIES/TM CVIST72F324BJ4T6 IC52 90M -HC 1084 30R I.C TC74HC7007AFEL...
Page 31 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New R503 00D 943 0101 101 WIRE , COPPER SN95/PB5 , 0.6 C3A206 R510 RES , CARBON CRD20TJ391T R513 00D 943 0101 101 WIRE , COPPER SN95/PB5 , 0.6 C3A206 R603 00D 943 0015 828 RES , CARBON...
Page 32 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New C610 00D 943 0016 018 CAP , CERAMIC 0 HCBS1H104ZFT C611 00D 943 0188 205 CAP , ELECT 220UF 16V CCEA1CH221T C612 00D 943 0016 018 CAP , CERAMIC 0...
Page 33 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New C835 00D 943 0175 108 CAP , ELECT 10UF 50V CCEA1HH100T C836 00D 943 0148 708 CAP , ELECT 47UF 50V CCEA1HH470T C837 00D 943 0148 708 CAP , ELECT 47UF 50V...
Page 34 DN-V210/DN-V310 EXPLODED VIEW Europe(E2) model only. DN-V310 model only. WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
Page 35: Parts List Of Exploded View
DN-V210/DN-V310 PARTS LIST OF EXPLODED VIEW ＊本表に "nsp" と記載されている部品は供給できません。＊ Parts for which "nsp" is indicated on this table cannot be supplied. ＊本表に "nsp" と記載されている基板 ASS’Y は供給できません。基板 ASS’Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
Page 36 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New TUBE , UL C4B120122 ★ A4 ★ A5 00D 943 0164 203 FERRITE , RING 29X7.7X19 CLZ9W003Z INSULATOR , SMPS L54 CMX1A221 ★ A6 ★ A7 00D 943 0214 204 CABLE , CARD 1M/M...
Page 37: Packing View
DN-V210/DN-V310 PACKING VIEW 210/310E3 model 210/310E2 model PARTS LIST OF PACKING & ACCESSORIES ＊本表に "nsp" と記載されている部品は供給できません。＊ Parts for which "nsp" is indicated on this table cannot be supplied. ＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Page 38 DN-V210/DN-V310 Ref. No. Part No. Part Name Remarks Q'ty New 5 00D 943 0025 300 PAD, GUIDE CPG1A752 LABEL, SERIAL NO CQB1A622 LABEL, MANUFAC.DATE for 210/310E3 CQB1A671Z RACK MOUNT PACKING ASS'Y CMPDNV210 BOX, RACK MOUNT CPG1A832 ANGLE, FRONT MOUNT CMP1A003B5...
Page 39: Wiring Diagram
DN-V210/DN-V310 WIRING DIAGRAM...
Page 40: Note For Schematic Diagram
DN-V210/DN-V310 NOTE FOR SCHEMATIC DIAGRAM 配線図について WARNING: ! 印の部品は安全を維持するために重要な部品です。従って交換時は必ず指定の部品を使用してください。 Parts marked with this symbol ! have critical characteristics. Use ONLY replacement parts recommended by the manufactur- 注） CAUTION: (1) 指定なき抵抗値は Ω、ｋはｋΩ、M は MΩ を示す。 Before returning the unit to the customer, make sure you make μ...
Page 41 SCHEMATIC DIAGRAMS (1/3) DN-V210/DN-V310 SCHEMATIC DIAGRAMS (1/3) CPU11958 MPEG UNIT...
Page 42 SCHEMATIC DIAGRAMS (2/3) DN-V210/DN-V310 SCHEMATIC DIAGRAMS (2/3) CPU11987 AV UNIT...
Page 43 SCHEMATIC DIAGRAMS (3/3) DN-V210/DN-V310 SCHEMATIC DIAGRAMS (3/3) CPU11840 SMPS UNIT...
