- Page 1 HA - MC01 Installation Manual Guide to intelligent Alarm Immobiliser 9001 ISO 9001 QS 9000 Manufacturer: COMMERCIAL ELECTRONICS 264 HAYDONS ROAD, WIMBLEDON, LONDON SW19 8TT. UK TEL: +44 020 8404 7105 FAX: +44 020 84047104 http://www.hawkcaralarm.com e-mail: info@hawkcaralarm.com...
-
Page 2: General Guidance
Installing HAWK® Motorcycle Alarm System (General Guidance) We think youʼve made an excellent choice in allowing HAWK® to protect your bike. Now the question is: “How in the world am I going to install this – there are so many wires.” What seems like a hard task is actually not too bad;... - Page 3 Wiring the Alarm Unit Once the panels are removed, you will want to locate a good spot to mount the module. The harder to see, the better. This will make it much more difficult for a would-be-thief. You will generally tie strap, screw, or adhere (if adhesive pad is provided) the module to a support brace or stiff, flat surface.
- Page 4 Reverse Polarity Reverse Polarity is the combination of 2 wires operating a motor of some sort. When you activate a reverse polarity motor, one wire goes to 12volts the other wire becomes grounded (-). When you move the motor in the opposite direction, the leads swap polarity. To test for a reverse polarity system, do as follows.
-
Page 5: Planning The Installation
Install Your HAWK compact Motorcycle Alarm System PLANNING THE INSTALLATION The Box Contains Tools Required • The Control Unit • Pliers/Cable Cutters • Two Remote Transmitters • Motorcycle wiring diagram • Installation Instruction • Drill (9.5mm & 8mm bits) •... - Page 6 INSTALLATION OF MAIN SYSTEM COMPONENTS Great care has been take in the design and manufacture of HAWK products, Correct installation and good working practices will enhance the operation of the alarm system and give long term benefit to the user.
- Page 7 6. Engine immobilisation- there are 4 cables 1) BLACK/WHITE wire 2) WHITE/ BLACK wire 3) Grey 4) Grey. Recommended circuits are the starter motor or fuel pump relay. (The CPU on Italian motorcycles or the Hall Effect ignition on Harley Davidsons is not recommended.) 7.
- Page 8 ATTENTION: Commercial Electronics always suggests installation be performed by a certified and trained installation technician, professional installation is requirement to obtain full warranty. This wiring information is being provided free of charge and on an “as is” basis, without any representation or warranty to the products being installed.
