Please refer to the following sheet for more details about each component.
SN
①
②
③
④
⑤
⑥
⑦
⑧
Note:
For reset, long press for 8 seconds and then the light off; For WPS (Wi-Fi Protected Setup), one quick
press.
Please refer to the following sheet for more details about status of indicator light.
Figure 2-2
Name
Reset/ WPS (Wi-Fi Protected Setup) button
Indicator light 1
Lower cover
Micro SD card slot
Indicator light 2
Waterproof ring
Wifi antenna
Locking screw
Sheet 2-2
3
